TECHNICAL REPORT ISO/TR 9241-393:2020(E)
Ergonomics of human-system interaction —
Part 393:
Structured literature review of visually induced motion
sickness during watching electronic images
1 Scope
This document gives the scientific summaries of visually induced motion sickness resulting from
images presented visually on or by electronic display devices. Electronic displays include flat panel
displays, electronic projections on a flat screen, and head-mounted displays.
Different aspects of human-system interaction are covered in other parts of the ISO 9241 series (see
Annex A).
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
visually induced motion sickness
VIMS
motion sickness-like symptoms induced by perceived motion within the visual environment, such as
when watching movies and screen images of video games
Note 1 to entry: The symptoms may include dizziness (3.2), vertigo (3.3), sweating, odd feelings in the stomach,
and nausea which can progress to vomiting.
3.2
dizziness
physical unsteadiness, lack of balance or light-headedness
3.3
vertigo
sensation of rotation or movement of oneself (subjective vertigo), or of rotation or movement of one’s
surroundings (objective vertigo), in any plane, caused by diseases of the inner ear, or by disturbances of
the vestibular centres or pathways in the central nervous system
3.4
postural ataxia
inability to coordinate voluntary movements for maintaining posture, caused by dysfunction to sensory
nerve inputs, motor nerve outputs, or the processing of them
© ISO 2020 – All rights reserved 1
---------------------- Page: 7 ----------------------
ISO/TR 9241-393:2020(E)
3.5
disorientation
loss of sense of direction, position or relationship with the surroundings
3.6
global image motion
wide spatial range of visual motion composed of different velocities and directions that are
systematically aligned in a moving image
Note 1 to entry: There are generally six types of global image motion that correspond to the different types of
motion of a camera during the shooting of images. These are rotation around and translation along the pitch,
yaw, and roll axes (see Figure 1).
Key
1 yaw
2 pitch
3 roll
Figure 1 — Rotations around and translation along the three axes
3.7
vection
self-motion perception induced by visual motion
Note 1 to entry: Vection can be categorized into two different types: linear vection and circular vection. Liner
vection consists of linear self-motion perception, while circular vection consists of circular self-motion perception
around either one or several of the yaw, pitch, and roll axes.
3.8
design field of view
design FOV
angular region subtending the active area of a display as designed to be observed from the viewing
position
4 Theories of visually induced motion sickness
Although the specific mechanism of VIMS has not been clarified, there are several hypotheses to explain
the cause of motion sickness (MS) including VIMS. Major hypotheses of MS are:
1) sensory conflict theory, or sensory rearrangement theory;
2) poison theory; and
3) postural instability theory.
The sensory conflict theory (Reason and Brand, 1975) explains the cause of MS as the mismatch among
different types of sensory information, and even within single modalities of this information, such as
visual, vestibular, proprioceptive, etc.
2 © ISO 2020 – All rights reserved
---------------------- Page: 8 ----------------------
ISO/TR 9241-393:2020(E)
The sensory rearrangement theory suggests that sickness occurs when the pattern of sensory
information containing signals from multi-modal senses and those within a single modal sense do not
match the patterns of those stored in the central nervous system, or CNS, from past experiences. As a
modified version of this sensory rearrangement theory, the theory that focuses on sensory mismatch
of the subjective vertical is known as subjective vertical theory. The sensory rearrangement theory
holds that the severity of sickness increases when the discrepancy between the pattern of sensory
information signals and those stored in CNS becomes larger. When we consider and clarify the meaning
of “mismatch” among different senses, it leads to the sensory rearrangement theory, which is widely
accepted among researchers. In general, the sensory rearrangement theory is often referred to as
sensory conflict theory.
The poison theory (Treisman, 1977) is used to explain why MS arises. The idea is that MS was developed
collaterally for organisms to survive in the course of evolution. According to the theory, when emesis
was established as a reaction to intoxication by poison, organisms developed a process in which
dizziness and vertigo, and then postural instability, is induced while the gastrointestinal tract is being
emptied by producing mismatch signals among the visual, vestibular, and proprioceptive modalities.
Because of this process, emesis is induced without the ingestion of poison by actual mismatch between
the different types of sensory information. This theory is interesting but difficult to examine and it
generally does not contradict other theories trying to explain the mechanism of VIMS.
The postural instability theory (Riccio and Stoffregen, 1991) explains the cause of MS as the state of
postural instability. Organisms try to keep postural stability in accordance with their environment in
daily activities. The stable state can be obtained by reduce body fluctuations to the smallest, while
remaining fluctuations cannot be fully controlled. According to the theory, sickness occurs when a
stable state cannot be obtained. Moreover, the severity of sickness can be determined by the time the
body remains in the unstable state. There are various discussions, both from positive and negative
sides, on this theory.
5 Measurement of visually induced motion sickness
Measurement methods of VIMS can be mainly categorized as subjective measures of symptoms or
physiological recordings including those of autonomic nervous activities. Subjective measures can be
basically classified into two categories:
1) evaluation of sickness severity with one axis scale; and
2) evaluations of various symptoms related to the sickness, which are then used to obtain a total score
and several sub-scores.
The measurements required to evaluate one value of sickness severity can be obtained in a short time.
Then, those measurements can be carried out while participants are exposed to stimuli of VIMS during
experiments. These kinds of measurements were proposed by various researchers who used different
scales. Thus, it is rather difficult to directly compare the data obtained in different experiments by
different researchers. The scales can be different in light of:
a) the number of points of the scale,
b) the level of severity indicated by the largest score, and
c) the kind of symptom levels attributed to each score of the scale.
The number of points on the scale is inconsistent: some of them have 20, and others have 11, 7, 6,
and 4. Keshavarz and Hecht (2011a) proposed a fast motion sickness scale (FMS), which is a 20-point
rating scale ranging from zero (no sickness at all) to 20 (frank sickness). They examined and found
high correlations with the simulator sickness questionnaire (SSQ), total score (r = 0,79) and sub-score
(r = 0,83). They also used it in another experiment (Keshavarz and Hecht, 2011b).
There are two different, but comparable, scales adopting 11-point levels of scoring. One is called the
misery scale (MISC), which has been used by Bos and his colleagues (Bos et al., 2005; Lubeck et al.,
2015; Lubeck et al., 2016). The scale was revised from the one adopted by Wertheim et al. (1998), based
© ISO 2020 – All rights reserved 3
---------------------- Page: 9 ----------------------
ISO/TR 9241-393:2020(E)
on “the knowledge that nausea is generally preceded by other symptoms such as dizziness, headache,
(cold) sweat, and stomach awareness” (Bos et al., 2005). The MISC with symptom description for each
score is shown in Table 1. The other is the sickness related scale, focusing on the symptoms felt in the
head, and of dizziness and nausea (Ujike et al., 2004; Ujike et al., 2005). The scale is presented in Table 2.
Table 1 — Misery scale (MISC)
Symptom Severity Score
No problems 0
Uneasiness (no typical symptoms) 1
Dizziness, warmth, headache, stomach awareness, sweating, and vague 2
other symptoms slight 3
fairly 4
severe 5
Nausea slight 6
fairly 7
severe 8
Retching 9
Vomiting 10
Table 2 — Sickness related scale
Symptom description Rating
No problems 0
Feeling very slight unusual sensation 1
Feeling slight unusual sensation 2
Tendency to feel unusual sense in the head 3
Sometimes feeling unusual sense in the head 4
Feeling unusual sense in the head 5
Tendency to feel sick and dizziness 6
Feeling slight sick and dizziness 7
Feeling sick and dizziness 8
Feeling very sick and dizziness 9
Cannot see visual motion, or feel vomiting 10
A 7-point scale is used in several reports (Webb and Griffin, 2002; Webb and Griffin, 2003; Lo and So,
2001; So et al., 2001; Ji et al., 2009), and attributes symptom levels to each score as:
— 0 = no symptoms;
— 1 = any unpleasant symptom, however slight;
— 2 = mild unpleasant symptom;
— 3 = mild nausea;
— 4 = mild to moderate nausea;
— 5 = moderate nausea, but can continue;
— 6 = moderate nausea, want to stop.
4 © ISO 2020 – All rights reserved
---------------------- Page: 10 ----------------------
ISO/TR 9241-393:2020(E)
A 6-point scale is used by other researchers (Bijveld et al., 2008; Golding et al., 2009), of which the scale
indicates the symptoms as:
— 1 = no symptoms;
— 2 = initial symptoms, but no nausea;
— 3 = mild nausea,
— 4 = moderate nausea (stop motion);
— 5 = severe nausea;
— 6 = vomiting.
A 4-point scale was produced by Bagshaw and Stott (1985) and is used by some studies (Clemes and
Howarth, 2005; Diels and Howarth, 2011; Diels and Howarth, 2013), of which the range is:
— 1 = no symptoms;
— 2 = mild symptoms, but no nausea;
— 3 = mild nausea;
— 4 = moderate nausea.
Another 4-point scale, which simply indicates “general discomfort”, one of the 16 items adopted in SSQ,
was used by others (Ujike et al., 2005b).
To date, several different methods have been proposed for scoring, with the evaluation of multiple
symptoms. One of these methods uses the Graybiel scale of MS (Graybiel et al., 1968). Alternative forms
of the method have been derived. The Graybiel scale has 7 categories of symptoms for evaluating MS
(see Table 3). For each of the categories, the severity of symptoms is evaluated, and then a total score is
obtained (Hu et al, 1989; Andre et al., 1996). Depending on the total score, the level of severity of MS can
be categorized as being one of five different levels.
Table 3 — Categories and levels of severity of the Graybiel scale
a
Pathognomonic Major Minor Minimal AQS
Category
16 points 8 points 4 points 2points 1 point
Vomiting or Epigastric Epigastric
c b d
Nausea syndrome Nausea II , III Nausea I
retching discomfort awareness
b c d
Skin colour Pallor III Pallor II Pallor I Flushing
b c d
Cold sweating III II I
Increased
b c d
III II I
salivation
b c d
Drowsiness III II I
Pain Headache
Dizziness:
Central nervous
c
Eyes closed ≥II
system
b
Eyes open III
Levels of severity identified by total points scored
a
Additional qualifying symptoms.
b
Severe or marked.
c
Moderate.
d
Slight.
© ISO 2020 – All rights reserved 5
---------------------- Page: 11 ----------------------
ISO/TR 9241-393:2020(E)
Table 3 (continued)
a
Pathognomonic Major Minor Minimal AQS
Category
16 points 8 points 4 points 2points 1 point
Frank Severe Moderate Moderate
Slight malaise
sickness malaise malaise A malaise B
(S) (M III) (M IIA) (M IIB) (M I)
≥16 points 8–15 points 5–7 points 3–4 points 1–2 points
a
Additional qualifying symptoms.
b
Severe or marked.
c
Moderate.
d
Slight.
Some related scoring methods exist. These methods score eight different symptoms with four levels
of severity: 0 = none, 1 = mild, 2 = moderate, 3 = severe. Some researchers adopted these eight
different symptoms as: vertigo, dizziness, bodily warmth, headache, increased salivation, stomach
awareness, nausea, and dry mouth (Bonato et al., 2005; Bonato et al., 2004; Bubka and Bonato, 2003).
Others adopted the eight symptoms as being: dizziness, bodily warmth, headache, sweating, stomach
awareness, increased salivation, nausea, and pallor that are rated by an experimenter (Golding et al.,
2009; Bijveld et al., 2008).
Another scoring system, that is widely used, is the simulator sickness questionnaire (SSQ) developed
by Kennedy et al. (1993). The SSQ has 16 items of symptoms to be eval
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
