EN 50382-1:2008/A1:2013

(Amendment)

Railway applications - Railway rolling stock high temperature power cables having special fire performance - Part 1: General requirements

Railway applications - Railway rolling stock high temperature power cables having special fire performance - Part 1: General requirements

2013-03-25 - Publication editing allocated to cpalagi@cencenelec.eu
2021: CLC legacy converted by DCLab NISOSTS

Bahnanwendungen - Hochtemperaturkabel und -leitungen für Schienenfahrzeuge mit verbessertem Verhalten im Brandfall - Teil 1: Allgemeine Anforderungen

Applications ferroviaires - Câbles pour matériel roulant ferroviaire ayant des performances particulières de comportement au feu - Partie 1: Prescriptions générales

Železniške naprave - Visokotemperaturni močnostni kabli za železniška vozna sredstva, ki imajo posebne požarne lastnosti - 1. del: Splošne zahteve

Ta 1. del standarda EN 50382 določa splošne zahteve, ki se uporabljajo za kable, navedene v standardu EN 50382-2. Vključuje podrobne zahteve za izolacijske in oklopne materiale ter druge komponente, omenjene v standardu EN 50382-2. Standard EN 50382-1 zlasti določa tiste zahteve, ki so v povezavi s požarno varnostjo. Na podlagi dokazanih dolgoletnih izkušenj in zanesljivosti se te kable ocenjuje pri občasnih toplotnih obremenitvah, ki povzročajo staranje, enakovredno neprekinjenemu delovanju pri temperaturi vodnika 120 °C ali 150 °C. Največja temperatura za kratkostične pogoje za silikonsko gumo je 350 °C pri trajanju 5 sekund. Čeprav so obe izolacijski in ena oklopna spojina, ki so določene v tem standardu, zmožne delovati pri temperaturi 150 °C, je tam, kjer so uporabljeni pokositreni vodniki, največja obratovalna temperatura omejena na 120 °C in iz enakega tehničnega razloga je največja kratkostična temperatura za pokositrene bakrene vodnike omejena na 250 °C. Tudi izbira oklepa lahko omeji obratovalno temperaturo na 120 °C. Ta 1. del se mora uporabljati skupaj s standardom EN 50382-2.

General Information

Status
Published
Publication Date
06-Jun-2013
Withdrawal Date
28-Apr-2016
ICS
13.220.40 - Ignitability and burning behaviour of materials and products
29.060.20 - Cables
45.060.01 - Railway rolling stock in general
Technical Committee
CLC/TC 20 - Electric cables
Drafting Committee
CLC/TC 20 - Electric cables
Current Stage
6060 - Document made available - Publishing
Start Date
07-Jun-2013
Completion Date
07-Jun-2013
Ref Project
SIST EN 50382-1:2008/A1:2013 - Railway applications - Railway rolling stock high temperature power cables having special fire performance - Part 1: General requirements

Relations

Amends
EN 50382-1:2008 - Railway applications - Railway rolling stock high temperature power cables having special fire performance - Part 1: General requirements
Effective Date
28-Jan-2023

Buy Standard

EN 50382-1:2008/A1:2013EN 50382-1:2008/A1:2013
PreviousNext
Amendment
EN 50382-1:2008/A1:2013
English language
3 pages
