Electromagnetic compatibility and Radio spectrum Matters (ERM) - Wideband transmission systems - Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques - Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive

The present document applies to Wide Band Data Transmission equipment.
The present document also describes spectrum access requirements to facilitate spectrum sharing with other equipment. Wide Band Data Transmission equipment covered by the present document is operated in accordance with the ERC Recommendation 70-03 [i.10], annex 3 or Commission Decision 2006/771/EC [i.11] (and its amendments). Examples of Wide Band Data Transmission equipment are equipments such as IEEE 802.11™ RLANs [i.3], Bluetooth® wireless technologies, Zigbee™, etc. This equipment can be used in fixed, mobile or nomadic applications, e.g.:
stand-alone radio equipment with or without their own control provisions;
plug-in radio devices intended for use with or within a variety of host systems, e.g. personal computers, hand-held terminals, etc.;
plug-in radio devices intended for use within combined equipment, e.g. cable modems, set-top boxes, access points, etc.;
combined equipment or a combination of a plug-in radio device and a specific type of host equipment. This radio equipment is capable of operating in the band 2,4 GHz to 2,4835 GHz.
Applications using Ultra Wide Band (UWB) technology are not covered by the present document.
The present document is intended to cover the provisions of Directive 1999/5/EC [i.1] (R&TTE Directive) article 3.2, which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference".

Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Širokopasovni prenosni sistemi - Oprema za prenos podatkov v frekvenčnem pasu 2,4 GHz ISM, ki uporablja širokopasovne modulacijske tehnike - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE

Ta dokument se uporablja za opremo za širokopasovni prenos podatkov.
Ta dokument opisuje tudi zahteve za dostop do spektra, ki omogočajo lažje deljenje spektra z drugo opremo. Oprema za širokopasovni prenos podatkov, ki je obravnavana v tem dokumentu, se uporablja v skladu z dodatkom 3 k priporočilu ERC 70-03 [i.10] ali Odločbo Komisije št. 2006/771/ES [i.11] s spremembami. Med opremo za širokopasovni prenos podatkov spadajo na primer IEEE 802.11™, zelo zmogljiva radijska lokalna omrežja (RLAN) [i.3], brezžične tehnologije Bluetooth®, Zigbee™, itd. Ta oprema se lahko uporablja v fiksnih, mobilnih ali nomadskih aplikacijah, kot so:
samostojna radijska oprema s pripadajočimi določbami o nadzoru ali brez;
vtične radijske naprave za uporabo z različnimi gostiteljskimi sistemi, npr. osebnimi računalniki, ročnimi terminali itd., ali v njih;
vtične radijske naprave za uporabo v sestavljenih sistemih, npr. kabelskih modemih, komunikatorjih, dostopnih točkah itd.;
sestavljeni sistemi ali kombinacija vtične radijske naprave in posebne vrste gostiteljske opreme. Ta radijska oprema lahko deluje v pasu 2,4 GHz do 2,4835 GHz.
Ta dokument ne zajema aplikacij, ki uporabljajo ultra širokopasovno (UWB) tehnologijo.
Ta dokument zajema določbe člena 3.2 Direktive 1999/5/ES [i.1] (direktive R&TTE), ki navaja, da »mora biti radijska oprema skonstruirana tako, da učinkovito uporablja spekter, razporejen za prizemne/vesoljske radijske komunikacije in orbitalne vire, tako da ne pride do škodljivega motenja«.
