ASTM C1761/C1761M-23

Standard Specification for Lightweight Aggregate for Internal Curing of Concrete

SCOPE
1.1 This specification covers lightweight aggregate intended to provide water for internal curing of concrete. It includes test methods for determining the absorption and desorption properties of lightweight aggregate.
Note 1: Internal curing provides an additional source of water to sustain hydration and substantially reduce the early-age autogenous shrinkage and self-desiccation that can be significant contributors to early-age cracking. Appendix X1 provides guidance on calculating the quantity of lightweight aggregate for internal curing.
1.2 The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance. Some values have only SI units because the inch-pound equivalents are not used in practice.
Note 2: Sieve size is identified by its standard designation in Specification E11. The alternative designation given in parentheses is for information only and does not represent a different standard sieve size.
1.3 The text of this specification references notes and footnotes that provide explanatory material. These notes and footnotes (excluding those in tables and figures) shall not be considered as requirements of the standard.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-May-2023
• ICS: 91.100.30 - Concrete and concrete products
• Technical Committee: C09 - Concrete and Concrete Aggregates
• Drafting Committee: C09.21 - Lightweight Aggregates and Concrete

Relations

• Refers: ASTM C1608-23 - Standard Test Method for Chemical Shrinkage of Hydraulic Cement Paste
• Effective Date: 01-Dec-2023
• Refers: ASTM C142/C142M-17(2023) - Standard Test Method for Clay Lumps and Friable Particles in Aggregates
• Effective Date: 01-Oct-2023
• Refers: ASTM C114-23 - Standard Test Methods for Chemical Analysis of Hydraulic Cement
• Effective Date: 01-Oct-2023
• Refers: ASTM C29/C29M-23 - Standard Test Method for Bulk Density (“Unit Weight”) and Voids in Aggregate
• Effective Date: 01-Oct-2023
• Refers: ASTM C125-19a - Standard Terminology Relating to Concrete and Concrete Aggregates
• Effective Date: 15-Dec-2019
• Refers: ASTM D75/D75M-19 - Standard Practice for Sampling Aggregates
• Effective Date: 01-Nov-2019
• Refers: ASTM C1698-19 - Standard Test Method for Autogenous Strain of Cement Paste and Mortar
• Effective Date: 01-Oct-2019
• Refers: ASTM C125-19 - Standard Terminology Relating to Concrete and Concrete Aggregates
• Effective Date: 01-Jan-2019
• Refers: ASTM C125-18b - Standard Terminology Relating to Concrete and Concrete Aggregates
• Effective Date: 01-Oct-2018
• Refers: ASTM C125-18a - Standard Terminology Relating to Concrete and Concrete Aggregates
• Effective Date: 01-Jul-2018
• Refers: ASTM C125-18 - Standard Terminology Relating to Concrete and Concrete Aggregates
• Effective Date: 01-Jan-2018
• Refers: ASTM C1608-17 - Standard Test Method for Chemical Shrinkage of Hydraulic Cement Paste
• Effective Date: 01-Aug-2017
• Refers: ASTM C330/C330M-17 - Standard Specification for Lightweight Aggregates for Structural Concrete
• Effective Date: 01-May-2017
• Refers: ASTM D2172/D2172M-17 - Standard Test Methods for Quantitative Extraction of Asphalt Binder from Asphalt Mixtures
• Effective Date: 01-Apr-2017
• Refers: ASTM D2172/D2172M-17e1 - Standard Test Methods for Quantitative Extraction of Asphalt Binder from Asphalt Mixtures
• Effective Date: 01-Apr-2017

Overview

ASTM C1761/C1761M-23 is the international standard specification for lightweight aggregate used for internal curing of concrete. Published by ASTM International, this standard defines the requirements, test methods, and application guidelines for lightweight aggregate materials that supply additional water within concrete mixes to promote optimal hydration and reduce early-age cracking.

Internal curing is a proven technique in concrete technology that mitigates autogenous shrinkage and self-desiccation, common causes of early-age cracking. The standard provides a framework for evaluating the absorption and desorption properties of lightweight aggregates to ensure sufficient water is available to support cement hydration during curing.

Key Topics

• Scope & Purpose: Specifies properties and requirements for lightweight aggregate intended for internal curing applications in concrete.
• Types of Lightweight Aggregates: Covers manufactured aggregates (e.g., expanded clay, shale, slate, pelletized products) and processed natural materials (e.g., pumice, scoria, tuff).
• Absorption and Desorption Testing: Includes methods for determining the 72-hour water absorption and the ability of pre-wetted aggregates to release water at relative humidity levels similar to curing environments.
• Chemical and Physical Requirements:
  • Limits on organic impurities, iron staining, and loss on ignition to ensure aggregate quality.
  • Restrictions on clay lumps, friable particles, and specific grading requirements for fine, coarse, and combined aggregates.
  • Maximum dry loose bulk density specifications for different aggregate classes.
• Measurement Units: Stipulates the use of SI and inch-pound units independently; values in each system are not directly interchangeable.
• Safety and Compliance: Outlines the user’s responsibility for safety, health, environmental practices, and compliance with relevant regulations.

Applications

The standard is directly applicable to:

• Concrete Production: Selection and qualification of lightweight aggregate for integration into concrete mixes, particularly where reduced cracking and sustained hydration are desired.
• Quality Assurance: Laboratory and field use of the outlined test methods for verifying aggregate absorption and desorption, ensuring adequate internal curing performance.
• Infrastructure Projects: Infrastructure, bridges, slabs, and mass concrete applications where internal curing enhances durability, reduces thermal gradients, and minimizes shrinkage-induced cracks.
• Preconstruction and Procurement: Guidance for specifying agencies, concrete producers, and contractors in ordering, certifying, and documenting compliance of aggregates used for internal curing.

Related Standards

Standards commonly referenced in conjunction with ASTM C1761/C1761M-23 include:

• ASTM C330/C330M: Specification for lightweight aggregates for structural concrete.
• ASTM C29/C29M: Test method for bulk density and voids in aggregates.
• ASTM C128: Test method for relative density and absorption of fine aggregate.
• ASTM C136/C136M: Sieve analysis of fine and coarse aggregates.
• ASTM C40/C40M & C87/C87M: Methods for assessing the effect of organic impurities on aggregate.
• ASTM C142/C142M: Test for clay lumps and friable particles in aggregates.
• ASTM E11: Standard for test sieve designations.
• ASTM D75/D75M: Practice for sampling aggregates.

Practical Value

ASTM C1761/C1761M-23 provides essential guidelines for ensuring that lightweight aggregates used in internal curing meet rigorous quality and performance criteria. This ensures:

• Enhanced crack resistance and long-term durability in concrete structures.
• Improved predictability and reliability in concrete curing and strength development.
• Standardized sampling, testing, and reporting procedures that benefit producers, contractors, and project owners alike.

Keywords: lightweight aggregate, internal curing, concrete hydration, ASTM C1761, absorption, desorption, concrete aggregate standards, shrinkage reduction.

Standards Content (Sample)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: C1761/C1761M − 23
Standard Specification for
Lightweight Aggregate for Internal Curing of Concrete
This standard is issued under the fixed designation C1761/C1761M; the number immediately following the designation indicates the
year of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last
reapproval. A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope* 2. Referenced Documents
2.1 ASTM Standards:
1.1 This specification covers lightweight aggregate intended
C29/C29M Test Method for Bulk Density (“Unit Weight”)
to provide water for internal curing of concrete. It includes test
and Voids in Aggregate
methods for determining the absorption and desorption prop-
C40/C40M Test Method for Organic Impurities in Fine
erties of lightweight aggregate.
Aggregates for Concrete
NOTE 1—Internal curing provides an additional source of water to
C87/C87M Test Method for Effect of Organic Impurities in
sustain hydration and substantially reduce the early-age autogenous
Fine Aggregate on Strength of Mortar
shrinkage and self-desiccation that can be significant contributors to
early-age cracking. Appendix X1 provides guidance on calculating the
C114 Test Methods for Chemical Analysis of Hydraulic
quantity of lightweight aggregate for internal curing.
Cement
C125 Terminology Relating to Concrete and Concrete Ag-
1.2 The values stated in either SI units or inch-pound units
gregates
are to be regarded separately as standard. The values stated in
C128 Test Method for Relative Density (Specific Gravity)
each system may not be exact equivalents; therefore, each
and Absorption of Fine Aggregate
system shall be used independently of the other. Combining
C136/C136M Test Method for Sieve Analysis of Fine and
values from the two systems may result in non-conformance.
Coarse Aggregates
Some values have only SI units because the inch-pound
C142/C142M Test Method for Clay Lumps and Friable
equivalents are not used in practice.
Particles in Aggregates
NOTE 2—Sieve size is identified by its standard designation in Speci-
C330/C330M Specification for Lightweight Aggregates for
fication E11. The alternative designation given in parentheses is for
Structural Concrete
information only and does not represent a different standard sieve size.
C641 Test Method for Iron Staining Materials in Light-
1.3 The text of this specification references notes and
weight Concrete Aggregates
footnotes that provide explanatory material. These notes and
C702/C702M Practice for Reducing Samples of Aggregate
footnotes (excluding those in tables and figures) shall not be
to Testing Size
considered as requirements of the standard.
C1498 Test Method for Hygroscopic Sorption Isotherms of
Building Materials
1.4 This standard does not purport to address all of the
C1608 Test Method for Chemical Shrinkage of Hydraulic
safety concerns, if any, associated with its use. It is the
Cement Paste
responsibility of the user of this standard to establish appro-
C1698 Test Method for Autogenous Strain of Cement Paste
priate safety, health, and environmental practices and deter-
and Mortar
mine the applicability of regulatory limitations prior to use.
D75/D75M Practice for Sampling Aggregates
1.5 This international standard was developed in accor-
D2172/D2172M Test Methods for Quantitative Extraction of
dance with internationally recognized principles on standard-
Asphalt Binder from Asphalt Mixtures
ization established in the Decision on Principles for the
E11 Specification for Woven Wire Test Sieve Cloth and Test
Development of International Standards, Guides and Recom-
Sieves
mendations issued by the World Trade Organization Technical
Barriers to Trade (TBT) Committee.
3. Terminology
3.1 Definitions:
This specification is under the jurisdiction of ASTM Committee C09 on
Concrete and Concrete Aggregates and is the direct responsibility of Subcommittee
C09.21 on Lightweight Aggregates and Concrete. For referenced ASTM standards, visit the ASTM website, www.astm.org, or
Current edition approved June 1, 2023. Published August 2023. Originally contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM
approved in 2012. Last previous edition approved in 2017 as C1761/C1761M – 17. Standards volume information, refer to the standard’s Document Summary page on
DOI: 10.1520/C1761_C1761M-23. the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
