EN 60332-1-2:2004/A12:2020

Tests on electric and optical fibre cables under fire conditions - Part 1-2: Test for vertical flame propagation for a single insulated wire or cable - Procedure for 1 kW pre-mixed flame

This standard specifies the procedure for testing the resistance to vertical flame propagation for a single vertical electrical insulated conductor or cable, or optical fibre cable, under fire conditions.

Prüfungen an Kabeln, isolierten Leitungen und Glasfaserkabeln im Brandfall - Teil 1-2: Prüfung der vertikalen Flammenausbreitung an einer Ader, einer isolierten Leitung oder einem Kabel - Prüfverfahren mit 1 kW-Flamme mit Gas-/Luft-Gemisch

Essais des câbles électriques et à fibres optiques soumis au feu - Partie 1-2: Essai de propagation verticale de la flamme sur conducteur ou câble isolé - Procédure pour flamme à prémélange de 1kW

Preskusi na električnih kablih in kablih iz optičnih vlaken v požarnih razmerah - 1-2. del: Preskus navpičnega širjenja ognja po posamezni izolirani žici ali kablu - Postopek za predmešani plamen 1 kW - Dopolnilo A12

General Information

• Status: Published
• Publication Date: 03-Dec-2020
• ICS: 13.220.40 - Ignitability and burning behaviour of materials and products
• ICS: 29.020 - Electrical engineering in general
• ICS: 29.060.20 - Cables
• Technical Committee: CLC/TC 20 - Electric cables
• Drafting Committee: CLC/TC 20 - Electric cables
• Current Stage: 6060 - Document made available - Publishing
• Start Date: 04-Dec-2020
• Due Date: 01-May-2022
• Completion Date: 04-Dec-2020
• Ref Project: SIST EN 60332-1-2:2005/A12:2021 - Tests on electric and optical fibre cables under fire conditions - Part 1-2: Test for vertical flame propagation for a single insulated wire or cable - Procedure for 1 kW pre-mixed flame

Relations

• Amends: EN 60332-1-2:2004 - Tests on electric and optical fibre cables under fire conditions - Part 1-2: Test for vertical flame propagation for a single insulated wire or cable - Procedure for 1 kW pre-mixed flame
• Effective Date: 24-Sep-2019
• Revised: EN 60332-1-2:2004/A11:2016 - Tests on electric and optical fibre cables under fire conditions - Part 1-2: Test for vertical flame propagation for a single insulated wire or cable - Procedure for 1 kW pre-mixed flame
• Effective Date: 24-Sep-2019

Overview

EN 60332-1-2:2004/A12:2020 is a CLC/CENELEC amendment to the EN 60332-1-2 series describing a standardized fire test for vertical flame propagation on a single insulated electrical conductor, cable, or optical fibre cable. The procedure uses a 1 kW pre‑mixed (gas/air) flame to assess a specimen’s tendency to ignite and sustain vertical flame propagation under controlled laboratory conditions. Amendment A12 (approved 2020-11-05) updates mounting and positioning requirements to ensure valid and repeatable results.

Key Topics and Requirements

• Scope: Procedure for testing resistance to vertical flame propagation of a single vertical insulated wire, cable, or optical fibre cable using a 1 kW pre‑mixed flame.
• Test flame application: Use of a pre‑mixed gas/air flame with a defined impingement point (the “blue cone”) on the test piece.
• Positioning of test piece: The test is valid only if the specimen remains in the test flame for the whole test. Amendment A12 adds provisions when the specimen moves out of the flame (for example due to breaking at the flame impact point).
• Optional securing loops (A12):
  • Use 1 mm diameter metal wire loops applied around the test piece if it moves out of the flame.
  • Place loops approximately 50 mm below and 50 mm and 150 mm above the blue cone impingement position.
  • Attach loops to the metallic enclosure side walls or to a vertical rod/rail at the back; at test start, loops must not touch the specimen.
  • Inner diameter of loops must exceed the cable diameter by at least 4.0 mm.
• Documentation and figures: Figure 2 (application of flame to test piece) is replaced to reflect the optional securing loops and updated geometry.

Applications and Users

This standard is widely used by:

• Cable manufacturers for product development and flammability verification
• Independent testing laboratories undertaking cable fire performance testing
• Specifiers, procurement teams, and compliance officers in construction, transportation, telecommunications and utilities requiring verified cable fire behavior data
• Regulatory bodies and certification organizations assessing compliance with national or sectoral fire-safety requirements

Practical benefits include consistent, repeatable assessment of a single conductor or cable’s vertical flame propagation behavior, helping manufacturers reduce fire risks and enabling purchasers to compare fire performance.

Related Standards

• Other parts of the EN 60332 series covering cable fire performance (vertical and multi‑wire tests)
• National implementations of EN 60332-1-2:2004/A12:2020 by CENELEC members

Keywords: EN 60332-1-2:2004/A12:2020, vertical flame propagation, 1 kW pre-mixed flame, cable flammability test, optical fibre cable, CENELEC, cable fire test.

Standards Content (Sample)

SLOVENSKI STANDARD
01-februar-2021
Preskusi na električnih kablih in kablih iz optičnih vlaken v požarnih razmerah - 1-
2. del: Preskus navpičnega širjenja ognja po posamezni izolirani žici ali kablu -
Postopek za predmešani plamen 1 kW - Dopolnilo A12
Tests on electric and optical fibre cables under fire conditions - Part 1-2: Test for vertical
flame propagation for a single insulated wire or cable - Procedure for 1 kW pre-mixed
flame
Prüfungen an Kabeln, isolierten Leitungen und Glasfaserkabeln im Brandfall - Teil 1-2:
Prüfung der vertikalen Flammenausbreitung an einer Ader, einer isolierten Leitung oder
einem Kabel - Prüfverfahren mit 1 kW-Flamme mit Gas-/Luft-Gemisch
Essais des câbles électriques et à fibres optiques soumis au feu - Partie 1-2: Essai de
propagation verticale de la flamme sur conducteur ou câble isolé - Procédure pour
flamme à prémélange de 1kW
Ta slovenski standard je istoveten z: EN 60332-1-2:2004/A12:2020
ICS:
13.220.40 Sposobnost vžiga in Ignitability and burning
obnašanje materialov in behaviour of materials and
proizvodov pri gorenju products
29.060.20 Kabli Cables
33.180.10 (Optična) vlakna in kabli Fibres and cables
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD EN 60332-1-2:2004/A12

NORME EUROPÉENNE
EUROPÄISCHE NORM
December 2020
ICS 13.220.40; 29.020; 29.060.20

English Version
Tests on electric and optical fibre cables under fire conditions -
Part 1-2: Test for vertical flame propagation for a single insulated
wire or cable - Procedure for 1 kW pre-mixed flame
Essais des câbles électriques et à fibres optiques soumis Prüfungen an Kabeln, isolierten Leitungen und
au feu - Partie 1-2: Essai de propagation verticale de la Glasfaserkabeln im Brandfall - Teil 1-2: Prüfung der
flamme sur conducteur ou câble isolé - Procédure pour vertikalen Flammenausbreitung an einer Ader, einer
flamme à prémélange de 1kW isolierten Leitung oder einem Kabel - Prüfverfahren mit 1
kW-Flamme mit Gas-/Luft-Gemisch
This amendment A12 modifies the European Standard EN 60332-1-2:2004; it was approved by CENELEC on 2020-11-05. CENELEC
members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this amendment the
status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This amendment exists in three official versions (English, French, German). A version in any other language made by translation under the
responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the same status as
the official versions.
CENELEC members are the national elec
...
