(Main)Space product assurance - Repair and modification of printed circuit board assemblies for space use
Space product assurance - Repair and modification of printed circuit board assemblies for space use
The requirements and procedures for repair and modification detailed in this Standard are designed to maintain the rigorous standards set
by the customer for the manufacture and assembly of space-quality printed circuit boards.
This Standard is confined to the repair and modification of singlesided, doublesided and multilayer printed circuit board assemblies.
This Standard does not address the potential need for rework resulting from a repair or modification and unassembled (bare) printed
circuits boards.
This standard may be tailored for the specific characteristics and constraints of a space project, in conformance with ECSS-S-ST-00.
Raumfahrtproduktsicherung - Reparatur und Modifikation von Leiterplatten-Baugruppen für den Einsatz im Weltraum
Assurance produit des projets spatiaux - Réparation et modification des ensembles de circuits imprimés pour utilisation spatiale
Zagotavljanje varnih proizvodov v vesoljski tehniki - Popravilo in spreminjanje plošč tiskanih vezij za vesoljsko uporabo
Zahteve in postopki za popravilo in spreminjanje iz tega standarda so namenjeni ohranjanju strogih standardov, ki jih določa odjemalec za proizvodnjo in sestavo plošč tiskanih vezij za vesoljsko uporabo. Ta standard je omejen na popravilo in spreminjanje enostranskih, dvostranskih in večslojnih plošč tiskanih vezij. Ta standard ne obravnava potencialne potrebe po predelavi, ki izhaja iz popravila ali spreminjanja, ter nesestavljenih (praznih) plošč tiskanih vezij. Ta standard se lahko prilagodi posameznim lastnostim in omejitvam vesoljskega projekta v skladu s standardom ECSS-S-ST-00.
