ASTM D8114-23a

Standard Test Method for Measurement of Effects of Automotive Engine Oils on Fuel Economy of Passenger Cars and Light-Duty Trucks in Sequence VIE Spark Ignition

SIGNIFICANCE AND USE
5.1 Test Method—The data obtained from the use of this test method provide a comparative index of the fuel-saving capabilities of automotive engine oils under repeatable laboratory conditions. A BL has been established for this test to provide a standard against which all other oils can be compared. The BL oil is an SAE 20W-30 grade fully formulated lubricant. The test procedure was not designed to give a precise estimate of the difference between two test oils without adequate replication. The test method was developed to compare the test oil to the BL oil. Companion test methods used to evaluate engine oil performance for specification requirements are discussed in the latest revision of Specification D4485.
5.2 Use—The Sequence VIE test method is useful for engine oil fuel economy specification acceptance. It is used in specifications and classifications of engine lubricating oils, such as the following:
5.2.1 Specification D4485.
5.2.2 API 1509.
5.2.3 SAE Classification J304.
5.2.4 SAE Classification J1423.
SCOPE
1.1 This test method covers an engine test procedure for the measurement of the effects of automotive engine oils on the fuel economy of passenger cars and light-duty trucks with gross vehicle weight 3856 kg or less. The tests are conducted using a specified spark-ignition engine with a displacement of 3.6 L (General Motors)4 on a dynamometer test stand. It applies to multi-viscosity oils used in these applications.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.2.1 Exceptions—Where there is no direct equivalent such as the units for screw threads, National Pipe threads/diameters, tubing size, and single source supply equipment specifications. Additionally, Brake Specific Fuel Consumption (BSFC) is measured in kilogram per kilowatt hour.
1.3 This test method is arranged as follows:
Subject
Section
Introduction
Scope
1
Referenced Documents
2
Terminology
3
Summary of Test Method
4
Significance and Use
5
Apparatus
6
General
6.1
Test Engine Configuration
6.2
Laboratory Ambient Conditions
6.3
Engine Speed and Torque Control
6.4
Dynamometer
6.4.1
Dynamometer Torque
6.4.2
Engine Cooling System
6.5
External Oil System
6.6
Fuel System
6.7
Fuel Flow Measurement
6.7.2
Fuel Temperature and Pressure Control to the Fuel Flow Meter
6.7.3
Fuel Temperature and Pressure Control to Engine Fuel Rail
6.7.4
Fuel Supply Pumps
6.7.5
Fuel Filtering
6.7.6
Engine Intake Air Supply
6.8
Intake Air Humidity
6.8.1
Intake Air Filtration
6.8.2
Intake Air Pressure Relief
6.8.3
Temperature Measurement
6.9
Thermocouple Location
6.9.5
AFR Determination
6.10
Exhaust and Exhaust Back Pressure Systems
6.11
Exhaust Manifolds
6.11.1
Laboratory Exhaust System
6.11.2
Exhaust Back Pressure
6.11.3
Pressure Measurement and Pressure Sensor Locations
6.12
Engine Oil
6.12.2
Fuel to Fuel Flow Meter
6.12.3
Fuel to Engine Fuel Rail
6.12.4
Exhaust Back Pressure
6.12.5
Intake Air
6.12.6
Intake Manifold Vacuum/Absolute Pressure
6.12.7
Coolant Flow Differential Pressure
6.12.8
Crankcase Pressure
6.12.9
Engine Hardware and Related Apparatus
6.13
Test Engine Configuration
6.13.1
ECU (Power Control Module)
6.13.2
Thermostat Block-Off Adapter Plate
6.13.3
Wiring Harness
6.13.4
Thermostat Block-Off Plate
6.13.5
Oil Filter Adapter Plate
6.13.6
Modified Throttle Body Assembly
6.13.7
Fuel Rail
6.13.8
Miscellaneous Apparatus Related to Engine Operation
6.14
Reagents and Materials
7
Engine Oil
7.1
Test Fuel
7.2
Engine Coolant
7.3
Cleaning Materials...

General Information

• Status: Published
• Publication Date: 30-Sep-2023
• ICS: 75.100 - Lubricants, industrial oils and related products
• Technical Committee: D02 - Petroleum Products, Liquid Fuels, and Lubricants
• Drafting Committee: D02.B0.01 - Passenger Car Engine Oils

Relations

• Replaces: ASTM D8114-23 - Standard Test Method for Measurement of Effects of Automotive Engine Oils on Fuel Economy of Passenger Cars and Light-Duty Trucks in Sequence VIE Spark Ignition
• Effective Date: 01-Oct-2023
• Refers: ASTM D445-24 - Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids (and Calculation of Dynamic Viscosity)
• Effective Date: 01-Apr-2024
• Refers: ASTM D3231-24 - Standard Test Method for Phosphorus in Gasoline
• Effective Date: 01-Mar-2024
• Refers: ASTM D2699-24 - Standard Test Method for Research Octane Number of Spark-Ignition Engine Fuel
• Effective Date: 01-Mar-2024
• Refers: ASTM D4175-23a - Standard Terminology Relating to Petroleum Products, Liquid Fuels, and Lubricants
• Effective Date: 15-Dec-2023
• Refers: ASTM D86-23ae1 - Standard Test Method for Distillation of Petroleum Products and Liquid Fuels at Atmospheric Pressure
• Effective Date: 01-Dec-2023
• Refers: ASTM D86-23a - Standard Test Method for Distillation of Petroleum Products and Liquid Fuels at Atmospheric Pressure
• Effective Date: 01-Dec-2023
• Refers: ASTM D445-23 - Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids (and Calculation of Dynamic Viscosity)
• Effective Date: 01-Nov-2023
• Refers: ASTM D2699-23b - Standard Test Method for Research Octane Number of Spark-Ignition Engine Fuel
• Effective Date: 01-Nov-2023
• Refers: ASTM D2699-23a - Standard Test Method for Research Octane Number of Spark-Ignition Engine Fuel
• Effective Date: 01-Oct-2023
• Refers: ASTM D4175-23 - Standard Terminology Relating to Petroleum Products, Liquid Fuels, and Lubricants
• Effective Date: 01-Jul-2023
• Refers: ASTM D4175-23e1 - Standard Terminology Relating to Petroleum Products, Liquid Fuels, and Lubricants
• Effective Date: 01-Jul-2023
• Refers: ASTM D86-23 - Standard Test Method for Distillation of Petroleum Products and Liquid Fuels at Atmospheric Pressure
• Effective Date: 01-Mar-2023
• Refers: ASTM D2699-23 - Standard Test Method for Research Octane Number of Spark-Ignition Engine Fuel
• Effective Date: 01-Mar-2023
• Refers: ASTM D445-21e2 - Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids (and Calculation of Dynamic Viscosity)
• Effective Date: 15-May-2021

Overview

ASTM D8114-23a is a standard test method developed by ASTM International for measuring the effects of automotive engine oils on the fuel economy of passenger cars and light-duty trucks using Sequence VIE spark-ignition engines. The primary goal of this test method is to provide a controlled, comparative index for assessing the fuel-saving capability of different engine oils, supporting specification compliance and product development in the automotive lubricants industry.

The test uses a specific spark-ignition engine setup under standardized laboratory conditions, providing repeatable results. Comparison is made against a designated baseline oil (an SAE 20W-30 fully formulated lubricant), ensuring that the impact of any test oil on engine fuel economy can be objectively evaluated.

Key Topics

• Fuel Economy Measurement: The standard evaluates the relative effectiveness of multi-viscosity engine oils in improving fuel efficiency, using Brake Specific Fuel Consumption (BSFC) as the primary metric.
• Standardized Engine and Test Protocol: Testing is conducted with a 3.6 L General Motors spark-ignition engine mounted on a dynamometer, following tightly controlled parameters for speed, torque, temperature, air, and fuel supply.
• Baseline Lubricant Comparison: All oils are measured against the established baseline oil, allowing for consistent, meaningful comparisons.
• Calibration and Reference Procedures: The method outlines strict requirements for equipment calibration and the use of reference materials, often facilitated by the ASTM Test Monitoring Center to ensure inter-laboratory consistency.
• Controlled Laboratory Conditions: Environmental variables like temperature, humidity, and airflow are regulated to minimize external influences.
• Applicability and Limitations: The method is intended for specification acceptance and classification of engine oils, but not for absolute determination of fuel economy differences without adequate test replication.

Applications

ASTM D8114-23a is essential for:

• Engine Oil Manufacturers: Validating claims for energy-saving or fuel economy benefits of new or reformulated lubricants.
• Automotive OEMs: Specifying qualified engine oils for warranty, compliance, and performance requirements in vehicles up to 3,856 kg gross vehicle weight.
• Regulatory and Certification Bodies: Assessing fuel economy contribution of engine oils for compliance with industry standards, certification, and labeling.
• Test Laboratories: Conducting standardized comparative evaluations for product development, quality control, and industry research.
• Aftermarket and Lubricant Distributors: Supporting product marketing and selection based on independently verified fuel economy performance.

Related Standards

Several key standards are referenced alongside ASTM D8114-23a to provide a comprehensive framework for engine oil performance evaluation:

• ASTM D4485: Sets the performance specification for active API Service Category engine oils.
• API 1509: Covers the Engine Oil Licensing and Certification System.
• SAE J304: Classification of engine oil tests for performance requirements.
• SAE J1423: Classification of energy-conserving engine oils for passenger cars and light-duty trucks.

Other related ASTM methods include procedures for viscosity measurement (ASTM D445), density (ASTM D4052), oil analysis (ASTM D5185), and sulfur content determination (ASTM D5453).

Conclusion

ASTM D8114-23a plays an important role in the automotive and lubricant industries by defining a rigorous, reproducible test protocol for measuring the fuel economy impact of engine oils. This ensures transparency, reliability, and comparability for lubricant specification, development, and regulatory compliance. By adhering to this standard, stakeholders can credibly demonstrate the fuel-saving benefits of their products, supporting innovation and informed decision-making in the market for energy-efficient lubricants.

Keywords: ASTM D8114-23a, engine oil, fuel economy, Sequence VIE, automotive lubricants, spark-ignition engine, lubricant testing, specification acceptance, baseline oil, fuel consumption measurement, standardized test method.

Standards Content (Sample)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: D8114 − 23a
Standard Test Method for
Measurement of Effects of Automotive Engine Oils on Fuel
Economy of Passenger Cars and Light-Duty Trucks in
1,2
Sequence VIE Spark Ignition
This standard is issued under the fixed designation D8114; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
Portions of this test method are written for use by laboratories that make use of ASTM Test
Monitoring Center (TMC) services (see Annex A1 – Annex A4).
The TMC provides reference oils and engineering and statistical services to laboratories that desire
to produce test results that are statistically similar to those produced by laboratories previously
calibrated by the TMC.
In general, the Test Purchaser decides if a calibrated test stand is to be used. Organizations such as
the American Chemistry Council require that a laboratory utilize the TMC services as part of their test
registration process. In addition, the American Petroleum Institute (API) and the Gear Lubricant
Review Committee of the Lubricant Review Institute (SAE International) require that a laboratory use
the TMC services in seeking qualification of oils against their specifications.
The advantage of using the TMC services to calibrate test stands is that the test laboratory (and
hence the Test Purchaser) has an assurance that the test stand was operating at the proper level of test
severity. It should also be borne in mind that results obtained in a non-calibrated test stand may not
be the same as those obtained in a test stand participating in the ASTM TMC services process.
Laboratories that choose not to use the TMC services may simply disregard these portions.
ASTM International policy is to encourage the development of test procedures based on generic
equipment. It is recognized that there are occasions where critical/sole-source equipment has been
approved by the technical committee (surveillance panel/task force) and is required by the test
procedure. The technical committee that oversees the test procedure is encouraged to clearly identify
if the part is considered critical in the test procedure. If a part is deemed to be critical, ASTM
encourages alternative suppliers to be given the opportunity for consideration of supplying the critical
part/component providing they meet the approval process set forth by the technical committee.
An alternative supplier can start the process by initiating contact with the technical committee
(current chairs shown on ASTM TMC website). The supplier should advise on the details of the part
that is intended to be supplied. The technical committee will review the request and determine
feasibility of an alternative supplier for the requested replacement critical part. In the event that a
replacement critical part has been identified and proven equivalent the sole-source supplier footnote
shall be removed from the test procedure.
