This European Standard specifies equipment and procedures for determining the pull-through resistance of plate anchors through thermal insulation products.
Wärmedämmstoffe für das Bauwesen - Bestimmung des Durchzugwiderstandes von Tellerdübeln durch Wärmedämmstoffe
Diese Europäische Norm legt Prüfeinrichtungen und Verfahren zur Bestimmung des Durchzugwiderstands von Tellerdübeln durch Wärmedämmstoffe fest.
Produits isolants thermiques destinés aux applications du bâtiment - Détermination de la résistance au déboutonnage des chevilles à rosace dans les produits isolants thermiques
La présente Norme européenne spécifie les équipements nécessaires et les modes opératoires à suivre pour déterminer la résistance au déboutonnage des chevilles à rosace dans les produits isolants thermiques.
Toplotnoizolacijski proizvodi za uporabo v gradbeništvu - Ugotavljanje odpornosti sider proti potegu skozi toplotnoizolacijske proizvode
Ta evropski standard določa opremo in postopke za ugotavljanje odpornosti sider proti potegu skozi toplotnoizolacijske proizvode.
General Information
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Toplotnoizolacijski proizvodi za uporabo v gradbeništvu - Ugotavljanje odpornosti sider proti potegu skozi toplotnoizolacijske proizvodeWärmedämmstoffe für das Bauwesen - Bestimmung des Durchzugwiderstandes von Tellerdübeln durch WärmedämmstoffeProduits isolants thermiques destinés aux applications du bâtiment - Détermination de la résistance au déboutonnage des chevilles à rosace dans les produits isolants thermiquesThermal insulation products for building applications - Determination of the pull-through resistance of plate anchors through thermal insulation products91.100.60Thermal and sound insulating materialsICS:Ta slovenski standard je istoveten z:EN 16382:2016SIST EN 16382:2017en,fr,de01-januar-2017SIST EN 16382:2017SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16382
October
t r s x ICS
{ sä s r rä x r English Version
Thermal insulation products for building applications æ Determination of the pullæthrough resistance of plate anchors through thermal insulation products Produits isolants thermiques destinés aux applications du bâtiment æ Détermination de la résistance au déboutonnage des chevilles à rosace dans les produits isolants thermiques
Wärmedämmstoffe für das Bauwesen æ Bestimmung des Durchzugwiderstandes von Tellerdübeln durch Wärmedämmstoffe This European Standard was approved by CEN on
x August
t r s xä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s x CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s x u z tã t r s x ESIST EN 16382:2017
Key 1 plate anchor covered with a suitable non-adhesive foil 2 template 3 thermal insulation product 4 suitable device for fixation the anchorage area of the anchor 5 tension plate 6 glue 7 clamp
b width of the square template dp diameter of the anchor plate including additional plates if used ds diameter of the circular recess in the template dz diameter of the tension plate F tensile load tI thickness of the thermal insulation product Figure 1 — Principle of the test arrangement SIST EN 16382:2017
Key F tensile load r distance from the centre of the anchor sleeve to the remotest point of the breaking cone Figure 2 — Schematic presentation of a failure with a breaking cone of the insulation product after pull-through testing
Key r distance from the centre of the anchor sleeve to the remotest point of the breaking cone Figure 3 — Determination of the distance r by a breaking cone 5.1 Glue The glue shall be suitable for the thermal insulation product and for the tension plate (e.g. solvent-free epoxy or polyurethane based). The glue shall not influence the mechanical properties of the insulation product. 5.2 Template The square templates with circular openings shall be rigid. Test results are valid if every distance of the circular recess to the breaking cone is at least 25 mm. SIST EN 16382:2017
a) Test setup for middle area position b) Test setup for joint position
c) Test setup for middle area position with limited width of the thermal insulation product d) Test setup for edge/corner position Key 1 plate anchor covered with a suitable non-adhesive foil 2 template 3 clamp
b width of the square template c distance which defines the anchor setting position edge or corner at the insulation board c may be chosen according to the mounting guidelines of the ETIC system. Figure 4 — Arrangement of the thermal insulation product in the test setup 6.2 Preparation of the test specimens The plate anchor shall be placed according 6.1. In case of test setups according Figure 4, b), c) and d), the insulation boards shall be secured together on the edges with a suitable circumferential adhesive tape, to counter a movement of the boards in horizontal direction. If the anchor is fixed in a concrete slab, a concrete slab with a minimum strength corresponding to class C20/25 according to EN 206 shall be used (see Figure 6). The spacer to the thermal insulation product shall be equivalent to the thickness of the lower template plus the clamps. The anchor shall be installed SIST EN 16382:2017
...
