EN 60534-6-1:1997

Industrial-process control valves - Part 6: Mounting details for attachment of positioners to control valves - Section 1: Positioner mounting on linear actuators

Intended to permit a variety of positioning devices, which respond to a linear motion, to be mounted on the actuator of a control valve, either directly or by employing an intermediate mounting bracket. Applicable where interchangeability between actuators and positioners is desired.

Stellventile für die Prozeßregelung - Montage-Einzelheiten zur Befestigung von Stellungsreglern an Stellventil-Antriebe - Hauptabschnitt 1: Montage von Stellungsreglern an Hubantriebe

Vannes de régulation des processus industriels - Partie 6: Détails d'assemblage pour le montage des positionneurs sur les actionneurs de vannes de régulation - Section 1: Montage des positionneurs sur les actionneurs linéaires

A pour objectif de permettre à plusieurs systèmes de positionnement qui répondent à un mouvement rectiligne d'être montés sur l'actionneur d'une vanne de régulation, soit directement soit en utilisant un support de montage intermédiaire. S'applique lorsqu'on souhaite que les actionneurs et les positionneurs soient interchangeables.

Industrial-process control valves - Part 6: Mounting details for attachment of positioners to control valves - Section 1: Positioner mounting on linear actuators (IEC 60534-6-1:1997)

General Information

• Status: Published
• Publication Date: 14-Oct-1997
• Withdrawal Date: 30-Jun-1998
• ICS: 23.060.40 - Pressure regulators
• ICS: 25.040.40 - Industrial process measurement and control
• Technical Committee: CLC/TC 65X - Industrial-process measurement, control and automation
• Drafting Committee: IEC/SC 65B - IEC_SC_65B
• Parallel Committee: IEC/SC 65B - IEC_SC_65B
• Current Stage: 6060 - Document made available - Publishing
• Start Date: 15-Oct-1997
• Completion Date: 15-Oct-1997
• Ref Project: SIST EN 60534-6-1:1998 - Industrial-process control valves -- Part 6: Mounting details for attachment of positioners to control valves -- Section 1: Positioner mounting on linear actuators

Overview

EN 60534-6-1:1997 (CLC adoption of IEC 60534-6-1:1997) specifies standardized mounting details for attachment of positioners to control valves - Section 1: positioner mounting on linear actuators. The standard is intended to permit a variety of positioning devices that respond to linear motion to be mounted on actuator yokes either directly or via an intermediate mounting plate, promoting interchangeability between actuators and positioners from different manufacturers.

Key topics and technical requirements

• Scope: Applies to side-mounted positioners on actuators with travel typically from 10 mm to 100 mm and to three basic actuator yoke types:
  • cast or fabricated yoke,
  • central tube yoke,
  • column/pillar yoke.
• Basic design principles: Ensure correct positioning relative to actuator stem and rigid mounting of the positioner. Manufacturers are encouraged to provide attachment means on both sides of the yoke to allow reversible mounting.
• Feedback connection: Standardizes a connection piece with four M6 threaded holes, each surrounded by a bearing area of at least 10 mm diameter (rotation/180° option may reduce required holes).
• Mounting plate design: Positioners may incorporate direct attachment means or be supplied with a mounting plate designed per standard figures. Material thickness and internal design are left to manufacturers, but plate geometry must ensure proper contact and rigidity.
• Actuator yoke mounting options:
  • ribs with fixing holes (rib detail specified),
  • U-bolts for pillar diameters 20–35 mm,
  • two outer fixing holes on a plane surface (M8 fastenings referenced in figures).
• Illustrative dimensions and figures define drilling, hole placements, rib profiles and U-bolt dimensions to achieve compatibility (refer to the standard figures for exact values).

Applications

• Ensures mechanical compatibility when retrofitting or replacing positioners on linear actuators in industrial-process control valves.
• Used during design and production of actuators, positioners, and mounting kits to guarantee interchangeability.
• Supports maintenance, spares management and lifecycle upgrades in oil & gas, chemical, power generation and process industries where control-valve positioners are commonly used.

Who uses this standard

• Valve and actuator manufacturers
• Positioner and instrumentation vendors
• Plant engineers, maintenance and reliability teams
• Procurement/specification engineers defining valve packages

Related standards

• Part of the IEC/EN 60534 series on industrial-process control valves (see other parts of IEC 60534 for definitions and complementary requirements).

Keywords: EN 60534-6-1:1997, positioner mounting, linear actuators, control valves, actuator yoke, mounting plate, feedback connection, interchangeability.

Standards Content (Sample)

SLOVENSKI STANDARD
01-november-1998
Industrial-process control valves - Part 6: Mounting details for attachment of
positioners to control valves - Section 1: Positioner mounting on linear actuators
(IEC 60534-6-1:1997)
Industrial-process control valves -- Part 6: Mounting details for attachment of positioners
to control valves -- Section 1: Positioner mounting on linear actuators
Stellventile für die Prozeßregelung -- Montage-Einzelheiten zur Befestigung von
Stellungsreglern an Stellventil-Antriebe -- Hauptabschnitt 1: Montage von
Stellungsreglern an Hubantriebe
Vannes de régulation des processus industriels -- Partie 6: Détails d'assemblage pour le
montage des positionneurs sur les actionneurs de vannes de régulation -- Section 1:
Montage des positionneurs sur les actionneurs linéaires
Ta slovenski standard je istoveten z: EN 60534-6-1:1997
ICS:
23.060.40 7ODþQLUHJXODWRUML Pressure regulators
25.040.40 Merjenje in krmiljenje Industrial process
industrijskih postopkov measurement and control
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

NORME
CEI
INTERNATIONALE
IEC
60534-6-1
INTERNATIONAL
Première édition
STANDARD
First edition
1997-08
Vannes de régulation des processus industriels –
Partie 6:
Détails d’assemblage pour le montage
des positionneurs sur les actionneurs
de vannes de régulation –
Section 1: Montage des positionneurs
sur les actionneurs linéaires
Industrial-process control valves –
Part 6:
Mounting details for attachment of
positioners to control valves –
Section 1: Positioner mounting on
linear actuators
 IEC 1997 Droits de reproduction réservés  Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun any form or by any means, electronic or mechanical,
procédé, électronique ou mécanique, y compris la photo- including photocopying and microfilm, without permission in
copie et les microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: [phone] e-mail: [e-mail] IEC web site http: //www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
N
PRICE CODE
International Electrotechnical Commission
Pour prix, voir catalogue en vigueur
For price, see current catalogue

60534-6-1 © IEC:1997 – 3 –
CONTENTS
Page
FOREWORD . 5
Clause
1 Scope and object . 7
2 Definitions. 7
3 Basic design principles. 7
4 Feedback connection . 9
5 Mounting plate design . 9
6 Actuator yoke mounting. 9
Figures. 11

60534-6-1 © IEC:1997 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
___________
INDUSTRIAL-PROCESS CONTROL VALVES –
Part 6: Mounting details for attachment of positioners to control valves –
Section 1: Positioner mounting on linear actuators
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60534-6-1 has been prepared by subcommittee 65B: Devices, of
IEC technical committee 65: Industrial-process measurement and control.
This standard, together with IEC 60534-6-2 when published, will cancel and replace the first
edition of IEC 60534-6 published in 1985.
The text of this standard is based on the following documents:
FDIS Report on voting
65B/311/FDIS 65B/317/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.

60534-6-1 © IEC:1997 – 7 –
INDUSTRIAL-PROCESS CONTROL VALVES –
Part 6: Mounting details for attachment of positioners to control valves –
Section 1: Positioner mounting on linear actuators
1 Scope and object
This section of IEC 60534-6 is intended to permit a variety of positioning devices, which
respond to a linear motion, to be mounted on the actuator of a control valve, either directly or
by employing an intermediate mounting bracket. This section is applicable where
interchangeability between actuators and positioners is desired.
The following parameters define the intended applicability of this section for the guidance of
manufacturers and users.
– The standardized mounting appli
...
