Overview

ISO/FDIS 14505-2, titled Ergonomics of the thermal environment - Evaluation of thermal environments in vehicles - Part 2: Determination of equivalent temperature, is an international standard developed by ISO. This document provides comprehensive guidelines for assessing thermal conditions inside vehicle compartments, focusing on the determination of equivalent temperature. Its applications extend beyond vehicles into other confined spaces where asymmetric climatic conditions may exist. The methodologies set out in ISO 14505-2 are especially useful for scenarios where deviations from thermal neutrality are relatively minor. The standard also offers procedures that can be incorporated into performance standards for testing HVAC systems in vehicles and similar environments.

Key Topics

• Thermal Assessment Principles: The standard details the principles and procedures for quantifying the thermal environment using equivalent temperature, a unified metric combining convection and radiation effects on human heat exchange.
• Equivalent Temperature Types:
  • Whole body equivalent temperature: Measures overall thermal conditions affecting the body.
  • Segmental equivalent temperature: Assesses specific body segments (e.g., head, chest, limbs).
  • Directional equivalent temperature: Evaluates heat exchange in particular orientations with flat sensors.
  • Omnidirectional equivalent temperature: Uses ellipsoid sensors to measure combined directional factors.
  • Equivalent contact temperature: Focuses on heat flux between the body and contact surfaces-critical for vehicle seats.
• Instrument Guidelines: Recommends appropriate measurement devices, including thermal manikins, omnidirectional sensors, and flat heated sensors, complete with calibration and specification requirements.
• Assessment Methods: Provides step-by-step procedures for conducting local and whole-body thermal measurements, interpreting results, and ensuring repeatability and accuracy.

Applications

ISO/FDIS 14505-2 serves a wide range of professional and industrial needs, including:

• Vehicle HVAC Testing and Design: Automakers and HVAC engineers can use these guidelines to evaluate cabin thermal comfort, optimize climate control systems, and comply with regulatory requirements.
• Cabin and Confined Space Comfort Analysis: The standard’s methodology is applicable to trains, aircraft, marine vessels, and specialized work environments, ensuring occupant comfort and safety in varied conditions.
• Ergonomic Product Evaluation: Researchers and developers of seats and interior components can assess the impact of materials and designs on localized thermal comfort, especially in areas of direct skin contact.
• Regulatory Compliance and Performance Benchmarking: By following a unified approach, organizations can demonstrate compliance with health, safety, and ergonomics standards pertaining to thermal environments in transportation and industrial applications.

Related Standards

To support a holistic approach to assessing the thermal environment, the following standards are often used alongside ISO/FDIS 14505-2:

• ISO 14505-1: Ergonomics of the thermal environment - Evaluation of thermal environments in vehicles - Part 1: Principles and methods for assessment of thermal stress
• ISO 14505-3: Ergonomics of the thermal environment - Evaluation of thermal environments in vehicles - Part 3: Evaluation of thermal comfort using human subjects
• ISO 13731: Ergonomics of the thermal environment - Vocabulary and symbols
• SAE J2234: Recommended practice for measuring thermal comfort in vehicles
• ISO 7730: Ergonomics of the thermal environment - Analytical determination and interpretation of thermal comfort using calculation of the PMV and PPD indices

Practical Value

Applying ISO/FDIS 14505-2 enables organizations to:

• Ensure thermal comfort and safety for drivers and passengers
• Provide objective, repeatable data for vehicle development and certification
• Identify and mitigate local discomfort conditions, especially in asymmetric climatic scenarios
• Advance ergonomic design and occupant well-being through data-driven insights into thermal environments

By leveraging this standard, manufacturers, researchers, and regulatory bodies can achieve efficient, accurate, and user-centered evaluation of vehicle and cabin thermal conditions.
