IEC TR 60068-3-82:2024

Environmental testing - Part 3-82: Supporting documentation and guidance - Confirmation of the performance of whisker test method

IEC TR 60068-3-82:2024, which is a Technical Report, provides technical background information on the whisker test methods from IEC 60068-2-82 and guidance on test selection.

General Information

• Status: Published
• Publication Date: 14-Aug-2024
• ICS: 19.040 - Environmental testing
• Technical Committee: TC 91 - Electronics assembly technology
• Drafting Committee: WG 3 - TC 91/WG 3
• Current Stage: PPUB - Publication issued
• Start Date: 15-Aug-2024
• Completion Date: 23-Aug-2024

Overview

IEC TR 60068-3-82:2024 is a Technical Report that provides technical background and practical guidance for confirming the performance of the whisker test method referenced in IEC 60068-2-82. It focuses on tin (Sn) whisker phenomena in electronic components and surface finishes, explains underlying growth mechanisms, and gives guidance on selecting and performing appropriate whisker testing and whisker inspection methods as part of environmental testing and reliability assessment.

Key topics and technical guidance

The report covers the following key technical areas and requirements:

• Whisker growth mechanisms

  • Detailed discussion of Sn whiskers, intermetallic compound (IMC) formation, corrosion effects, and the impact of grain structure and surface finish (bright vs. matte Sn).
  • Effects of coefficient of thermal expansion (CTE) mismatch and temperature cycling on whisker initiation and growth.
  • Process- and design-related factors that influence whisker risk (plating, diffusion barriers, flux residues, mechanical stress, press-fit and bending operations).

• Whisker testing guidance

  • Preconditioning recommendations for different application scenarios (press-fit, mechanical loading, soldering/welding).
  • Environmental test types relevant to whisker formation: ambient storage, damp heat, temperature cycling, and application-specific ambient tests for press-fit connections.
  • Considerations on test severity and combining environmental stresses for realistic assessment.

• Inspection and measurement requirements

  • Comparison and guidance on detection methods including light optical inspection and scanning electron microscopy (SEM).
  • Verification of inspection methodology: detection capability, length and density measurement capability, and overall criteria for reliable whisker quantification.
  • Guidance on technological similarity when extrapolating test results between related materials or component designs.

Practical applications - who uses this standard

IEC TR 60068-3-82 is aimed at professionals responsible for electronic reliability and compliance, including:

• Reliability and test engineers assessing tin whisker risk on components and assemblies
• PCB and connector designers evaluating surface finish and press-fit interactions
• Component manufacturers and contract manufacturers validating plating and process controls
• Independent test laboratories performing environmental and whisker testing
• Procurement and quality assurance teams setting acceptance criteria for assemblies in automotive, aerospace, medical, and industrial electronics

Related standards

• IEC 60068-2-82 - Whisker test methods (main test procedures referenced by this TR)
• IEC 60068 series - Environmental testing standards and guidance for broader context

IEC TR 60068-3-82:2024 is a practical resource for understanding tin whisker mechanisms, selecting appropriate environmental tests, and implementing robust inspection methods to manage whisker-related reliability risks.
