IEC 60317-13:2010
(Main)Specifications for particular types of winding wires - Part 13: Polyester or polyesterimide overcoated with polyamide-imide enamelled round copper wire, class 200
Specifications for particular types of winding wires - Part 13: Polyester or polyesterimide overcoated with polyamide-imide enamelled round copper wire, class 200
IEC 60317-13:2010 specifies the requirements of enamelled round copper winding wire of class 200 with a dual coating. The underlying coating is based on polyester or polyesterimide resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. The superimposed coating is based on polyamide-imide resin. The main changes with respect to the previous edition are:
- new requirements for appearance;
- reference to new resistance to refrigerants test in IEC 60851-4;
- deletion of high temperature failure requirement;
- new pin hole test requirements.
This publication is to be read in conjunction with IEC 60317-0-1:2008.
Spécifications pour types particuliers de fils de bobinage - Partie 13: Fil de section circulaire en cuivre émaillé avec polyester ou polyesterimide et avec surcouche polyamide-imide, classe 200
La CEI 60317-13:2010 concerne les fils de bobinage de section circulaire en cuivre émaillé de classe 200 avec un double revêtement. La sous-couche est à base de résine polyester ou polyesterimide, qui peut être modifiée à condition qu'elle conserve l'identité chimique de la résine initiale et réponde à toutes les exigences du fil. La surcouche est à base de résine polyamide-imide. Les modifications principales par rapport à l'édition précédente sont:
- nouvelles exigences concernant l'aspect;
- référence à l'essai de la résistance aux réfrigérants de la CEI 60851-4;
- suppresion des exigences concernant la défaillance à haute température;
- nouvelles exigences concernant la détection des microfissures en immersion.
Cette publication doit être lue conjointement avec la CEI 60317-0-1:2008.
