(Main)Resistance welding equipment - Water-cooled secondary connection cables(ISO 8205:2021)
Resistance welding equipment - Water-cooled secondary connection cables(ISO 8205:2021)
This document gives specifications for single- and double-conductor secondary connection cables used for resistance welding and allied processes. These specifications include requirements for electrical, mechanical and cooling characteristics of the cables and their test procedures.
Widerstandsschweißeinrichtungen - Wassergekühlte Sekundäranschlusskabel (ISO 8205:2021)
Dieses Dokument enthält Festlegungen für Einleiter- und Zweileiter-Sekundäranschlusskabel, wie sie für die Widerstandsschweißtechnik und verwandte Verfahren benutzt werden. Diese Festlegungen umfassen Anfor¬derungen an die elektrischen und mechanischen Eigenschaften und die Kühlung für die Kabel sowie an deren Prüfverfahren.
Matériel de soudage par résistance - Câbles secondaires refroidis par eau (ISO 8205:2021)
Le présent document fournit des spécifications pour les câbles secondaires à un conducteur ou à deux conducteurs utilisés en soudage par résistance et techniques connexes. Ces spécifications incluent les exigences relatives aux caractéristiques électriques, mécaniques et de refroidissement de ces câbles ainsi que leurs procédures d'essai.
