EN 60255-149:2013 (IEC 60255-149:2013) defines functional requirements for thermal electrical relays - a class of measuring relays and protection equipment that prevent thermal damage by monitoring AC current and related temperature inputs. The standard establishes minimum requirements for the protection function, measurement characteristics and reproducible test methodologies for dependent time (thermal) relays based on a first-order thermal model with memory function.

Key topics and technical requirements

• Protection function and inputs
  • Specification of energizing quantities: a.c. current through equipment and complementary inputs such as ambient, coolant, top-oil and winding temperature.
  • Support for binary input signals and logic required to calculate thermal level.
• Thermal modelling and calculation
  • Use of a first-order thermal model to derive an equivalent heating current and thermal level with memory of prior loading (hot and cold states).
  • Definition of basic (setting) and operating current values and time–current limit characteristic equations (cold and hot curves).
• Outputs and behaviour
  • Binary outputs: operate (trip), alarm and other status signals.
  • Requirements for behaviour during auxiliary-power loss and facilities for thermal reset.
• Performance and accuracy
  • Accuracy of operate current and operate time, plus limits for steady-state errors.
  • Performance under frequency variations, harmonic distortion, and different ambient temperatures.
• Functional test methodology
  • Type testing procedures for cold and hot curves, harmonics, frequency variation tests, cooling time-constant evaluation and test point tables for repeatable verification.
• Documentation
  • Type test reports and user documentation requirements; informative annexes explain the first-order thermal model and temperature-setting approaches.

Applications and users

• Intended for manufacturers, test laboratories, design engineers and utilities involved in:
  • Protection of motors, transformers and rotating machinery against thermal overload.
  • Development and certification of thermal protection relays and relay firmware that implement thermal models and time–current characteristics.
  • Procurement and acceptance testing of protection relays used in power-generation, industrial and utility installations.
• Useful for system integrators implementing relay logic including digital communication interfaces (see related IEC standards).

Related standards

• IEC 60255-1 (measuring relays - common requirements)
• IEC 60085 (thermal evaluation of electrical insulation)
• IEC 61850 family (power utility automation data models and communications)
• IEC 60034-11, IEC 60947 series (referenced in the EN/IEC bibliographic notes)

EN 60255-149:2013 provides a consistent, testable framework for specifying and verifying thermal protection relays, promoting interoperability and repeatable protection performance across manufacturers and users.
