ASTM E1584-23

Standard Test Method for Assay of Nitric Acid

SIGNIFICANCE AND USE
4.1 This test method provides a means for assaying nitric acid, based on total acidity. The concentration of nitric acid is important in many of the uses of nitric acid, including specification compliance and manufacturing control.
SCOPE
1.1 This test method covers determination of the assay of nitric acid by total acidity.
1.2 This test method is suitable for concentrations between approximately 50 % and 70 %, calculated as nitric acid.
1.3 The following applies for the purposes of determining the conformance of the test results using this test method to applicable specifications, results shall be rounded off in accordance with the rounding-off method of Practice E29.
1.4 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use. For specific hazard statements, see Section 8.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 30-Jun-2023
• ICS: 71.060.30 - Acids
• Technical Committee: D16 - Aromatic, Industrial, Specialty and Related Chemicals
• Drafting Committee: D16.10 - Acids

Standards Content (Sample)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: E1584 − 23
Standard Test Method for
1
Assay of Nitric Acid
This standard is issued under the fixed designation E1584; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope* E180 Practice for Determining the Precision of ASTM
Methods for Analysis and Testing of Industrial and Spe-
1.1 This test method covers determination of the assay of
3
cialty Chemicals (Withdrawn 2009)
nitric acid by total acidity.
E200 Practice for Preparation, Standardization, and Storage
1.2 This test method is suitable for concentrations between
of Standard and Reagent Solutions for Chemical Analysis
approximately 50 % and 70 %, calculated as nitric acid.
E300 Practice for Sampling Industrial Chemicals
1.3 The following applies for the purposes of determining
2.2 Other Documents:
the conformance of the test results using this test method to
OSHA Regulations, 29 CFR, paragraphs 1910.1000 and
4
applicable specifications, results shall be rounded off in accor-
1910.1200
dance with the rounding-off method of Practice E29.
3. Summary of Test Method
1.4 The values stated in SI units are to be regarded as
standard. No other units of measurement are included in this
3.1 A weighed sample of acid is diluted in water and titrated
standard.
with 1.0 N sodium hydroxide solution, using phenolphthalein
as the end-point indicator.
1.5 This standard does not purport to address all of the
safety concerns, if any, associated with its use. It is the
4. Significance and Use
responsibility of the user of this standard to establish appro-
priate safety, health, and environmental practices and deter-
4.1 This test method provides a means for assaying nitric
mine the applicability of regulatory limitations prior to use.
acid, based on total acidity. The concentration of nitric acid is
For specific hazard statements, see Section 8.
important in many of the uses of nitric acid, including
1.6 This international standard was developed in accor-
specification compliance and manufacturing control.
dance with internationally recognized principles on standard-
ization established in the Decision on Principles for the 5. Interferences
Development of International Standards, Guides and Recom-
5.1 Acids other than nitric, and compounds that consume
mendations issued by the World Trade Organization Technical
sodium hydroxide, will yield erroneously high results.
Barriers to Trade (TBT) Committee.
6. Apparatus
2. Referenced Documents
6.1 Erlenmeyer Flask, 250 mL, glass stoppered.
2
2.1 ASTM Standards:
6.2 Buret, 50 mL, Class A.
E29 Practice for Using Significant Digits in Test Data to
Determine Conformance with Specifications
NOTE 1—A digital buret or automated titrator capable of measuring
D1193 Specification for Reagent Water
volumes to the nearest 0.01 mL may be used in place of a conventional
D6809 Guide for Quality Control and Quality Assurance buret.
Procedures for Aromatic Hydrocarbons and Related Ma-
7. Reagents
terials
7.1 Purity of Reagents—Reagent grade chemicals shall be
used in all tests. Unless otherwise indicated, it is intended that
1
This test method is under the jurisdiction of ASTM Committee D16 on
all reagents conform to the specifications of the Committee on
Aromatic, Industrial, Specialty and Related Chemicals and is the direct responsi-
bility of Subcommittee D16.10 on Acids.
Analytical Reagents of the American Chemical Society where
Current edition approved July 1, 2023. Published July 2023. Originally approved
in 1993. Last previous edition approved in 2017 as E1584 – 17. DOI: 10.1520/
E1584-23.
2 3
For referenced ASTM standards, visit the ASTM website, www.astm.org, or The last approved version of this historical standard is referenced on
contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM www.astm.org.
4
Standards volume information, refer to the standard’s Document Summary page on Available from Superintendent of Documents, U.S. Government Printing
the ASTM website. Office, 732 N. Capitol St. NW, Mail Stop: SDE, Washington, DC 20401.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1 ----------------------
E1584 − 23
5 A
TABLE 1 Sample Size for Assay of Nitric Acid
such specifications are available. Other grades may be used,
HNO , % Sample Size, mL Nominal Weight, g
provided it is first
...

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: E1584 − 17 E1584 − 23
Standard Test Method for
1
Assay of Nitric Acid
This standard is issued under the fixed designation E1584; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This test method covers determination of the assay of nitric acid by total acidity.
1.2 This test method covers determination of the assay of nitric acid by total acidity. This test method is suitable for concentrations
between approximately 5050 % and 70 %, calculated as nitric acid.
1.3 The following applies for the purposes of determining the conformance of the test results using this test method to applicable
specifications, results shall be rounded off in accordance with the rounding-off method of Practice E29.
1.4 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 Review the current Safety Data Sheets (SDS) for detailed information concerning toxicity, first aid procedures, and safety
precautions.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use. Specific precautionary statements are given in For specific hazard statements, see Section 8.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
E29 Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications
D1193 Specification for Reagent Water
D6809 Guide for Quality Control and Quality Assurance Procedures for Aromatic Hydrocarbons and Related Materials
E180 Practice for Determining the Precision of ASTM Methods for Analysis and Testing of Industrial and Specialty Chemicals
3
(Withdrawn 2009)
E200 Practice for Preparation, Standardization, and Storage of Standard and Reagent Solutions for Chemical Analysis
E300 Practice for Sampling Industrial Chemicals
1
This test method is under the jurisdiction of ASTM Committee D16 on Aromatic, Industrial, Specialty and Related Chemicals and is the direct responsibility of
Subcommittee D16.10 on Acids.
Current edition approved June 1, 2017July 1, 2023. Published July 2017July 2023. Originally approved in 1993. Last previous edition approved in 20112017 as
E1584 – 11.E1584 – 17. DOI: 10.1520/E1584-17.10.1520/E1584-23.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
3
The last approved version of this historical standard is referenced on www.astm.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1 ----------------------
E1584 − 23
2.2 Other Documents:
4
OSHA Regulations, 29 CFR, paragraphs 1910.1000 and 1910.1200
3. Summary of Test Method
3.1 A weighed sample of acid is diluted in water and titrated with 1.0 N sodium hydroxide solution, using phenolphthalein as the
end-point indicator.
4. Significance and Use
4.1 This test method provides a means for assaying nitric acid, based on total acidity. The concentration of nitric acid is important
in many of the uses of nitric acid, including specification compliance and manufacturing control.
5. Interferences
5.1 Acids other than nitric, and compounds that consume sodium hydroxide, will yield erroneously high results.
6. Apparatus
6.1 Erlenmeyer Flask, 250 mL, glass stoppered.
6.2 Buret, 50 mL, Class A.
NOTE 1—A digital buret or automated titrator capable of measuring volumes to the nearest 0.01 mL may be used in place of a conventional buret.
7. Reagents
7.1 Purity of Reagents—Reagent grade chemicals shall be used in all tests. Unless otherwise indicated, it is intended
...
