Radio-frequency connectors - Part 70: Sectional specification for series HD-BNC radio-frequency coaxial connectors - Characteristic Impedance 75 Ω

IEC 61169-70:2024, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) of HD-BNC series RF coaxial connectors together with the pro forma blank detail specification. HD-BNC series connectors with characteristic impedance of 75 Ω are used with RF cables or micro-strips in microwave, telecommunication, wireless and other fields. The operating frequency limit is up to 18 GHz. It also prescribes mating face dimensions for general purpose connectors, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series HD-BNC RF connectors. This specification indicates the recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.

Hochfrequenz-Steckverbinder - Teil 70: Rahmenspezifikation für Hochfrequenz-Koaxialsteckverbinder der Serie HD-BNC - Wellenwiderstand 75 Ohm

Connecteurs pour fréquences radioélectriques - Partie 70 : Spécification intermédiaire pour les connecteurs coaxiaux pour fréquences radioélectriques de la série HD-BNC - Impédance caractéristique de 75 Ω

L’IEC 61169-70:2024, qui est une spécification intermédiaire (SI), fournit des informations et des règles relatives à la préparation des spécifications particulières (SP) pour les connecteurs coaxiaux RF de la série HD-BNC, conjointement avec la spécification particulière-cadre pro forma. Les connecteurs de la série HD-BNC de 75 Ω d’impédance caractéristique sont utilisés avec des câbles RF ou des microrubans dans les domaines des hyperfréquences, des télécommunications, des applications sans fil et d’autres domaines. La limite de fréquence de fonctionnement s’étend jusqu’à 18 GHz. Elle spécifie également les dimensions des faces d’accouplement pour les connecteurs d’usage général, ainsi que des informations concernant les calibres et les essais choisis dans l’IEC 61169-1, applicables à toutes les spécifications particulières ayant trait aux connecteurs RF de la série HD-BNC. La présente spécification indique les caractéristiques de performance recommandées à prendre en considération pour rédiger une spécification particulière, et elle couvre les programmes d’essais et les exigences de contrôle pour les niveaux d’assurance qualité M et H.

Radiofrekvenčni konektorji - 70. del: Področna specifikacija za radiofrekvenčne koaksialne konektorje serije HD-BNC - Karakteristična impedanca 75 ohmov (IEC 61169-70:2024)

Standard IEC 61169-70:2024, ki je področna specifikacija (SS), podaja informacije in določa pravila za pripravo podrobnih specifikacij (DS) za radiofrekvenčne (RF) koaksialne konektorje serije HD-BNC skupaj s pro forma okvirno podrobno specifikacijo. Konektorji serije HD-BNC s karakteristično impendanco 75 Ω se uporabljajo z radiofrekvenčnimi kabli ali mikrotrakovi pri mikrovalovanju, telekomunikacijah, v brezžičnih omrežjih in na drugih področjih. Omejitev frekvenčnega območja delovanja je največ 18 GHz.
Standard opisuje tudi prednje mere stikanja za konektorje za splošni namen, informacije o merjenju in preskuse, izbrane iz standarda IEC 61169-1, ki se uporabljajo za vse podrobne specifikacije v zvezi z radiofrekvenčnimi konektorji serije HD-BNC.
Ta specifikacija navaja priporočene lastnosti, ki jih je treba upoštevati pri sestavljanju podrobne specifikacije, ter zajema razporede preskusov in zahteve za pregled za ravni vrednotenja M in H.
