SLOVENSKI STANDARD
SIST EN 60422:2013
01-julij-2013
0LQHUDOQDL]RODFLMVNDROMDYHOHNWULþQLRSUHPL1DSRWNL]DQDG]RURYDQMHLQ
Y]GUåHYDQMH
Mineral insulating oils in electrical equipment - Supervision and maintenance guidance
Richtlinien zur Überwachung und Wartung von Isolierölen auf Mineralölbasis in
elektrischen Betriebsmitteln
Huiles minérales isolantes dans les matériels électriques - Lignes directrices pour la
maintenance et la surveillance
Ta slovenski standard je istoveten z: EN 60422:2013
ICS:
29.040.10 Izolacijska olja Insulating oils
SIST EN 60422:2013 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
SIST EN 60422:2013
---------------------- Page: 2 ----------------------
SIST EN 60422:2013
EUROPEAN STANDARD
EN 60422
NORME EUROPÉENNE
May 2013
EUROPÄISCHE NORM
ICS 29.040.10 Supersedes EN 60422:2006
English version
Mineral insulating oils in electrical equipment -
Supervision and maintenance guidance
(IEC 60422:2013)
Huiles minérales isolantes dans les Isolieröle auf Mineralölbasis in
matériels électriques - elektrischen Betriebsmitteln -
Lignes directrices pour la maintenance et Leitlinie zur Überwachung und Wartung
la surveillance (IEC 60422:2013)
(CEI 60422:2013)
This European Standard was approved by CENELEC on 2013-02-14. CENELEC members are bound to comply
with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard
the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on
application to the CEN-CENELEC Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CENELEC member into its own language and notified
to the CEN-CENELEC Management Centre has the same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus,
the Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany,
Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland,
Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.
CENELEC
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
Management Centre: Avenue Marnix 17, B - 1000 Brussels
© 2013 CENELEC - All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 60422:2013 E
---------------------- Page: 3 ----------------------
SIST EN 60422:2013
EN 60422:2013 - 2 -
Foreword
The text of document 10/894/FDIS, future edition 4 of IEC 60422, prepared by IEC TC 10 "Fluids for
electrotechnical applications" was submitted to the IEC-CENELEC parallel vote and approved by
CENELEC as EN 60422:2013.
The following dates are fixed:
• latest date by which the document has (dop) 2013-11-14
to be implemented at national level by
publication of an identical national
standard or by endorsement
(dow) 2016-02-14
• latest date by which the national
standards conflicting with the
document have to be withdrawn
This document supersedes EN 60422:2006.
EN 60422:2013 represents a major revision of EN 60422:2006, in order to bring in line this standard with
latest development of oil condition monitoring, containing new limits for oil parameters, suggested
corrective actions in the tables and new test methods.
The action limits for all oil tests have been revised and changes made where necessary to enable users
to use current methodology and comply with requirements and regulations affecting safety and
environmental aspects.
In addition, EN 60422:2013 incorporates changes introduced in associated standards since
EN 60422:2006 was published.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC [and/or CEN] shall not be held responsible for identifying any or all such patent
rights.
Endorsement notice
The text of the International Standard IEC 60422:2013 was approved by CENELEC as a European
Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standards indicated:
IEC 60567 NOTE Harmonised as EN 60567.
IEC 60599 NOTE Harmonised as EN 60599.
IEC 61198 NOTE Harmonised as EN 61198.
ISO 12185 NOTE Harmonised as EN ISO 12185.
---------------------- Page: 4 ----------------------
SIST EN 60422:2013
- 3 - EN 60422:2013
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
NOTE When an international publication has been modified by common modifications, indicated by (mod), the relevant EN/HD
applies.
Publication Year Title EN/HD Year
IEC 60156 - Insulating liquids - Determination of the EN 60156 -
breakdown voltage at power frequency - Test
method
IEC 60247 - Insulating liquids - Measurement of relative EN 60247 -
permittivity, dielectric dissipation factor (tan δ)
and d.c. resistivity
IEC 60296 2012 Fluids for electrotechnical applications - EN 60296 2012
Unused mineral insulating oils for
transformers and switchgear
IEC 60475 - Method of sampling insulating liquids EN 60475 -
IEC 60666 2010 Detection and determination of specified EN 60666 2010
additives in mineral insulating oils
IEC 60814 - Insulating liquids - Oil-impregnated paper and EN 60814 -
pressboard - Determination of water by
automatic coulometric Karl Fischer titration
IEC 60970 - Insulating liquids - Methods for counting and EN 60970 -
sizing particles
IEC 61125 1992 Unused hydrocarbon-based insulating liquids - EN 61125 1993
+ corr. September 1992 Test methods for evaluating the oxidation
stability
IEC 61619 - Insulating liquids - Contamination by EN 61619 -
polychlorinated biphenyls (PCBs) - Method of
determination by capillary column gas
chromatography
IEC 62021-1 - Insulating liquids - Determination of acidity - EN 62021-1 -
Part 1: Automatic potentiometric titration
IEC 62021-2 - Insulating liquids - Determination of acidity - EN 62021-2 -
Part 2: Colourimetric titration
IEC 62535 2008 Insulating liquids - Test method for detection EN 62535 2009
of potentially corrosive sulphur in used and
unused insulating oil
IEC 62697-1 2012 Test method for quantitative determination of EN 62697-1 2012
corrosive sulfur compounds in unused and
used insulating liquids -
Part 1: Test method for quantitative
determination of dibenzyldisulfide (DBDS)
EN 14210 - Surface active agents - Determination of - -
interfacial tension of solutions of surface
active agents by the stirrup or ring method
---------------------- Page: 5 ----------------------
SIST EN 60422:2013
EN 60422:2013 - 4 -
Publication Year Title EN/HD Year
ISO 2049 - Petroleum products - Determination of colour - -
(ASTM scale)
ISO 2719 - Determination of flash point - Pensky-Martens EN ISO 2719 -
closed cup method
ISO 3016 - Petroleum products - Determination of pour - -
point
ISO 3104 - Petroleum products - Transparent and opaque EN ISO 3104 -
liquids - Determination of kinematic viscosity
and calculation of dynamic viscosity
ISO 3675 - Crude petroleum and liquid petroleum EN ISO 3675 -
products - Laboratory determination of density
- Hydrometermethod
ISO 4406 1999 Hydraulic fluid power - Fluids - Method for - -
coding the level of contamination by solid
particles
ASTM D971 - Standard test method for interfacial tension of - -
oil against water by the ring method
ASTM D1275 2006 Standard test method for corrosive sulfur in - -
electrical insulating oils
DIN 51353 - Testing of insulating oils; detection of - -
corrosive sulfur; silver strip test
---------------------- Page: 6 ----------------------
SIST EN 60422:2013
IEC 60422
®
Edition 4.0 2013-01
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Mineral insulating oils in electrical equipment – Supervision and maintenance
guidance
Huiles minérales isolantes dans les matériels électriques – Lignes directrices
pour la maintenance et la surveillance
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
CODE PRIX X
ICS 29.040.10 ISBN 978-2-83220-560-0
Warning! Make sure that you obtained this publication from an authorized distributor.
Attention! Veuillez vous assurer que vous avez obtenu cette publication via un distributeur agréé.
® Registered trademark of the International Electrotechnical Commission
Marque déposée de la Commission Electrotechnique Internationale
---------------------- Page: 7 ----------------------
SIST EN 60422:2013
– 2 – 60422 IEC:2013
CONTENTS
FOREWORD . 4
INTRODUCTION . 6
1 Scope . 8
2 Normative references . 8
3 Terms and definitions . 9
4 Properties and deterioration/degradation of oil . 10
5 Oil tests and their significance . 11
5.1 General . 11
5.2 Colour and appearance . 12
5.3 Breakdown voltage . 12
5.4 Water content . 12
5.4.1 General . 12
5.4.2 Water in oil . 12
5.4.3 Water content in the oil/paper-system . 14
5.4.4 Interpretation of results. 15
5.5 Acidity . 15
5.6 Dielectric dissipation factor (DDF) and resistivity . 15
5.7 Inhibitor content and oxidation stability . 18
5.7.1 Oxidation stability . 18
5.7.2 Monitoring of uninhibited oils . 18
5.7.3 Monitoring of inhibited oils . 18
5.8 Sediment and sludge . 18
5.9 Interfacial tension (IFT) . 19
5.10 Particle count . 19
5.11 Flash point . 19
5.12 Compatibility of insulating oils . 20
5.13 Pour point . 20
5.14 Density . 20
5.15 Viscosity. 20
5.16 Polychlorinated biphenyls (PCBs) . 21
5.17 Corrosive sulphur . 21
5.18 Dibenzyl disulphide (DBDS) . 22
5.19 Passivator . 22
6 Sampling of oil from equipment . 22
7 Categories of equipment . 23
8 Evaluation of mineral insulating oil in new equipment . 23
9 Evaluation of oil in service . 24
9.1 General . 24
9.2 Frequency of examination of oils in service . 25
9.3 Testing procedures . 26
9.3.1 General . 26
9.3.2 Field tests. 26
9.3.3 Laboratory tests . 27
9.4 Classification of the condition of oils in service . 27
9.5 Corrective action . 27
---------------------- Page: 8 ----------------------
SIST EN 60422:2013
60422 IEC:2013 – 3 –
10 Handling and storage . 32
11 Treatment . 33
11.1 WARNING . 33
11.2 Reconditioning . 34
11.2.1 General . 34
11.2.2 Reconditioning equipment . 35
11.2.3 Application to electrical equipment . 36
11.3 Reclaiming . 37
11.3.1 General . 37
11.3.2 Reclaiming by percolation . 37
11.3.3 Reclaiming by contact . 38
11.3.4 Renewal of additives . 38
11.4 Decontamination of oils containing PCBs . 38
11.4.1 General . 38
11.4.2 Dehalogenation processes using sodium and lithium derivatives . 38
11.4.3 Dehalogenation processes using polyethylene glycol and potassium
hydroxide (KPEG) . 39
11.4.4 Dehalogenation in continuous mode by closed circuit process . 39
12 Replacement of oil in electrical equipment . 39
12.1 Replacement of oil in transformers rated below 72,5 kV and in switchgear
and associated equipment . 39
12.2 Replacement of oil in transformers rated 72,5 kV and above . 39
12.3 Replacement of oil in electrical equipment contaminated with PCB . 40
13 Passivation . 40
Annex A (informative) Evaluating water in oil and insulation. 41
Annex B (informative) Particles . 43
Annex C (informative) Test method for determination of sediment and sludge . 44
Bibliography . 45
Figure 1 – Example of variation in saturation water content with oil temperature and
acidity for insulating oil originally conforming to IEC 60296 . 14
Figure 2 – Example of variation of resistivity with temperature for insulating oils . 17
Figure A.1 – Typical correction factors . 41
Table 1 – Tests for in-service mineral insulating oils . 11
Table 2 – Categories of equipment . 23
Table 3 – Recommended limits for mineral insulating oils after filling in new electrical
equipment prior to energization . 24
a
Table 4 – Recommended frequency of testing . 26
Table 5 – Application and interpretation of tests (1 of 4) . 28
Table 6 – Summary of typical actions . 32
Table 7 – Conditions for processing inhibited and/ or passivator containing mineral
insulating oils . 35
Table A.1 – Guidelines for interpreting data expressed in per cent saturation . 42
Table B.1 – Typical contamination levels (particles) encountered on power transformer
insulating oil as measured using IEC 60970 . 43
---------------------- Page: 9 ----------------------
SIST EN 60422:2013
– 4 – 60422 IEC:2013
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
MINERAL INSULATING OILS IN ELECTRICAL EQUIPMENT –
SUPERVISION AND MAINTENANCE GUIDANCE
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60422 has been prepared by IEC technical committee 10: Fluids
for electrotechnical applications.
This fourth edition cancels and replaces the third edition, published in 2005, and constitutes a
technical revision.
The main changes with respect to the previous edition are as follows:
This new edition represents a major revision of the third edition, in order to bring in line this
standard with latest development of oil condition monitoring, containing new limits for oil
parameters, suggested corrective actions in the tables and new test methods.
The action limits for all oil tests have been revised and changes made where necessary to
enable users to use current methodology and comply with requirements and regulations
affecting safety and environmental aspects.
---------------------- Page: 10 ----------------------
SIST EN 60422:2013
60422 IEC:2013 – 5 –
In addition, this standard incorporates changes introduced in associated standards since the
third edition was published.
The text of this standard is based on the following documents:
FDIS Report on voting
10/894/FDIS 10/896/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
---------------------- Page: 11 ----------------------
SIST EN 60422:2013
– 6 – 60422 IEC:2013
INTRODUCTION
Insulating mineral oils are used in electrical equipment employed in the generation,
transmission, distribution and use of electrical energy, so that the amount of oil in service,
worldwide, amounts to hundreds of millions of kilograms.
Monitoring and maintaining oil quality is essential to ensure the reliable operation of oil-filled
electrical equipment. Codes of practice for this purpose have been established by electrical
power authorities, power companies and industries in many countries.
A review of current experience reveals a wide variation of procedures and criteria. It is
possible, however, to compare the value and significance of standardized oil tests and to
recommend uniform criteria for the evaluation of test data.
If a certain amount of oil deterioration (by degradation or contamination) is exceeded, there is
inevitably some erosion of safety margins and the question of the risk of premature failure
should be considered. While the quantification of the risk can be very difficult, a first step
involves the identification of potential effects of increased deterioration. The philosophy
underlying this standard is to furnish users with as broad a base of understanding of oil
quality deterioration as is available, so that they can make informed decisions on inspection
and maintenance practices.
Unused mineral oils are limited resources and should be handled with this in mind. Used
mineral oils are, by most regulations, deemed to be controlled waste. If spills occur this may
have a negative environmental impact especially if the oil is contaminated by persistent
organic pollutants such as polychlorinated biphenyls (PCBs).
This International Standard, whilst technically sound, is mainly intended to serve as a
common basis for the preparation of more specific and complete codes of practice by users in
the light of local circumstances. Sound engineering judgement will have to be exerted in
seeking the best compromise between technical requirements and economic factors.
Reference should also be made to instructions from the equipment manufacturer.
General caution
This International Standard does not purport to address all the safety problems associated
with its use. It is the responsibility of the user of this standard to establish appropriate health
and safety practices and determine the applicability of regulatory limitations prior to use.
The mineral oils and oil additives which are the subject of this standard should be handled
with due regard to personal hygiene. Direct contact with the eyes may cause slight irritation.
In the case of eye contact, irrigation with copious quantities of clean running water should be
carried out and medical advice sought. For more information, refer to the safety data sheet
provided by the manufacturer. Some of the tests specified in this standard involve the use of
processes that could lead to a hazardous situation. Attention is drawn to the relevant standard
for guidance.
Environment
This standard is applicable to mineral oils, chemicals and used sample containers.
Attention is drawn to the fact that, at the time of writing this standard, some mineral oils in
service are known to be contaminated to some degree by PCBs.
---------------------- Page: 12 ----------------------
SIST EN 60422:2013
60422 IEC:2013 – 7 –
Because of this, safety countermeasures should be taken to avoid risks to workers, the public
and the environment during the life of the equipment, by strictly controlling spills and
emissions. Disposal or decontamination of these oils should be carried out strictly according
to local regulations. Every precaution should be taken to prevent release of mineral oil into
the environment.
---------------------- Page: 13 ----------------------
SIST EN 60422:2013
– 8 – 60422 IEC:2013
MINERAL INSULATING OILS IN ELECTRICAL EQUIPMENT –
SUPERVISION AND MAINTENANCE GUIDANCE
1 Scope
This International Standard gives guidance on the supervision and maintenance of the quality
of the insulating oil in electrical equipment.
This standard is applicable to mineral insulating oils, originally supplied conforming to
IEC 60296, in transformers, switchgear and other electrical apparatus where oil sampling is
reasonably
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
