SIST EN 12310-2:2019

Flexible sheets for waterproofing - Determination of resistance to tearing - Part 2: Plastic and rubber sheets for roof waterproofing

This document specifies a method for the determination of tear properties of plastic and rubber sheets for roof waterproofing using a trapezoidal test specimen with a nick or cut.

Abdichtungsbahnen - Bestimmung des Widerstandes gegen Weiterreißen - Teil 2: Kunststoff- und Elastomerbahnen für Dachabdichtungen

Dieses Dokument legt ein Verfahren zur Bestimmung der Weiterreißeigenschaften von Kunststoff- und Elastomerbahnen zur Dachabdichtung unter Verwendung eines trapezförmigen Probekörpers mit Kerbe oder (Ein)Schnitt fest.

Feuilles souples d’étanchéité - Détermination de la résistance à la déchirure - Partie 2 : Feuilles d’étanchéité de toiture plastiques et élastomères

La présente Norme européenne spécifie une méthode permettant de déterminer la résistance à la déchirure de feuilles d’étanchéité de toiture plastiques et élastomères à l’aide d’une éprouvette trapézoïdale entaillée.

Hidroizolacijski trakovi - Določevanje odpornosti proti nadaljnjemu trganju - 2. del: Polimerni in elastomerni trakovi za tesnjenje streh

Ta evropski standard določa metodo za določevanje lastnosti trganja polimernih in elastomernih trakov za tesnjenje streh z uporabo trapeznega preskušanca z utorom ali zarezo.

General Information

• Status: Published
• Public Enquiry End Date: 14-Nov-2017
• Publication Date: 18-Mar-2019
• ICS: 91.060.20 - Roofs
• ICS: 91.100.50 - Binders. Sealing materials
• Technical Committee: VLA - Water proofing
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 15-Jan-2019
• Due Date: 22-Mar-2019
• Completion Date: 19-Mar-2019
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Mandate: M/102 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on membranes
• Ref Project: EN 12310-2:2018 - Flexible sheets for waterproofing - Determination of resistance to tearing - Part 2: Plastic and rubber sheets for roof waterproofing

Relations

• Replaces: SIST EN 12310-2:2001 - Flexible sheets for waterproofing - Determination of resistance to tearing - Part 2: Plastic and rubber sheets for roof waterproofing
• Effective Date: 01-Apr-2019

Overview

EN 12310-2:2018 - Flexible sheets for waterproofing: Determination of resistance to tearing - Part 2: Plastic and rubber sheets for roof waterproofing - specifies a laboratory method to measure the tear resistance of plastic and rubber roof waterproofing sheets. The method uses a trapezoidal test specimen with a nick or cut and records the maximum force required to propagate the tear. This standard is intended for product characterization (as manufactured or supplied), not for in‑situ installed membrane systems.

Key Topics

• Test principle: Measure the peak force required to tear a pre‑notched trapezoidal specimen using a tensile testing machine until break.
• Specimen geometry & preparation: Templates define the trapezoidal shape and nick; five specimens are cut for each direction (longitudinal and transverse) to assess directional tear resistance.
• Conditioning: Specimens conditioned for at least 20 hours at (23 ± 2) °C and (50 ± 5) % RH prior to testing.
• Test apparatus & settings:
  • Tensile testing machine with continuous force/extension recording and uniform grip separation.
  • Loading capacity of at least 2 000 N.
  • Grip separation speed (100 ± 10) mm/min.
  • Grip width not less than 50 mm; grips must limit specimen slip to ≤1 mm for products ≤3 mm thick and ≤2 mm for thicker products.
  • Force measurement accuracy to at least Class 2 (EN ISO 7500-1).
• Results & reporting:
  • Report maximum force (N) for each specimen; compute arithmetic mean tear force for each direction (LF and TF).
  • Discard and retest if slip exceeds permitted limits.
  • Test report to reference EN 12310-2 and include sampling, specimen prep, environmental conditions, and any deviations.

Applications

• Quality control and product development for roof waterproofing membranes, including polymeric and elastomeric sheets.
• Verification of material performance for manufacturers, independent testing laboratories, and conformity assessment bodies.
• Technical specification input for architects, roof system designers, and procurement teams who need validated tear resistance data when selecting membranes.
• Supporting documentation for product datasheets and compliance evidence in tendering or certification processes.

Related standards

• EN 13956 - Definitions and characteristics for plastic and rubber sheets for waterproofing (used in conjunction with EN 12310-2).
• EN 13416:2001 - Rules for sampling (referenced for sampling procedures).
• EN ISO 7500-1:2018 - Calibration and verification of force measuring systems (referenced for force accuracy).

Keywords: EN 12310-2:2018, tear resistance, flexible sheets for waterproofing, roof waterproofing, trapezoidal test specimen, tensile testing machine, membrane testing.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Abdichtungsbahnen - Bestimmung des Widerstandes gegen Weiterreißen - Teil 2: Kunststoff- und Elastomerbahnen für DachabdichtungenFeuilles souples d’étanchéité - Détermination de la résistance à la déchirure - Partie 2 : Feuilles d’étanchéité de toiture plastiques et élastomèresFlexible sheets for waterproofing - Determination of resistance to tearing - Part 2: Plastic and rubber sheets for roof waterproofing91.100.50Veziva. Tesnilni materialiBinders. Sealing materials91.060.20StreheRoofsICS:Ta slovenski standard je istoveten z:EN 12310-2:2018SIST EN 12310-2:2019en,fr,de01-april-2019SIST EN 12310-2:2019SLOVENSKI
STANDARDSIST EN 12310-2:20011DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12310-2
December
t r s z ICS
{ sä s r rä w r Supersedes EN
s t u s ræ tã t r r rEnglish Version
Flexible sheets for waterproofing æ Determination of resistance to tearing æ Part
tã Plastic and rubber sheets for roof waterproofing Feuilles souples d 5étanchéité æ Détermination de la résistance à la déchirure æ Partie
t ã Feuilles d 5étanchéité de toiture plastiques et élastomères
Abdichtungsbahnen æ Bestimmung des Widerstandes gegen Weiterreißen æ Teil
tã Kunststoffæ und Elastomerbahnen für Dachabdichtungen This European Standard was approved by CEN on
t x October
t r s zä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Rue de la Science 23,
B-1040 Brussels
t r s z CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s t u s ræ tã t r s z ESIST EN 12310-2:2019

s and
t have been changedá the value
· 120 has been included and replaces the fix length 130mm; — Figure 3 has been replaced by a photograph showing two reference lines; — the normative references where updated. According to the CEN-CENELEC Internal Regulations, the national standards organisations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greec
...
