SLOVENSKI STANDARD
01-april-2000
Electrical accessories - Circuit-breakers and similar equipment for household use
- Auxiliary contact units (IEC 62019:1999)
Electrical accessories - Circuit-breakers and similar equipment for household use -
Auxiliary contact units
Elektrisches Installationsmaterial - Schutzschalter und ähnliche Geräte für
Hausinstallationen - Hilfsschalter
Petit appareillage électrique - Disjoncteurs et appareillage similaire pour usages
domestiques - Blocs de contacts auxiliaires
Ta slovenski standard je istoveten z: EN 62019:1999
ICS:
29.120.50 9DURYDONHLQGUXJD Fuses and other overcurrent
PHGWRNRYQD]DãþLWD protection devices
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
NORME CEI
INTERNATIONALE IEC
INTERNATIONAL
Première édition
STANDARD
First edition
1999-02
Petit appareillage électrique –
Disjoncteurs et appareillage similaire
pour usages domestiques – Blocs de contacts
auxiliaires
Electrical accessories –
Circuit-breakers and similar equipment
for household use – Auxiliary contact units
IEC 1999 Droits de reproduction réservés Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun procédé, any form or by any means, electronic or mechanical,
électronique ou mécanique, y compris la photo-copie et les including photocopying and microfilm, without permission in
microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http://www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
V
PRICE CODE
International Electrotechnical Commission
Pour prix, voir catalogue en vigueur
For price, see current catalogue
62019 © IEC:1999 – 3 –
CONTENTS
Page
FOREWORD . 5
Clause
1 Scope and object . 7
2 Normative references.7
3 Definitions.9
4 Classification.11
5 Characteristics.11
5.1 Type of auxiliary contact unit . 11
5.2 Rated values of auxiliary contacts . 13
5.3 Performance under normal and abnormal load conditions . 13
5.4 Utilization categories of auxiliary contacts. 15
5.5 Electrically separated contact elements . 15
6 Marking and other information . 15
6.1 Marking.15
6.2 Terminal identification.17
6.3 Instructions for installation and operation. 17
7 Standard conditions for operation in service. 17
8 Requirements for construction and operation . 17
8.1 Constructional requirements.17
8.2 Performance requirements.23
8.3 Test device of the auxiliary contact unit . 23
8.4 Correct operation of the main switching device . 25
8.5 Electromagnetic compatibility.25
9 Tests.25
9.1 Kinds of test. 25
9.2 Verification of compliance with constructional requirements . 25
9.3 Performance.27
9.4 Tests of creepage distances and clearances for electronic circuits. 35
9.5 Requirements for capacitors and specific resistors and inductors used in
electronic circuits . 39
Annex A (normative) Determination of clearances and creepage distances. 53
Annex B (informative) Contact rating based on utilization categories . 59
Annex C (informative) Example of inductive loads for tests of d.c. contacts . 61
Annex D (informative) Bibliography . 67
Figures. 43
Table 1 – Utilization categories for auxiliary contacts . 15
Table 2 – Clearances and creepage distances . 21
Table 3 – Additional test sequences for auxiliary contact units already fully tested together
with one kind of main switching device. 27
Table 4 – Verification of making and breaking capacities of auxiliary contact
units under normal conditions corresponding to the utilization categories. 31
Table 5 – Verification of making and breaking capacities of auxiliary contact units
under abnormal conditions corresponding to the utilization categories . 33
Table 6 – Maximum permissible temperatures under abnormal conditions . 41
62019 © IEC:1999 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
ELECTRICAL ACCESSORIES –
CIRCUIT-BREAKERS AND SIMILAR EQUIPMENT
FOR HOUSEHOLD USE –
AUXILIARY CONTACT UNITS
FOREWORD
1) The IEC (International Electrotechnical Commission) is a world-wide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 62019 has been prepared by subcommittee 23E: Circuit-breakers
and similar equipment for household use, of IEC technical committee 23: Electrical accessories.
The text of this standard is based on the following documents:
FDIS Report on voting
23E/363/FDIS 23E/366/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
Annex A forms an integral part of this standard.
Annexes B, C and D are for information only.
62019 © IEC:1999 – 7 –
ELECTRICAL ACCESSORIES –
CIRCUIT-BREAKERS AND SIMILAR EQUIPMENT
FOR HOUSEHOLD USE –
AUXILIARY CONTACT UNITS
1 Scope and object
This International Standard applies to auxiliary contact units associated (or intended to be
associated) with circuit-breakers for overcurrent protection, and with residual current operated
circuit-breakers with or without integral overcurrent protection for household and similar
installations, having a rated voltage not exceeding 440 V a.c. and 250 V d.c., and a rated
current not exceeding 10 A.
NOTE 1 – These requirements may also be used as guidance for auxiliary contacts units intended to be assembled
with other switching devices for household and similar installations.
NOTE 2 – It is recommended that the advice of the manufacturer be sought concerning any application with low
level energy appliances (low level values of current and/or voltage.) For low-energy contacts, specific
recommendations are given in IEC 60947-5-4.
The object of this standard is to state
a) the characteristics of the auxiliary contact units;
b) their electrical and mechanical requirements with respect to
1) the various duties to be performed;
2) the significance of the rated characteristics and of the markings;
3) the tests to verify the rated characteristics;
c) the functional requirements to be satisfied by the auxiliary contact units with respect to
1) environmental conditions, including those of enclosed equipment;
2) dielectric properties;
3) terminals;
4) safety of use.
2 Normative references
The following normative documents contain provisions which, through reference in this text,
constitute provisions of this International Standard. For dated references, subsequent
amendments to, or revisions of, any of these publications do not apply. However, parties to
agreements based on this International Standard are encouraged to investigate the possibility
of applying the most recent editions of the normative documents indicated below. For undated
references, the latest edition of the normative document referred to applies. Members of IEC
and ISO maintain registers of currently valid International Standards.
IEC 60050(441):1984, International Electrotechnical Vocabulary (IEV) – Chapter 441: Switchgear,
controlgear and fuses
62019 © IEC:1999 – 9 –
IEC 60065:1998, Audio, video and similar apparatus – Safety requirements
IEC 60249-2 (all specifications), Base materials for printed circuits – Part 2: Specifications
IEC 60384-14:1993, Fixed capacitors for uses in electronic equipment – Part 14. Sectional
specification: Fixed capacitors for electromagnetic interference suppression and connection to
the supply mains
IEC 60617 (all parts), Graphical symbols for diagrams
IEC 60664-3:1992, Insulation coordination for equipment within low-voltage systems – Part 3:
Use of coating to achieve insulation coordination of printed board assemblies
IEC 60898:1995, Electrical accessories – Circuit-breakers for overcurrent protection for
household and similar installations
IEC 60998-2-2:1991, Connecting devices for low voltage circuits for household and similar
purposes – Part 2-2: Particular requirements for connecting devices as separate entities with
screwless-type clamping units
IEC 60947-5-1:1997, Low-voltage switchgear and controlgear – Part 5: Control circuit devices
and switching elements – Section one: Electromechanical control circuit devices
IEC 60947-5-4:1996, Low-voltage switchgear and controlgear – Part 5: Control circuit devices
and switching elements – Section 4: Methods of assessing the performance of low-energy
contacts. Special tests
IEC 61008-1:1996, Residual current operated circuit-breakers without integral overcurrent
protection for household and similar uses (RCCBs) – Part 1: General rules
IEC 61009-1:1996, Residual current operated circuit-breakers with integral overcurrent
protection for household and similar uses (RCBOs) – Part 1: General rules
IEC 61210:1993, Connecting devices – Flat quick-connect terminations for electrical copper
conductors – Safety requirements
ISO 306:1994, Plastics – Thermoplastic materials – Determination of Vicat softening temperature
(VST)
3 Definitions
For the purpose of this International Standard, the following definitions apply.
3.1
auxiliary contact
contact included in an auxiliary circuit and mechanically operated by the switching device
[IEV 441-15-10]
62019 © IEC:1999 – 11 –
3.2
auxiliary contact unit
unit containing one or more control and/or auxiliary contacts mechanically operated by a main
switching device
NOTE – The main switching device may be a circuit-breaker, RCCB, RCBO, switch, etc.
3.3
contact element (of an auxiliary contact)
structural part, fixed and movable, conducting or insulating, of an auxiliary contact necessary to
close and open one single conducting path of the auxil
...
