Stationary training equipment - Part 2: Strength training equipment, additional specific safety requirements and test methods (ISO 20957-2:2020)

This document specifies additional safety requirements for stationary strength training equipment.
This document is intended to be read in conjunction with the general safety requirements of ISO 20957‑1.
This document is applicable to stationary training equipment type strength training equipment with stacked weight resistance or other means of resistance, such as elastic cords, hydraulic, pneumatic, electrical, magnetic, springs and externally loaded weights (type 2) (hereinafter referred to as training equipment) with the classes H, S and I according to ISO 20957‑1.
NOTE Free-weight barbell racks are subject to the requirements of ISO 20957‑4 and ISO 20957‑1.

Stationäre Trainingsgeräte - Teil 2: Kraft-Trainingsgeräte, zusätzliche besondere sicherheitstechnische Anforderungen und Prüfverfahren (ISO 20957-2:2020)

Dieses Dokument legt weitere sicherheitstechnische Anforderungen für stationäre Kraft Trainingsgeräte fest.
Es ist vorgesehen dieses Dokument in Verbindung mit den allgemeinen sicherheitstechnischen Anforderungen nach ISO 20957 1, anzuwenden.
Dieses Dokument gilt für stationäre Trainingsgeräte vom Typ Kraft Trainingsgeräte (Typ 2) (im Folgenden Trainingsgeräte genannt) der Klassen H, S und I nach ISO 20957 1, bei denen der Widerstand durch Steckgewichte oder andere Widerstandssysteme, wie elastische Bänder, Hydraulik, Pneumatik, Elektronik, Magnetkraft, Federn und extern belastete Gewichte aufgebaut wird.
ANMERKUNG   Ablagen für Langhanteln mit freien Gewichten unterliegen den Anforderungen von ISO 20957 4 und ISO 20957 1.

Équipement d'entraînement fixe - Partie 2: Équipement d'entraînement de force, exigences spécifiques de sécurité et méthodes d'essai supplémentaires (ISO 20957-2:2020)

Le présent document spécifie des exigences de sécurité supplémentaires pour les équipements d'entraînement fixes de force.
Le présent document est destiné à être lu conjointement aux exigences de sécurité générales figurant dans l'ISO 20957‑1.
Le présent document s'applique aux équipements d'entraînement fixes de type équipements d'entraînement de force utilisant une résistance à l'aide de piles de poids ou d'autres moyens de résistance comme de la corde élastique, des systèmes hydrauliques, pneumatiques, électriques, magnétiques ou à ressorts et des poids chargés par l'extérieur (type 2) (équipements désignés ci-après par « équipements d'entraînement ») de classes H, S et I, conformément à l'ISO 20957‑1.
NOTE Les supports de poids et d'haltères libres sont soumis aux exigences de l'ISO 20957‑4 et de l'ISO 20957‑1.
