IEC 60809:2021

Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements

IEC 60809:2021 is applicable to electric light sources for use in automotive applications, for example in road illumination devices and/or light signalling devices for road vehicles.
It is especially applicable to light sources listed in UN Resolution R.E.5 and light sources subject to other legislations.
This fourth edition cancels and replaces the third edition published in 2014, Amendment 1:2017, Amendment 2:2017 and Amendment 3:2019. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) Introduction of a light technical measurement on LED light sources intended for use in front-lighting applications.
b) As the original data sheets and some figures from previous editions were not available in an editable format, they have been reproduced from their old format, following the current drafting rules and are now in single language format. Some reproductions constitute minor (obvious) editorial changes of the original text sections and original figures; no technical changes were introduced.

Lampes et sources lumineuses pour véhicules routiers - Exigences dimensionnelles, électriques et lumineuses

L'IEC 60809:2021 est applicable aux sources lumineuses électriques (voir Note 1) destinées à être utilisées dans les applications automobiles, par exemple dans les dispositifs d'éclairage de la route et/ou les appareils de signalisation pour véhicules routiers.
Il s'applique en particulier aux sources lumineuses répertoriées dans la Résolution R.E.5 de l'ONU et aux sources lumineuses qui font l'objet d'autres législations.
Cette quatrième édition annule et remplace la troisième édition parue en 2014, l'Amendement 1:2017, l'Amendement 2:2017 et l'Amendement 3:2019. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
introduction d'une mesure technique de la lumière sur les sources lumineuses à LED destinées à être utilisées dans les applications d'éclairage avant;
du fait que les feuilles de caractéristiques d'origine et certaines figures issues des éditions précédentes n'étaient pas disponibles sous un format éditable, elles ont été reproduites à partir de leur ancien format, conformément aux règles de rédaction en vigueur, mais à présent sous un format unilingue. Certaines reproductions présentent des modifications rédactionnelles mineures (évidentes) des sections de texte et des figures d'origine; aucune modification technique n'a été apportée.
La présente version bilingue (2021-10) correspond à la version anglaise monolingue publiée en 2021-04.
La version française de cette norme n'a pas été soumise au vote.
La langue employée pour l'élaboration de cette Norme internationale est l'anglais.

General Information

• Status: Published
• Publication Date: 07-Nov-2023
• ICS: 29.140.20 - Incandescent lamps
• ICS: 43.040.20 - Lighting, signalling and warning devices
• Technical Committee: SC 34A - Electric light sources
• Current Stage: PPUB - Publication issued
• Start Date: 30-Apr-2021
• Completion Date: 07-Apr-2021

Relations

• Amended By: IEC 60809:2021/AMD1:2023 - Amendment 1 - Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023
• Revises: IEC 60809:2014/AMD3:2019 - Amendment 3 - Lamps for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023
• Revises: IEC 60809:2014/AMD1:2017 - Amendment 1 - Lamps for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023
• Revises: IEC 60809:2014 - Lamps for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023
• Revises: IEC 60809:2014/AMD1:2017/ISH1:2017 - Interpretation sheet 1 - Lamps for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023
• Revises: IEC 60809:2014/AMD2:2017 - Amendment 2 - Lamps for road vehicles - Dimensional, electrical and luminous requirements
• Effective Date: 05-Sep-2023

Overview

IEC 60809:2021 - Edition 4.0 - is the International Electrotechnical Commission standard for lamps and light sources for road vehicles, defining dimensional, electrical and luminous requirements for electric light sources used in vehicle road illumination and signalling devices. The 2021 fourth edition replaces the 2014 edition and subsequent amendments and represents a technical revision. It is especially applicable to light sources listed in UN Regulation R.E.5 and other vehicle lighting legislation.

This edition introduces a new light-technical measurement for LED light sources intended for front-lighting and reproduces legacy data sheets in a single-language format to align with current drafting rules.

Key Topics and Requirements

The standard structures requirements and test conditions for different lamp technologies and includes:

• Definitions and scope covering electric light sources for automotive applications.
• Filament lamps: dimensional, marking, colour, bulb shape, caps/bases, electrical and photometric tests (includes sections for 6 V, 12 V and 24 V filament lamps).
• Discharge lamps: electrode and arc position, starting/run-up/hot-restrike behaviour, electrical and photometric characteristics.
• LED light sources: general requirements, marking, optical surfaces, colour of light, electrical and photometrical tests, and the new light-technical measurement methods (front-lighting).
• Sampling, compliance and lamp data sheets: standardized data sheets and conformity assessment.
• Normative annexes with measurement and test methods for internal elements, filament geometry, colour measurement and test conditions.

The document also addresses UV radiation, non-replaceable lamps, vibration/shock resistance and standard (étalon) reference lamps/light sources.

Applications

IEC 60809:2021 is intended for practical use in:

• Design and development of vehicle headlamps, fog lamps, tail lamps and signalling devices.
• Laboratory testing and type approval of replacement bulbs and integrated LED modules.
• Homologation and regulatory compliance where UN R.E.5 or national vehicle lighting rules reference IEC requirements.
• QA/production testing for automotive lighting suppliers and component manufacturers.

Who Uses This Standard

• Automotive OEMs and lighting system engineers
• Lamp and LED module manufacturers
• Test and certification laboratories
• Regulatory bodies and homologation authorities
• Aftermarket bulb manufacturers and suppliers

Related Standards

• UN Regulation R.E.5 (light sources referenced in the scope)
• Other IEC and vehicle lighting regulations referenced within test and measurement procedures (see the standard’s normative references for details).

Keywords: IEC 60809, road vehicle lamps, automotive light sources, LED light sources, filament lamps, discharge lamps, dimensional requirements, electrical requirements, luminous requirements, UN R.E.5, vehicle lighting compliance.
