EN 14469-2:2004

Pigments and extenders - Testing of colouring materials in plasticized polyvinyl chloride (PVC-P) - Part 2: Preparation of test specimens

This Part of EN 14469  specifies a procedure for preparing test samples for the testing of colouring materials )  in plasticized polyvinyl chloride (PVC-P) materials. It describes the manner in which basic mixtures as defined in EN 14469 -1 and pigments and pigment preparations are to be used to prepare test samples for the testing of particular pigment properties. The standard is applicable to inorganic and organic pigments, and also to pigment preparations in powder, paste or granular form (see Annex A (informative)).

Pigmente und Füllstoffe - Prüfung von Farbmitteln in weichmacherhaltigem Polyvinylchlorid (PVC-P) - Teil 2: Herstellen der Probenkörper

Dieser Teil von EN 14469 legt ein Verfahren zum Herstellen von Probenkörpern für die Prüfung von Farbmitteln ) in weichmacherhaltigem Polyvinylchlorid (PVC-P) fest. Es wird beschrieben, wie aus Grundmischungen nach prEN 14469-1 und Pigmenten sowie Pigmentpräparationen Probenkörper für die Prüfung bestimmter Pigmenteigenschaften herzustellen sind. Die Norm ist anwendbar für anorganische und organische Pigmente sowie für pulverförmige, pastenförmige und granulierte Pigmentpräparationen (siehe Anhang A (informativ)).

Pigments et matières de charge - Essai des matières colorantes dans le chlorure de polyvinyle plastifié (PVC-P) - Partie 2: Préparation des éprouvettes

Pigmenti in polnila - Preskušanje sredstev za obarvanje v mehčanem polivinilkloridu (PVC-P) - 2. del: Priprava preskusnih vzorcev

General Information

• Status: Published
• Publication Date: 27-Apr-2004
• ICS: 83.040.30 - Auxiliary materials and additives for plastics
• Technical Committee: CEN/TC 298 - Pigments and extenders
• Drafting Committee: CEN/TC 298/WG 1 - Colouring materials in plastics
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 27-Mar-2025
• Completion Date: 14-Apr-2025
• Ref Project: SIST EN 14469-2:2004 - Pigments and extenders - Testing of colouring materials in plasticized polyvinyl chloride (PVC-P) - Part 2: Preparation of test specimens

Overview

EN 14469-2:2004 is a European standard developed by CEN that specifies procedures for the preparation of test specimens used in evaluating colouring materials in plasticized polyvinyl chloride (PVC-P). As part two of the EN 14469 series, this standard focuses on the method of preparing test samples that allows accurate testing of pigment properties in PVC-P materials. It applies to a broad range of pigments including inorganic and organic types, as well as pigment preparations in powder, paste, or granular forms.

This standard plays a critical role in ensuring consistent and reproducible testing conditions, which translates to reliable results when evaluating pigment performance in plasticized PVC applications.

Key Topics

• Scope and Applicability
  EN 14469-2 applies to coloring materials tested within plasticized PVC matrices. It is designed for use with both pigments and pigment preparations as detailed in EN 14469-1, covering testing for specific pigment properties.

• Preparation Procedure
  The standard outlines step-by-step processes for:

  • Sampling colouring materials in compliance with EN ISO 15528.
  • Premixing pigments with a predefined PVC basic mixture to achieve homogeneity.
  • Milling the pigment-PVC mixture on a heated two-roll mill under controlled settings to form test sheets of uniform thickness (0.4 mm to 0.5 mm).
  • Pressing milled sheets under specific temperature and pressure conditions to improve surface quality and sample thickness for photometric analysis.

• Required Equipment
  Key apparatus includes:

  • Mixing vessels or beakers for premixing pigment and PVC mixtures.
  • Two-roll mills capable of precise temperature control, adjustable roll separation, and proper rotation speeds.
  • Plate presses for optional sample pressing to enhance gloss and thickness.

• Quality Assurance Notes
  The standard emphasizes the importance of:

  • Avoiding additional grinding during premixing to prevent altering pigment dispersion.
  • Ensuring thorough mixing during two-roll milling, commonly carried out over 200 roll revolutions within 5-10 minutes.
  • Rapid cooling after pressing to prevent thermal degradation of the specimen.

• Informative Annex
  Annex A provides additional guidance on laboratory practices, impact of pigment carrier materials, and variability accommodation in laboratory apparatus.

Applications

• Pigment Testing in PVC-P
  Enables manufacturers and testing laboratories to prepare specimens for evaluating pigment properties such as color strength, dispersion quality, and stability within plasticized PVC matrices.

• Quality Control in PVC Industry
  Assists in quality assurance workflows by standardizing test specimen preparation, thus supporting accurate comparison of pigment batches or new formulations.

• Research and Development
  Provides a reproducible method for formulating test sheets during pigment innovation, helping to assess compatibility and performance before commercial production.

• Regulatory Compliance
  Supports compliance with European testing standards for pigments and extenders used in flexible PVC products.

Related Standards

• EN 14469-1:2004 - Composition and preparation of basic mixtures for pigment testing in PVC-P.
• EN ISO 15528:2000 - Sampling methods for paints, varnishes, and raw materials used in coatings.
• EN 971-1 - Definitions for paints and varnishes terminology, including 'colouring materials'.

---

By adhering to EN 14469-2:2004, stakeholders in the pigments and PVC industries can ensure consistency, reliability, and comparability in the testing of coloured plasticized PVC materials. This facilitates better product development, compliance, and quality assurance throughout the supply chain.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.PPigmente und Füllstoffe - Prüfung von Farbmitteln in weichmacherhaltigem Polyvinylchlorid (PVC-P) - Teil 2: Herstellen der ProbenkörperPigments et matieres de charge - Essai des matieres colorantes dans le chlorure de polyvinyle plastifié (PVC-P) - Partie 2: Préparation des éprouvettesPigments and extenders - Testing of colouring materials in plasticized polyvinyl chloride (PVC-P) - Part 2: Preparation of test specimens83.040.30Pomožni materiali in aditivi za polimerne materialeAuxiliary materials and additives for plasticsICS:Ta slovenski standard je istoveten z:EN 14469-2:2004SIST EN 14469-2:2004en01-september-2004SIST EN 14469-2:2004SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 14469-2April 2004ICS 83.040.30English versionPigments and extenders - Testing of colouring materials inplasticized polyvinyl chloride (PVC-P) - Part 2: Preparation oftest specimensPigments et matières de charge - Essai des matièrescolorantes dans le chlorure de polyvinyle plastifié (PVC-P) -Partie 2: Préparation des éprouvettesPigmente und Füllstoffe - Prüfung von Farbmitteln inweichmacherhaltigem Polyvinylchlorid (PVC-P) - Teil 2:Herstellen der ProbenkörperThis European Standard was approved by CEN on 2 February 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 14469-2:2004: ESIST EN 14469-2:2004

inplasticized polyvinyl chloride (PVC-P) materials. It describes the manner in which basic mixtures as defined inEN 14469-1 and pigments and pigment preparations are to be used to prepare test samples for the testing ofparticular pigment properties. The standard is applicable to inorganic and organic pigments, and also to pigmentpreparations in powder, paste or granular form (see annex A (informative)).2 Normative referencesThis European Standard incorporates by dated or undated reference, provisions from other publications. Thesenormative references are cited at the appropriate places in the text, and the publications are listed hereafter. Fordated references, subsequent amendments to or revisions of any of these publications apply to this EuropeanStandard only when incorporated in it by amendment or revision. For undated references the latest edition of thepublication referred to applies (including amendments).EN ISO 15528, Paints, varnishes and raw materials for paints and varnishes - Sampling (ISO 15528:2000).3 Apparatus3.1 Mixing vessel3.2 Two-roll millwhich can be heated, with rolls whose separation can be adjusted, roll diameters shall be between 80 mm and200 mm, ratio of the speeds of rotation of the two rollers shall be between 1:1,1 and 1:1,2.NOTEThe rolls used should preferably have a chromed surface.3.3 Plate press (if required according to 5.3)which can be heated and coole
...
