Petroleum measurement systems - Part 2: Pipe prover design, calibration and operation (ISO 7278-2:2022)

This document provides descriptions of the different types of pipe provers, otherwise known as displacement provers, currently in use. These include sphere (ball) provers and piston provers operating in unidirectional and bidirectional forms. It applies to provers operated in conventional, reduced volume, and small volume modes.
This document gives guidelines for:
—    the design of pipe provers of each type;
—    the calibration methods;
—    the installation and use of pipe provers of each type;
—    the interaction between pipe provers and different types of flowmeters;
—    the calculations used to derive the volumes of liquid measured (see Annex A);
—    the expected acceptance criteria for fiscal and custody transfer applications, given as guidance for both the calibration of pipe provers and when proving flowmeters (see Annex C).
This document is applicable to the use of pipe provers for crude oils and light hydrocarbon products which are liquid at ambient conditions. The principles apply across applications for a wider range of liquids, including water. The principles also apply for low vapour pressure, chilled and cryogenic products, however use with these products can require additional guidance.

Mineralölmesssysteme - Teil 2: Auslegung, Kalibrierung und Betrieb von Rohrprüfgeräten (ISO 7278-2:2022)

Dieses Dokument enthält Beschreibungen der verschiedenen zur Zeit verwendeten Arten von Rohrprüfern; diese werden auch als Verdrängungsprüfer bezeichnet. Dazu gehören Kugelprüfer und Kolbenprüfer, die entweder unidirektional oder bidirektional betrieben werden. Es gilt für Prüfer, die in herkömmlicher Weise und in Betriebsarten für reduzierte Volumina sowie kleine Volumina betrieben werden.
Dieses Dokument enthält Leitlinien für:
—   die Auslegung von Rohrprüfern jedes der einzelnen Typen;
—   die Kalibrierverfahren;
—   die Installation und die Verwendung von Rohrprüfern jedes der einzelnen Typen;
—   die Wechselwirkung zwischen Rohrprüfern und verschiedenen Arten von Durchflussmessgeräten;
—   die Berechnungen zur Ableitung der gemessenen Flüssigkeitsvolumina (siehe Anhang A);
—   die für fiskalische und eichpflichtige Verkehrsanwendungen erwarteten Annahmekriterien, angegeben als Leitlinien sowohl für die Kalibrierung von Rohrprüfern als auch für die Prüfung von Durchflussmessgeräten (siehe Anhang C).
Dieses Dokument ist anzuwenden für die Verwendung von Rohrprüfern für Rohöle und leichte Kohlenwasserstoffprodukte, die bei Umgebungsbedingungen flüssig sind. Die hierin angegebenen Grundsätze gelten auch für Anwendungen mit weiteren Flüssigkeiten, einschließlich Wasser. Die Grundsätze gelten auch für Produkte mit niedrigem Dampfdruck sowie gekühlte und tiefkalte Produkte, jedoch kann die Verwendung mit diesen Produkten zusätzliche Leitlinien erfordern.
WARNUNG — Die Anwendung dieses Dokuments kann die Anwendung gefährlicher Stoffe, Arbeitsgänge und Geräte mit sich bringen. Dieses Dokument beansprucht nicht, sämtliche mit seiner Anwendung verbundenen Sicherheitsprobleme zu behandeln. Es liegt in der Verantwortung des Anwenders dieses Dokuments, geeignete Verhaltensregeln zur Sicherheit und Gesundheit festzulegen.

Systèmes de mesurage des produits pétroliers - Partie 2: Conception, étalonnage et fonctionnement des tubes étalons (ISO 7278-2:2022)

Le présent document décrit les différents types de tubes étalons, également appelés “étalons à déplacement”, actuellement utilisés. Cela comprend les tubes étalons à sphère et à piston, fonctionnant de manière unidirectionnelle et bidirectionnelle. Le présent document s'applique aux tubes étalons fonctionnant en mode conventionnel, à volume réduit et à petit volume.
Le présent document fournit des lignes directrices concernant:
—    la conception des tubes étalons de chaque type;
—    les méthodes d'étalonnage;
—    l'installation et l'utilisation des tubes étalons de chaque type;
—    l'interaction entre les tubes étalons et différents types de débitmètres;
—    les calculs utilisés pour obtenir les volumes de liquide mesurés (voir l'Annexe A);
—    les critères d'acceptation attendus pour les applications fiscales et de transactions commerciales, donnés à titre de recommandation, à la fois pour l'étalonnage des tubes étalons et la vérification des débitmètres (voir l'Annexe C).
Le présent document s'applique à l'utilisation de tubes étalons pour le pétrole brut et les produits d'hydrocarbure légers qui sont à l'état liquide dans les conditions ambiantes. Les principes cités s'appliquent à différentes applications ayant recours à un éventail plus large de liquides, y compris l'eau. Ces principes s'appliquent également aux produits à faible pression de vapeur, ainsi qu'aux produits refroidis et cryogéniques. Toutefois, l'utilisation de ces produits peut nécessiter des recommandations supplémentaires.

Merilni sistemi za nafto - 2. del: Načrtovanje, kalibracija in delovanje merilnika cevi (ISO 7278-2:2022)

Ta dokument podaja opise različnih merilnikov cevi (znanih tudi kot merilniki premika), ki so trenutno v uporabi. To vključuje kroglične in batne merilnike z enosmernim oziroma dvosmernim delovanjem. Uporablja se za merilnike, ki delujejo v običajnem načinu, načinu z zmanjšano in majhno prostornino.
Ta dokument podaja smernice za:
– načrtovanje merilnikov cevi posamezne vrste;
– kalibracijske metode;
– namestitev in uporabo merilnikov cevi posamezne vrste;
– medsebojno delovanje merilnikov cevi in različnih vrst merilnikov pretoka;
– izračune, ki se uporabljajo za izpeljavo izmerjene prostornine tekočine (glej dodatek A);
– pričakovane kriterije sprejemljivosti za fiskalni prenos in prenos skrbništva, podane kot smernice za kalibracijo merilnikov cevi in preskušanje merilnikov pretoka (glej dodatek C).
Ta dokument je namenjen za uporabo merilnikov cevi za surovo nafto in izdelke iz lahkega ogljikovodika, ki so pri običajnih okoljskih pogojih v tekočem stanju. Načela se uporabljajo za različne vrste tekočin, vključno z vodo. Prav tako se uporabljajo za izdelke z nizkim parnim tlakom ter ohlajene in kriogene izdelke, vendar so lahko pri takšni uporabi potrebne dodatne smernice.
