SIST EN 13329:2016+A1:2017/FprA2:2021

Laminate floor coverings - Elements with a surface layer based on aminoplastic thermosetting resins - Specifications, requirements and test methods

This European Standard specifies characteristics, requirements and test methods for laminate floor coverings with a surface layer based on aminoplastic thermosetting resins as defined in 3.1 and 3.2. It also specifies requirements for marking and packaging.
It includes a classification system, based on EN ISO 10874, giving practical requirements for areas of use and levels of use, to indicate where laminate floor coverings will give satisfactory service and to encourage the consumer to make an informed choice.
Laminate floor coverings are considered for domestic and commercial levels of use, including domestic kitchens. This standard does not specify requirements relating to areas which are subjected to frequent wetting, such as bathrooms, laundry rooms or saunas.

Laminatböden - Elemente mit einer Deckschicht auf Basis aminoplastischer, wärmehärtbarer Harze - Spezifikationen, Anforderungen und Prüfverfahren

Revêtements de sol stratifiés - Éléments dont la surface est à base de résines aminoplastes thermodurcissables - Spécifications, exigences et méthodes d'essai

Laminatne talne obloge - Elementi z zunanjo plastjo na osnovi aminoplastičnih termostabilnih smol - Specifikacije, zahteve in preskusne metode

General Information

• Status: Not Published
• Public Enquiry End Date: 02-Aug-2020
• ICS: 97.150 - Floor coverings
• Technical Committee: ITEK - Textile and textile products
• Current Stage: 98 - Abandoned project (Adopted Project)
• Start Date: 14-Oct-2021
• Due Date: 19-Oct-2021
• Completion Date: 14-Oct-2021
• Ref Project: EN 13329:2016+A1:2017/FprA2 - Laminate floor coverings - Elements with a surface layer based on aminoplastic thermosetting resins - Specifications, requirements and test methods

Relations

• Consolidated By: SIST EN 13329:2016+A2:2021 - Laminate floor coverings - Elements with a surface layer based on aminoplastic thermosetting resins - Specifications, requirements and test methods
• Effective Date: 30-Jun-2021
• Amends: SIST EN 13329:2016+A1:2017 - Laminate floor coverings - Elements with a surface layer based on aminoplastic thermosetting resins - Specifications, requirements and test methods
• Effective Date: 01-Jul-2020

Overview

SIST EN 13329:2016+A1:2017/FprA2:2021 is a comprehensive European standard developed by CEN, specifying the requirements, specifications, and test methods for laminate floor coverings. These laminates feature a surface layer based on aminoplastic thermosetting resins, which provide enhanced durability and performance. The standard addresses both domestic and commercial use scenarios, including domestic kitchens, while explicitly excluding areas subject to frequent wetting such as bathrooms, laundry rooms, and saunas unless authorized by the manufacturer.

This standard ensures manufacturers and consumers have a clear classification and understanding of laminate flooring's suitability for various use levels, enabling quality assurance and informed purchasing decisions.

Key Topics

• Surface Layer Composition
  Focuses on laminate elements with a surface layer composed of aminoplastic thermosetting resins, known for their resilience and durability.

• Classification System
  Utilizes a classification aligned with EN ISO 10874 to define levels of use, based on domestic and commercial application intensities:

  • Classes 21-23 for domestic moderate to heavy use
  • Classes 31-34 for commercial moderate to very heavy use

• Performance Requirements
  Includes test methods and minimum performance values for:

  • Abrasion resistance (AC1 to AC6 levels)
  • Impact resistance (small and large ball tests per EN 17368 and EN 438)
  • Resistance to staining
  • Effects of furniture legs and castor chairs
  • Thickness swelling limits after moisture exposure
  • Locking strength of laminate joints
  • Surface soundness and dimensional stability

• Test Methodology Updates
  Revision prA2:2020 introduces refined definitions, modified classification tables, and updated impact resistance testing methods including the large ball impact resistance test to ensure consistent and realistic evaluation of laminate durability.

• Installation and Use Guidelines
  Emphasizes that laminate flooring is generally intended for floating installations and may only be used in wet areas if explicitly approved by manufacturers under detailed installation instructions.

Applications

EN 13329 laminate flooring standards are critical for:

• Manufacturers
  To design and test laminate floors ensuring compliance with rigorous European performance standards, enhancing product reliability and market acceptance.

• Architects and Designers
  To specify laminate floor coverings suitable for varying levels of traffic in both residential and commercial environments, balancing aesthetics with durability.

• Contractors and Installers
  To follow reliable classifications and installation guidelines ensuring the performance and longevity of laminate flooring in different usage areas.

• Consumers and Facility Managers
  To make informed choices about laminate flooring products best suited to their environment’s wear and tear, improving satisfaction and long-term value.

Related Standards

• EN ISO 10874
  Classification of floor coverings by their usage and abrasion resistance levels, foundational to EN 13329’s level of use system.

• EN 438 Series
  Determination of resistance to impact, staining, and scratching of high-pressure laminates, referenced for large ball impact testing in EN 13329.

• EN 13756
  Defines core materials made of wood for laminate flooring, referenced in substrate definitions for EN 13329 compliance.

• EN 424, EN 425, ISO 24336, ISO 24334, ISO 24339
  Various test methods for furniture leg impact resistance, castor chair tests, swelling, locking strength, and dimensional stability.

---

By adhering to the SIST EN 13329:2016+A1:2017/FprA2:2021 standard, stakeholders ensure laminate floorings meet recognized European benchmarks, guaranteeing durability, safety, and performance suitable for real-world applications across residential and commercial spaces.

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN 13329:2016+A1:2017/oprA2:2020
01-julij-2020
Laminatne talne obloge - Elementi z zunanjo plastjo na osnovi aminoplastičnih
termostabilnih smol - Specifikacije, zahteve in preskusne metode
Laminate floor coverings - Elements with a surface layer based on aminoplastic
thermosetting resins - Specifications, requirements and test methods
Laminatböden - Elemente mit einer Deckschicht auf Basis aminoplastischer,
wärmehärtbarer Harze - Spezifikationen, Anforderungen und Prüfverfahren
Revêtements de sol stratifiés - Éléments dont la surface est à base de résines
aminoplastes thermodurcissables - Spécifications, exigences et méthodes d'essai
Ta slovenski standard je istoveten z: EN 13329:2016+A1:2017/prA2
ICS:
97.150 Talne obloge Floor coverings
SIST EN en
13329:2016+A1:2017/oprA2:2020
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

SIST EN 13329:2016+A1:2017/oprA2:2020

SIST EN 13329:2016+A1:2017/oprA2:2020

DRAFT
EUROPEAN STANDARD
EN 13329:2016+A1:2017
NORME EUROPÉENNE
EUROPÄISCHE NORM
prA2
July 2020
ICS 97.150
English Version
Laminate floor coverings - Elements with a surface layer
based on aminoplastic thermosetting resins -
Specifications, requirements and test methods
Revêtements de sol stratifiés - Éléments dont la surface Laminatböden - Elemente mit einer Deckschicht auf
est à base de résines aminoplastes thermodurcissables Basis aminoplastischer, wärmehärtbarer Harze -
- Spécifications, exigences et méthodes d'essai Spezifikationen, Anforderungen und Prüfverfahren
This draft amendment is submitted to CEN members for enquiry. It has been drawn up by the Technical Committee CEN/TC 134.

This draft amendment A2, if approved, will modify the European Standard EN 13329:2016+A1:2017. If this draft becomes an
amendment, CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for
inclusion of this amendment into the relevant national standard without any alteration.

This draft amendment was established by CEN in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC
Management Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and
United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are
aware and to provide supporting documentation.

Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without
notice and shall not be referred to as a European Standard.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION

EUROPÄISCHES KOMITEE FÜR NORMUNG

CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2020 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 13329:2016+A1:2017/prA2:2020 E
worldwide for CEN national Members.

SIST EN 13329:2016+A1:2017/oprA2:2020
EN 13329:2016+A1:2017/prA2:2020 (E)
Contents Page
European foreword . 3
1 Modification to Clause 1, Scope . 4
2 Modification to term 3.3, substrate . 4
3 Modification to 4.2, Classification requirements, Table 2 . 4
4 Modification to Annex H, Determination of large ball impact resistance . 7
Annex H (normative) Determination of large ball impact resistance . 8
H.1 General. 8
H.2 Apparatus . 8
H.3 Procedure . 8

SIST EN 13329:2016+A1:2017/oprA2:2020
EN 13329:2016+A1:2017/prA2:2020 (E)
European foreword
This document (EN 13329:2016+A1:2017/prA2:2020) has been prepared by Technical Committee
CEN/TC 134 “Resilient, textile and laminate floor coverings”, the secretariat of which is held by NBN.
This document is currently submitted to the CEN Enquiry.
This document will supersede EN 13329:2016+A1:2017.
In comparison with the previous version EN 13329:2016+A1:2017 of the original edition EN
13329:2016, the new consolidated version EN 13329:2016+A2:2020 will contain the following
technical modifications:
— Scope: replacement of the last paragraph;
— term 3.3 substrate: replacement of the definition;
— Table 2: change the requirements and test method for impact resistance: small ball and addition of
d
footnote to table as clarification for testing, replacement of Table 2;
— Annex H: small ball test method has been deleted, replacement of Annex H.

SIST EN 13329:2016+A1:2017/oprA2:2020
EN 13329:2016+A1:2017/prA2:2020 (E)
1 Modification to Clause 1, Scope
Replace the last paragraph of the scope
“Laminate floor coverings are considered for domestic and commercial levels of use, including domestic
kitchens. This standard does not specify requirements relating to areas which are subjected to frequent
wetting, such as bathrooms, laundry rooms or saunas.”
with
“Laminate floor coverings are generally designed for floating installations and are considered for
domestic and commercial levels of use, including domestic kitchens. This document does not specify
requirements relating to the use in areas which are subjected to frequent wetting, such as bathrooms,
laundry rooms or saunas. In general laminate floor coverings can only be used in those areas when
authorized by the manufacturer and under conditions described in the manufacturer's installation
guidelines.”.
2 Modification to term 3.3, substrate
Replace the definition
”core material of the laminate floor covering”
with
“core material of the laminate floor covering made of wood, as defined in EN 13756, for at least 65 % in
mass”.
3 Modification to 4.2, Classification requirements, Table 2
...
