EN 13775-1:2003

Railway applications - Measuring of new and modified freight wagons - Part 1: Measuring principles

This European Standard specifies requirements for measuring freight wagons and bogies. This ensures that the measuring methods are applied in accordance with uniform criteria. It applies to new and modified freight wagons and bogies. Provisions going beyond the scope of these requirements should be agreed upon by the contracting parties involved.
The measuring methods relate to the whole or parts of the underframes with or without add-ons if the geometrical structure does not permit anything else. Where appropriate, other measuring methods not specified here are necessary and should be specified in each individual case. This applies as appropriate to bogies.

Bahnanwendungen - Vermessung von Güterwagen beim Neubau und bei Umbauten - Teil 1: Meßgrundsätze

In dieser Europäischen Norm sind die Anforderungen für das Vermessen von Güterwagen und Drehgestellen festgelegt. Durch diese wird sichergestellt, daß Meßvorgänge nach einheitlichen Kriterien ausgeführt werden. Sie gilt für neue und umgebaute Güterwagen oder Drehgestelle. Über diese Anforderungen dieser Norm hinausgehende Forderungen sind zwischen den Vertragspartnern zu vereinbaren. Durch das Vermessen ist festzustellen, ob die Abweichungen von den Nennmaßen innerhalb der in den Teilen 2 bis 6 dieser Normenreihe festgelegten Toleranzen liegen.

Applications ferroviaires - Mesure des wagons lors de leur construction et lors de modifications - Partie 1: Principes de mesure

La présente norme européenne précise les exigences concernant les mesures des wagons et des bogies, qui assurent que les opérations de mesure sont effectuées en fonction de critères unifiés. Elle est applicable aux wagons et aux bogies neufs et modifiés. Les exigences allant au-delà de ladite norme doivent faire l'objet d'une convention particulière entre contractants. Les mesures doivent garantir que les écarts par rapport aux cotes nominales ne dépassent pas les tolérances fixées dans les parties 2 à 6 de la présente série.

Železniške naprave – Merjenje novih in predelanih tovornih vagonov – 1.del: Načela za izvajanje meritev

General Information

• Status: Published
• Publication Date: 17-Jun-2003
• ICS: 45.060.20 - Trailing stock
• Technical Committee: CEN/TC 256 - Railway applications
• Drafting Committee: CEN/TC 256/WG 26 - Freight wagons
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 13-Jun-2022
• Completion Date: 14-Apr-2025
• Directive: 93/38/EEC - Procurement procedures of entities operating in the water, energy, transport and telecommunications sectors
• Mandate: M/024 - Mandate to CEN/CENELEC/ETSI for programming and standardization in the field of railway equipment
• Ref Project: SIST EN 13775-1:2004 - Railway applications - Measuring of new and modified freight wagons - Part 1: Measuring principles

Overview

EN 13775-1:2003 is a European Standard developed by CEN that establishes uniform measuring principles for new and modified freight wagons and bogies used in railway applications. This standard ensures consistent measurement methods, promoting interoperability and safety across European railway networks. It applies to both entire underframes and parts thereof, including add-ons, particularly when geometric configurations restrict other measuring approaches. While this standard sets foundational requirements, any additional measuring provisions must be mutually agreed upon by contracting parties.

Key Topics

• Scope and Applicability:
  EN 13775-1 covers measurement requirements for new and modified freight wagons and bogies, providing a baseline for uniform dimensional verification. It focuses on measuring underframes or components, ensuring that operational safety and design integrity are maintained.

• Measurement Conditions and Accuracy:
  Measurements must be conducted on unrestrained components at ambient temperatures between 10 °C and 30 °C (20 °C ± 10 °C) to avoid heat distortion. Measuring equipment with an accuracy of ±0.5 mm is recommended. Calibration and documentation of measurement instruments are essential for maintaining precision.

• Terminology and Definitions:
  The standard defines key terms related to modifications, finished products, original identity, and substantial modifications-clarifying when and how measurement rules apply during changes that affect the wagon’s or bogie’s identity or structural shape.

• Dimensional Designations and Measuring Points:
  Dimensional letters specify directions: x (longitudinal), y (transverse), and z (height). Measuring points are indexed by position along the vehicle, designating left (L) and right (R) sides based on viewing direction from vehicle end 2 to end 1. This systematic approach aids in consistent data recording and analysis.

• Orientation and Direction:
  The standard defines vehicle ends and sides using consistent direction rules:

  • End 1 is the front in the driving direction; End 2 is the rear.
  • Sides are assigned as left (L) or right (R).
  • For freight wagons with hand brakes, the brake is located at End 2.
  • Bogies are similarly oriented based on brake fixed point positions.

Applications

EN 13775-1:2003 is essential for manufacturers, maintenance organizations, and railway operators involved in the construction, modification, and inspection of freight wagons and bogies. Its implementation supports:

• Quality Control: Ensures that all new and modified rolling stock meet dimensional tolerances for safe operation.
• Interoperability: Standardized measurement allows wagons to be used seamlessly across different European railway networks.
• Regulatory Compliance: Helps satisfy national and international inspection requirements for freight wagons.
• Design Verification: Facilitates evaluation of modifications related to wagon purpose or structural changes.
• Documentation: Provides a basis for clear measurement records supporting certification and approval processes.

Related Standards

This standard is part of the EN 13775 series related to measuring freight wagons and bogies:

• EN 13775-2: Measuring freight wagons with bogies
• EN 13775-3: Measuring freight wagons with 2 wheelsets
• prEN 13775-4: Measuring bogies with 2 wheelsets
• prEN 13775-5: Measuring bogies with 3 wheelsets
• prEN 13775-6: Measuring tight-coupled freight wagons

These complementary standards provide specific measurement methods adapted to different wagon and bogie configurations. Users should apply EN 13775-1 principles as a foundation and refer to these parts for detailed measurement procedures relevant to their vehicle type.

---

By adhering to EN 13775-1:2003, stakeholders in rail freight transport achieve consistent, reliable measurement practices that underpin the safety, functionality, and interoperability of European freight wagons and bogies. This harmonization is critical in supporting efficient cross-border railway operations and lifecycle management of rolling stock.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bahnanwendungen - Vermessung von Güterwagen beim Neubau und bei Umbauten - Teil 1: MeßgrundsätzeApplications ferroviaires - Mesure des wagons lors de leur construction et lors de modifications - Partie 1: Principes de mesureRailway applications - Measuring of new and modified freight wagons - Part 1: Measuring principles45.060.20Železniški vagoniTrailing stockICS:Ta slovenski standard je istoveten z:EN 13775-1:2003SIST EN 13775-1:2004en01-junij-2004SIST EN 13775-1:2004SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13775-1June 2003ICS 45.060.20English versionRailway applications - Measuring of new and modified freightwagons - Part 1: Measuring principlesApplications ferroviaires - Mesure des wagons lors de leurconstruction et lors de modifications - Partie 1: Principes demesureBahnanwendungen - Vermessung von Güterwagen beimNeubau und bei Umbauten - Teil 1: MeßgrundsätzeThis European Standard was approved by CEN on 14 February 2003.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Management Centre has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece,Hungary, Iceland, Ireland, Italy, Luxembourg, Malta, Netherlands, Norway, Portugal, Slovakia, Spain, Sweden, Switzerland and UnitedKingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2003 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13775-1:2003 ESIST EN 13775-1:2004
...
