SIST EN 302 208-1 V1.3.1:2010
(Main)Electromagnetic compatibility and Radio spectrum Matters (ERM) - Radio Frequency Identification Equipment operating in the band 865 MHz to 868 MHz with power levels up to 2 W - Part 1: Technical requirements and methods of measurement
Electromagnetic compatibility and Radio spectrum Matters (ERM) - Radio Frequency Identification Equipment operating in the band 865 MHz to 868 MHz with power levels up to 2 W - Part 1: Technical requirements and methods of measurement
The present document covers the minimum characteristics considered necessary in order to make the best use of the available frequencies. It does not necessarily include all the characteristics that may be required by a user, nor does it necessarily represent the optimum performance achievable.
Radio frequency identification products covered within the present document are considered by definition short-range devices. Power limits up to a maximum e.r.p. of 2 W are specified for this equipment in the frequency range 865 MHz to 868 MHz. The present document applies to RFID interrogators and tags operating together as a system. The interrogators transmit
in four specified channels of 200 kHz each using a modulated carrier. The tags respond with a modulated signal preferably in the adjacent low power channels. Interrogators may be used with either integral or external antennas. ElectroMagnetic Compatibility (EMC) requirements are covered by EN 301 489-1 [i.1] and EN 301 489-3 [i.2]. The types of equipment covered by the present document are as follows:
- fixed interrogators;
- portable interrogators;
- batteryless tags;
- battery assisted tags;
- battery powered tags.
Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Oprema za radiofrekvenčno identifikacijo (RFID), ki deluje v pasu od 865 MHz do 868 MHz z močnostnimi nivoji do 2 W - 1. del: Tehnične zahteve in merilne metode
Pričujoči dokument zajema minimalne zahtevane lastnosti za najboljšo izrabo razpoložljivih frekvenc. Ni nujno, da vključuje vse značilnosti, potrebne za uporabnika, niti ni nujno, da predstavlja dosegljive optimalne zmogljivosti.
Proizvodi za radiofrekvenčno identifikacijo, zajeti v pričujočem dokumentu, se po definiciji štejejo za naprave kratkega dosega. Za to opremo so določene omejitve moči do največ e.r.p. 2 W v frekvenčen razponu od 865 MHz do 868 MHz. Pričujoči dokument velja za RFID izpraševalce in oznake, ki skupaj delujejo kot sistem. Izpraševalci oddajajo na štirih določenih 200 kHz kanalih, vsak od njih pa uporablja modulirano nosilno frekvenco. Oznake odgovorijo z moduliranim signalom, po možnosti po sosednjih kanalih nizke moči. Izpraševalci se lahko uporabijo z vgrajenimi ali zunanjimi antenami. Zahteve po elektromagnetni združljivosti (EMC) so zajete v EN 301 489-1 [i.1] in EN 301 489-3 [i.2]. Tipi opreme, ki jo pričujoči dokument zajema, so:
- stalni izpraševalci;
- prenosni izpraševalci;
- oznake brez baterij;
- oznake, ki jim pomagajo baterije;
- oznake, ki jim poganjajo baterije.
