Fixed capacitors for use in electronic equipment - Part 11: Sectional specification - Fixed polyethylene-terephthalate film dielectric metal foil DC capacitors

IEC 60384-11:2019 is applicable to fixed direct current capacitors, for rated voltages not exceeding 6 300 V, using as dielectric a polyethylene-terephthalate film and electrodes of thin metal foils. For capacitors with rated voltages exceeding 1 000 V, additional tests and requirements may be specified in the detail specification. The capacitors covered by this document are intended for use in electronic equipment. Capacitors for electromagnetic interference suppression are not included, but are covered by IEC 60384‑14. The object of this document is to prescribe preferred ratings and characteristics and to select from IEC 60384-1:2016 the appropriate quality assessment procedures, tests and measuring methods and to give general performance requirements for this type of capacitor. Test severities and requirements prescribed in detail specifications referring to this sectional specification are of an equal or higher performance level. Lower performance levels are not permitted.
This edition includes the following significant technical changes with respect to the previous edition:
a) revision of all parts of the document based on the ISO/IEC Directives, Part 2:2018, and harmonization with other similar kinds of documents;
b) the document structure has been organized to follow new sectional specification structure decided in TC 40;
c) revised tables and Clause 5 so as to prevent duplications and contradictions.
The contents of the corrigendum of April 2020 have been included in this copy.

Condensateurs fixes utilisés dans les équipements électroniques - Partie 11: Spécification intermédiaire - Condensateurs fixes pour courant continu à diélectrique en film de polytéréphtalate d'éthylène à armatures en feuilles métalliques

L'IEC 60384-11:2019 est applicable aux condensateurs fixes pour courant continu, pour des tensions assignées ne dépassant pas 6 300 V, utilisant comme diélectrique un film de polytéréphtalate d'éthylène et des électrodes de feuilles métalliques minces. Pour des condensateurs de tensions assignées ne dépassant pas 1 000 V, d'autres essais et exigences peuvent être indiqués dans la spécification particulière. Les condensateurs couverts par le présent document sont destinés à être utilisés dans des équipements électroniques. Les condensateurs d'antiparasitage ne sont pas inclus, mais ils sont couverts par l'IEC 60384-14. Le présent document a pour objet de prescrire les caractéristiques et les valeurs assignées préférentielles, de sélectionner, en se référant à l'IEC 60384-1:2016, les procédures d'assurance de la qualité, les essais et les méthodes de mesure appropriés et de donner les exigences de performances générales pour ce type de condensateur. Les sévérités et les exigences d'essai prescrites dans les spécifications particulières se rapportant à la présente spécification intermédiaire sont de niveaux de performances supérieurs ou égaux. Des niveaux de performance inférieurs ne sont pas autorisés.
La présente édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) révision de toutes les parties du document en s'appuyant sur les directives ISO/IEC, Partie 2:2018, et harmonisation avec d'autres types de documents similaires;
b) la structure du document a été organisé pour suivre une nouvelle structure de spécification intermédiaire décidée par le comité d'étude 40;
c) révision des tableaux et de l'Article 5 pour éviter les répétitions et les contradictions.
Le contenu du corrigendum d'avril 2020 a été pris en considération dans cet exemplaire.
