ASTM D3032-21a

Standard Test Methods for Hookup Wire Insulation

ABSTRACT
These test methods detail the standard procedures for testing hookup wire insulations including all components of the insulation system used on single insulated conductors or an assembly of single insulated conductors such as a cable bundle and harness or flat ribbon cable. The insulating materials include not only the primary insulation over the conductor, but also insulating jackets over shielded constructions. The test procedures covered here shall be performed in the conditions or shall determine the properties, as follows: axial stability (longitudinal change) after thermal exposure; bondability to potting compounds; capacitance; cold bend test; concentricity; crush resistance; dielectric breakdown voltage; dimensions; dry-arc tracking; dynamic cut-through; fluid immersion; high temperature shock; insulation-continuity proof tests; insulation resistance; partial discharge (corona) inception and extinction voltage; relative thermal life and temperature index; strip force; surface resistance; tensile properties; vertical flame test; voltage rating of hook-up wire; voltage withstand test; and wet arc-tracking.
SCOPE
1.1 These test methods cover procedures for testing hookup wire.
1.2 For the purposes of these test methods, hookup wire insulation includes all components of the insulation system used on single insulated conductors or an assembly of single insulated conductors such as a cable bundle and harness or flat ribbon cable. The insulating materials include not only the primary insulation over the conductor, but also insulating jackets over shielded constructions.
1.3 These test methods and their locations are as follows:
Section
Axial Stability (Longitudinal Change) After Thermal Exposure
20
Bondability of Insulation to Potting Compounds
18
Capacitance
9 to 11
Cold Bend Test
25
Concentricity
25
Crush Resistance
19
Dielectric Breakdown Voltage
5
Dimensions
14
Dry-arc Tracking
28
Dynamic Cut-through
21
Fluid Immersion
22
High Temperature Shock
23
Insulation-Continuity Proof Tests
12
Insulation Resistance
6
Partial Discharge (Corona) Inception and Extinction Voltage
24
Relative Thermal Life and Temperature Index
13
Strip Force
26
Surface Resistance
26
Tensile Properties
16
Vertical Flame
17
Vertical Flame Test A
18.5
(Test Method D8354)
Vertical Flame Test B
17.6 – 17.11.4
Voltage Rating of Hook-Up Wire
Annex A1
Voltage Withstand Test
8
Wet Arc-tracking
27
1.4 The values stated in SI units are to be regarded as standard. The values given in parentheses after SI units are provided for information only and are not considered standard.
1.5 This standard measures and describes the response of materials, products, or assemblies to heat and flame under controlled conditions, but does not, by itself, incorporate all factors required for fire hazard or fire risk assessment of the materials, products, or assemblies under actual fire conditions.
1.6 Fire testing is inherently hazardous. Adequate safeguards for personnel and property shall be employed in conducting these tests.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use. For specific warning statements, see 17.1.3, 24.4, and Note 18.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Mar-2021
• ICS: 29.060.10 - Wires
• Technical Committee: D09 - Electrical and Electronic Insulating Materials
• Drafting Committee: D09.07 - Electrical Insulating Materials

Relations

• Refers: ASTM D1711-24 - Standard Terminology Relating to Electrical Insulation
• Effective Date: 01-Mar-2024
• Refers: ASTM D1868-20 - Standard Test Method for Detection and Measurement of Partial Discharge (Corona) Pulses in Evaluation of Insulation Systems
• Effective Date: 01-Mar-2020
• Refers: ASTM D149-20 - Standard Test Method for Dielectric Breakdown Voltage and Dielectric Strength of Solid Electrical Insulating Materials at Commercial Power Frequencies
• Effective Date: 01-Jan-2020
• Refers: ASTM D3636-19 - Standard Practice for Sampling and Judging Quality of Solid Electrical Insulating Materials
• Effective Date: 01-Apr-2019
• Refers: ASTM D5032-19 - Standard Practice for Maintaining Constant Relative Humidity by Means of Aqueous Glycerin Solutions
• Effective Date: 01-Mar-2019
• Refers: ASTM D1711-15 - Standard Terminology Relating to Electrical Insulation
• Effective Date: 01-Nov-2015
• Refers: ASTM D1711-14a - Standard Terminology Relating to Electrical Insulation
• Effective Date: 01-Nov-2014
• Refers: ASTM D1711-14 - Standard Terminology Relating to Electrical Insulation
• Effective Date: 01-May-2014
• Refers: ASTM D1711-13 - Standard Terminology Relating to Electrical Insulation
• Effective Date: 01-Nov-2013
• Refers: ASTM D1868-13 - Standard Test Method for Detection and Measurement of Partial Discharge (Corona) Pulses in Evaluation of Insulation Systems
• Effective Date: 01-Nov-2013
• Refers: ASTM E691-13 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-May-2013
• Refers: ASTM D3636-13ae1 - Standard Practice for Sampling and Judging Quality of Solid Electrical Insulating Materials
• Effective Date: 01-Mar-2013
• Refers: ASTM D3636-13a - Standard Practice for Sampling and Judging Quality of Solid Electrical Insulating Materials
• Effective Date: 01-Mar-2013
• Refers: ASTM D3636-13 - Standard Practice for Sampling and Judging Quality of Solid Electrical Insulating Materials
• Effective Date: 01-Jan-2013
• Refers: ASTM E691-11 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-Nov-2011

Overview

ASTM D3032-21a: Standard Test Methods for Hookup Wire Insulation presents comprehensive procedures for evaluating the performance and integrity of insulation materials used in single insulated conductors, cable bundles, cable harnesses, and flat ribbon cables. Authored by ASTM International, this standard is critical for industries relying on hookup wire insulation in electrical and electronic applications. It encompasses testing not only the primary insulation over conductors but also insulating jackets over shielded wire constructions, ensuring safety, reliability, and compliance across a wide array of products and environments.

Key Topics

ASTM D3032-21a outlines an extensive array of test methods to ensure that hookup wire insulation meets rigorous quality and safety requirements. Key areas covered include:

• Thermal and Mechanical Endurance:

  • Axial stability after thermal exposure
  • Cold bend tests
  • Crush resistance
  • High-temperature shock
  • Tensile properties

• Electrical Performance Testing:

  • Dielectric breakdown voltage
  • Capacitance and capacitance unbalance
  • Insulation resistance
  • Partial discharge (corona) inception and extinction voltage
  • Voltage rating and voltage withstand tests
  • Surface resistance

• Chemical and Environmental Resistance:

  • Fluid immersion
  • Bondability to potting compounds

• Flammability and Safety:

  • Vertical flame tests (including Test Methods D8354)
  • Dry-arc and wet arc tracking

• Physical Measurements:

  • Dimensions and concentricity
  • Strip force for insulation removal

Each test in the standard is designed to assess specific properties that affect the service life, reliability, and safety of wiring insulation in various operational contexts.

Applications

ASTM D3032-21a is widely used in the electrical, automotive, aerospace, and electronics industries where the performance of hookup wire insulation is critical. Practical applications include:

• Product Qualification and Compliance: Manufacturers rely on these methods to verify that wire insulation fulfills essential quality requirements and regulatory standards.
• Quality Control during Production: The standard enables routine batch testing to detect defects, maintain consistency, and prevent costly failures.
• Design Verification: Engineers and designers use the test results to select appropriate insulation systems that will perform under expected mechanical, thermal, electrical, and environmental stress.
• Safety Assessments: The included flame resistance and electrical breakdown tests are vital for ensuring the finished product poses minimal risk in real-world fire or overload conditions.
• Supplier Evaluation: Procurement teams use adherence to ASTM D3032-21a as a criterion for supplier selection and incoming product inspection.

Related Standards

ASTM D3032-21a references and aligns with several internationally recognized standards, providing a coordinated approach to wire insulation testing. Notable related standards include:

• ASTM D149: Dielectric Breakdown Voltage and Dielectric Strength
• ASTM D150: AC Loss Characteristics and Permittivity of Solid Electrical Insulation
• ASTM D257: DC Resistance or Conductance of Insulating Materials
• ASTM D471: Effect of Liquids on Rubber Properties
• ASTM D638: Tensile Properties of Plastics
• ASTM D8354: Flammability of Electrical Insulating Materials for Wires or Cables
• IEEE 98 and 101: Guides for Thermal Evaluation of Electrical Insulating Materials

Utilizing ASTM D3032-21a in conjunction with these standards supports comprehensive validation of insulation system performance, helping maintain global best practices in the assessment of electrical wire and cable products.

Keywords: ASTM D3032-21a, hookup wire insulation, wire insulation testing, dielectric breakdown, flame resistance, electrical insulation, quality control, cable harness, ribbon cable, insulation resistance, capacitance testing, ASTM standards.
