Fixed capacitors for use in electronic equipment - Part 16: Sectional specification - Fixed metallized polypropylene film dielectric DC capacitors

IEC 60384-16:2019 applies to fixed capacitors with metallized electrodes and poly­propylene dielectric for use in electronic equipment. These capacitors can have "self-healing properties" depending on conditions of use. They are mainly intended for use with direct voltage.
Capacitors for alternating voltage and pulse applications are not included, but are covered by IEC 60384-17. Capacitors for electromagnetic interference suppression are not included, but are covered by IEC 60384-14. Capacitors for electrical shock hazard protection (covered by IEC 60065) and fluorescent lamp and motor capacitors are also excluded.
The contents of the corrigendum of December 2020 have been included in this copy.

Condensateurs fixes utilisés dans les équipements électroniques - Partie 16: Spécification intermédiaire - Condensateurs fixes pour courant continu à diélectrique en film de polypropylène métallisé

L'IEC 60384-16:2019 s'applique aux condensateurs fixes à électrodes métallisées et à diélectrique en polypropylène destinés aux équipements électroniques. Ces condensateurs peuvent avoir des propriétés "autocicatrisantes" en fonction des conditions d'utilisation. Ils sont principalement destinés à être utilisés dans des applications en tension continue.
Les condensateurs destinés à des applications en tension alternative et en impulsions ne sont pas inclus, mais ils sont couverts par l'IEC 60384-17. Les condensateurs d'antiparasitage ne sont pas inclus, mais ils sont couverts par l'IEC 60384-14. Les condensateurs de protection contre les chocs électriques (couverts par l'IEC 60065), ainsi que les condensateurs pour moteurs et pour lampes fluorescentes sont également exclus.
Le contenu du corrigendum de décembre 2020 a été pris en considération dans cet exemplaire.
