ISO 15118-2:2014

Road vehicles - Vehicle-to-Grid Communication Interface - Part 2: Network and application protocol requirements

ISO 15118-2:2014 specifies the communication between battery electric vehicles (BEV) or plug-in hybrid electric vehicles (PHEV) and the Electric Vehicle Supply Equipment. The application layer message set defined in ISO 15118-2:2014 is designed to support the energy transfer from an EVSE to an EV. ISO 15118-1 contains additional use case elements describing the bidirectional energy transfer. The implementation of these use cases requires enhancements of the application layer message set defined herein. The purpose of ISO 15118-2:2014 is to detail the communication between an EV (BEV or a PHEV) and an EVSE. Aspects are specified to detect a vehicle in a communication network and enable an Internet Protocol (IP) based communication between EVCC and SECC. ISO 15118-2:2014 defines messages, data model, XML/EXI based data representation format, usage of V2GTP, TLS, TCP and IPv6. In addition, it describes how data link layer services can be accessed from a layer 3 perspective. The Data Link Layer and Physical Layer functionality is described in ISO 15118-3.

Véhicules routiers — Interface de communication entre véhicule et réseau électrique — Partie 2: Exigences du protocole d'application et du réseau

Le présent document spécifie la communication entre les véhicules électriques à batterie (VEB) ou les véhicules électriques hybrides rechargeables (VEHR) et l'infrastructure de recharge pour véhicules électriques. L'ensemble de messages de la couche application défini dans le présent document est conçu pour prendre en charge le transfert d'énergie entre une IRVE et un VE. L'ISO 15118-1 contient des éléments de cas d'utilisation supplémentaires (ID des éléments de cas d'utilisation de la Partie 1 : F4 et F5) décrivant le transfert d'énergie bidirectionnel. L'implémentation de ces cas d'utilisation nécessite des améliorations de l'ensemble de messages de la couche application défini dans le présent document. Les définitions de ces exigences supplémentaires feront l'objet de la prochaine révision du présent document. Le présent document a pour but de décrire de manière détaillée la communication entre un VE (VEB ou VEHR) et une IRVE. Les aspects spécifiés permettent de détecter un véhicule dans un réseau de communication, et de permettre une communication basée sur le protocole Internet (IP) entre le contrôleur de communication du véhicule électrique (EVCC) et le contrôleur de communication de l'infrastructure de recharge (SECC). Le présent document définit les messages, le modèle de données, le format de représentation de données basé sur XML/EXI, l'utilisation de V2GTP, TLS, TCP et IPv6. De plus, il décrit comment accéder aux services de la couche liaison de données à partir de la couche 3. La fonctionnalité de la couche liaison de données et de la couche physique est décrite dans l'ISO 15118-3.

General Information

• Status: Published
• Publication Date: 30-Mar-2014
• ICS: 43.120 - Electric road vehicles
• Technical Committee: ISO/TC 22/SC 31 - Data communication
• Drafting Committee: ISO/TC 22/SC 31/JWG 1 - Joint ISO/TC 22/SC 31 - IEC/TC 69 WG: Vehicle to grid communication interface (V2G CI)
• Current Stage: 9092 - International Standard to be revised
• Start Date: 21-Jan-2025
• Completion Date: 30-Oct-2025

Overview

ISO 15118-2:2014 - "Road vehicles - Vehicle-to-Grid Communication Interface - Part 2" defines the network and application protocol requirements for secure, IP-based communication between an electric vehicle (BEV or PHEV) and Electric Vehicle Supply Equipment (EVSE). The part details the application-layer message set, data model and representation (XML / EXI), the V2G Transfer Protocol (V2GTP), and use of standard Internet protocols such as IPv6, TCP and TLS to enable reliable and secure charging sessions. Physical and data link functions are covered separately in ISO 15118-3; Part 1 provides general use cases (including bidirectional energy transfer).

Key technical topics and requirements

• Application-layer message set and data model: Defines message types, sequencing, timing, error handling and complex data types to support charging sessions and identification modes (e.g., Plug & Charge).
• Data representation: XML and Efficient XML Interchange (EXI) formats for compact, interoperable message encoding.
• Network protocols: Specification of IPv6 addressing, TCP transport and the V2G Transfer Protocol (V2GTP) for EVCC–SECC communication.
• Security and certificates: Use of TLS (RFC-based, TLS 1.2 referenced), XML Signatures, X.509 certificate profiles, OCSP and related cryptographic profiles to authenticate parties, protect message integrity and support secure billing/contract verification.
• Layered architecture & data link access: Defines how layer‑3 IP services access data link layer functionality and outlines V2G communication states and timers (e.g., session setup and data-link setup).
• Normative references and compliance: Integrates multiple IETF, W3C, NIST and IEC normative references (e.g., RFCs for IPv6, TCP, TLS; EXI and XML Signature standards; IEC 61851 charging interfaces).

Practical applications and who uses this standard

ISO 15118-2 is essential for:

• EV manufacturers (OEMs) implementing EV communication controllers (EVCC) and Plug & Charge features.
• EVSE and charging-station manufacturers implementing SECC stacks and secure onboarding.
• Charging network operators and utilities integrating secure authentication, billing and energy-management functions.
• Software developers & system integrators building V2G-compliant middleware, back-end servers and certificate management systems.
• Security engineers and conformance testers validating TLS, XML signatures, certificate profiles and message sequencing. Practical uses include secure automated charging (Plug & Charge), optimized charging schedules, integration with smart grids and future vehicle-to-grid services (bidirectional charging requires extensions described in Part 1 and future revisions).

Related standards

• ISO 15118-1: General information and use-case definitions (includes bidirectional use cases)
• ISO 15118-3: Physical and data link layer requirements
• IEC 61851 and IEC 62196: Charging system and connector standards
• Relevant IETF/W3C/NIST documents (IPv6, TLS, EXI, XML Signature, X.509/OCSP)

Keywords: ISO 15118-2, vehicle-to-grid, V2G, EVSE, EVCC, SECC, Plug and Charge, V2GTP, XML/EXI, TLS, IPv6, charging session, certificate profile.
