EN ISO 20182:2008
(Main)Refractory test-piece preparation - Gunning refractory panels by the pneumatic-nozzle mixing type guns (ISO 20182:2008)
Refractory test-piece preparation - Gunning refractory panels by the pneumatic-nozzle mixing type guns (ISO 20182:2008)
ISO 20182:2008 describes the procedure for the preparation of test panels from refractory materials by gunning through pneumatic-nozzle mixing type guns at ambient temperatures.
ISO 20182:2008 does not apply to plastic gunning mixes, and might not apply to those mixes that contain aggregates that are susceptible to hydration.
It also does not apply to shotcrete type mixes.
Probenvorbereitung feuerfester Erzeugnisse - Probenvorbereitung feuerfester Spritzmassen mittels pneumatischer Spritzmaschinen (ISO 20182:2008)
Diese Internationale Norm legt die Verfahrensweise für die Probenvorbereitung von Spritzmassen aus feuerfesten Werkstoffen mittels Spritzmaschinen bei Umgebungstemperaturen fest.
ANMERKUNG Die Werte für die Probekörper aus der nach diesem Verfahren vorbereiteten Spritzmasse stimmen möglicherweise nicht mit den Werten von Probekörpern aus derselben Masse, die auf einer Baustelle vorbereitet wurde, überein.
Diese Internationale Norm gilt nicht für plastische Spritzmassen und möglicherweise nicht für Gemische, die hydratationsempfindliche Zuschlagstoffe enthalten.
Sie gilt darüber hinaus nicht für Spritzbeton-Gemische
Préparation d'éprouvettes réfractaires - Panneaux réfractaires pour gunitage au pistolet mélangeur pneumatique (ISO 20182:2008)
L'ISO 20182:2008 spécifie le mode de préparation de panneaux d'essai en matériaux réfractaires, par gunitage au moyen d'un pistolet mélangeur pneumatique, à température ambiante.
L'ISO 20182:2008 n'est pas applicable aux mélanges plastiques gunitables et peut ne pas être applicable aux mélanges qui contiennent des granulats susceptibles de s'hydrater.
Elle ne s'applique pas non plus aux mélanges de type béton projeté.
Priprava vzorcev ognjevzdržnih izdelkov za preskus - Nanašanje ognjevzdržnih plošč/preskušancev s pnevmatsko brizgalno pištolo (ISO 20182:2008)
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-junij-2008
3ULSUDYDY]RUFHYRJQMHY]GUåQLKL]GHONRY]DSUHVNXV1DQDãDQMHRJQMHY]GUåQLK
SORãþSUHVNXãDQFHYVSQHYPDWVNREUL]JDOQRSLãWROR ,62
Refractory test piece preparation - Gunning refractory panels by the pneumatic-nozzle
mixing type guns (ISO 20182:2008)
Probenvorbereitung feuerfester Erzeugnisse - Probenvorbereitung feuerfester
Spritzmassen mittels pneumatischer Spritzmaschinen (ISO 20182:2008)
Préparation d'éprouvettes réfractaires - Panneaux réfractaires pour gunitage au pistolet
mélangeur pneumatique (ISO 20182:2008)
Ta slovenski standard je istoveten z: EN ISO 20182:2008
ICS:
81.080 Ognjevzdržni materiali Refractories
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EUROPEAN STANDARD
EN ISO 20182
NORME EUROPÉENNE
EUROPÄISCHE NORM
January 2008
ICS 81.080
English Version
Refractory test-piece preparation - Gunning refractory panels by
the pneumatic-nozzle mixing type guns (ISO 20182:2008)
Préparation d'éprouvettes réfractaires - Panneaux Probenvorbereitung feuerfester Erzeugnisse -
réfractaires pour gunitage au pistolet mélangeur Probenvorbereitung feuerfester Spritzmassen mittels
pneumatique (ISO 20182:2008) pneumatischer Spritzmaschinen (ISO 20182:2008)
This European Standard was approved by CEN on 12 January 2008.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European
Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national
standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the
official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,
France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,
Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36 B-1050 Brussels
© 2008 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN ISO 20182:2008: E
worldwide for CEN national Members.
Contents Page
Foreword.3
Foreword
This document (EN ISO 20182:2008) has been prepared by Technical Committee ISO/TC 33 "Refractories" in
collaboration with Technical Committee CEN/TC 187 "Refractory products and materials", the secretariat of
which is held by BSI.
This European Standard shall be given the status of a national standard, either by publication of an identical
text or by endorsement, at the latest by July 2008, and conflicting national standards shall be withdrawn at the
latest by July 2008.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights.
According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following
countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech
Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain,
Sweden, Switzerland and the United Kingdom.
Endorsement notice
The text of ISO 20182:2008 has been approved by CEN as a EN ISO 20182:2008 without any modification.
INTERNATIONAL ISO
STANDARD 20182
Second edition
2008-01-15
Refractory test-piece preparation —
Gunning refractory panels by the
pneumatic-nozzle mixing type guns
Préparation d'éprouvettes réfractaires — Panneaux réfractaires pour
gunitage au pistolet mélangeur pneumatique
Reference number
ISO 20182:2008(E)
©
ISO 2008
ISO 20182:2008(E)
PDF disclaimer
This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but
shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In
downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat
accepts no liability in this area.
Adobe is a trademark of Adobe Systems Incorporated.
Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation
parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In
the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
© ISO 2008
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or
ISO's member body in the country of the requester.
ISO copyright office
Case postale 56 • CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail copyright@iso.org
Web www.iso.org
Published in Switzerland
ii © ISO 2008 – All rights reserved
ISO 20182:2008(E)
Contents Page
Foreword. iv
1 Scope .1
2 Normative references .1
3 Terms and definitions .1
4 Principle.2
5 Precision.2
6 Apparatus .2
7 Sampling.3
8 Procedure .3
9 Test report .5
Annex A (informative) Determination of total water content and rebound .6
ISO 20182:2008(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies
(ISO member bodies). The work of preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which a technical committee has been
established has the right to be represented on that committee. International organizations, governmental and
non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the
International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2.
The main task of technical committees is to prepare International Standards. Draft International Standards
adopted by the technical committees are circulated to the member bodies for voting. Publication as an
International Standard requires approval by at least 75 % of the member bodies casting a vote.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. ISO shall not be held responsible for identifying any or all such patent rights.
ISO 20182 was prepared by Technical Committee ISO/TC 33, Refractories in collaboration with Technical
Committee CEN/TC 187, Rerfractory products and materials.
This second edition cancels and replaces the first edition (ISO 20182:2005), which has been technically
revised as follows:
⎯ in 6.5, two acceptable support plates are now specified;
⎯ in Clause 8, pH determination has been added in place of water hardness testing and predamping
percentages are now given for both dense and insulating castables;
⎯ in Clause 9 test report item c), the water pH, if determined, replaces the water hardness;
⎯ in Clause 9 test report item d), by agreement between the interested parties, the total water content and
rebound are measured and recorded.
Annex A has been added, giving procedures for the determination of the total water content and rebound.
iv © ISO 2008 – All rights reserved
INTERNATIONAL STANDARD ISO 20182:2008(E)
Refractory test-piece preparation — Gunning refractory panels
by the pneumatic-nozzle mixing type guns
WARNING — This International Standard may involve the use of hazardous materials, operations and
equipment. It does not attempt to address the safety problems associated with its use. It is the
responsibility of the user of this International Standard to establish appropriate safety and health
practices, and to determine the applicability of regulatory limitations prior to use.
1 Scope
This International Standard describes the procedure for the preparation of test panels from refractory
materials by gunning through pneumatic-nozzle mixing type guns at ambient temperatures.
NOTE The values obtained from test pieces cut from the panel prepared using this method might not correspond with
those obtained from test pieces of the same material prepared at a gunning installation site.
This International Standard does not apply to plastic gunning mixes, and might not apply to those mixes that
contain aggregates that are susceptible to hydration.
It also does not apply to shotcrete type mixes.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 836, Refractories — Vocabulary
ISO 8656-1, Refractory products — Sampling of raw materials and unshaped products — Part 1: Sampling
scheme
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 836 and the following apply.
3.1
gun
assembly essentially comprising a chamber into which the refractory is added, together with a mechanism that
controls the flow of the material through the unit
NOTE Depending on the type used, the gun may be open at the top, or a closed pressurized unit may be used.
3.2
rebound material
material that fails to adhere to the surface when being sprayed, and ricochets out of the immediate area
ISO 20182:2008(E)
4 Principle
Refractory material is conveyed pneumatically in either a dry or predampened form to the test site, using
equipment of the nozzle mixing type. Then water is introduced to the refractory mix at the nozzle and the
mixture is projected onto a support plate (see 6.5).
5 Precision
Differences between various types of equipment and in operator techniques may result in variations in the
physical properties of the gunned specimens. For referee testing, it is desirable that the same operator should
use the same equipment to produce test specimens.
6 Apparatus
6.1 Gun, of the pneumatic-nozzle mixing type.
6.2 Air compressor, capable of supplying a steady airflow at the required pressure and volume.
6.3 Mixer, for use when predamping is carried out. The mixer shall be capable of producing a
homogeneous mixture of the material to be tested.
6.4 Hose/nozzle assembly, comprising a reinforced pneumatic hose and a nozzle assembly suitable for
the material being gunned.
6.5 Gunned-material support plate, flat, capable of producing a panel having minimum usable
dimensions of 280 mm × 280 mm × 100 mm thickness that is suitable for the tests intended to be carried out,
after allowance for any material to be cut off as described in Clause 8. The preferred support plate has ledges
at both sides and the top edge. An example of the preferred support plate is given in Figure 1a).
An alternative support plate may be used, 300 mm to 500 mm in length, and having a bottom support edge
100 mm in width and of the same overall length as the support plate. An example of the alternative support
plate is given in Figure 1b).
The support plate may be made of wood or steel and shall not flex during use. The support plate may be
larger than the minimum panel size, to allow the edges to be removed from the gunned panel, for example, to
remove trapped rebound material at the bottom, and other edge effects.
Interested parties shall agree which type of panel is used. The test report shall state the dimensions of the
gunned-material support plate and panel produced, and the type of panel used.
6.6 Air pressure gauge, capable of measuring pressures up to 690 kPa, plus or minus 5 % at all
pressures.
6.7 Water-measuri
...
