Technical characteristics and methods of measurement for equipment for generation, transmission and reception of Digital Selective Calling (DSC) in the maritime MF, MF/HF and/or VHF mobile service - Part 3: Class D DSC

The present document states the minimum requirements for general communication for shipborne fixed installations using
DSC - class D.
Class D DSC is intended be used in the Very High Frequency (VHF) band of the Maritime Mobile Service (MMS), for
distress, urgency and safety communication and general communications using telephony for subsequent
communications.
The present document is part 3 of a multi-part deliverable that covers the requirements to be fulfilled by equipment that
is either integrated with a transmitter and/or a receiver or equipment that is a stand-alone DSC terminal.
These requirements include the relevant provisions and the guidelines of the IMO as detailed in MSC/Circ.803 [i.1] for
non-SOLAS vessels participating in the GMDSS as well as Commission Decision of 12 August 2013
(2013/638/EU) [i.5].
