TECHNICAL IEC
REPORT
TR 61010-3-031
First edition
2003-04
Safety requirements for electrical equipment
for measurement, control, and laboratory use –
Part 3-031:
Conformity verification report for
IEC 61010-031:2002 –
Safety requirements for hand-held probe
assemblies for electrical test and measurement
Règles de sécurité pour appareils électriques
de mesurage, de régulation et de laboratoire –
Partie 3-031:
Rapport de vérification de la conformité
de la CEI 61010-031:2002 –
Prescriptions de sécurité pour sondes équipées
tenues à la main pour mesurage et essais électriques

Reference number
IEC/TR 61010-3-031:2003(E)
Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the

60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.

Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,

edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the

base publication incorporating amendment 1 and the base publication incorporating

amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (http://www.iec.ch/searchpub/cur_fut.htm)
enables you to search by a variety of criteria including text searches, technical
committees and date of publication. On-line information is also available on
recently issued publications, withdrawn and replaced publications, as well as
corrigenda.
• IEC Just Published
This summary of recently issued publications (http://www.iec.ch/online_news/
justpub/jp_entry.htm) is also available by email. Please contact the Customer
Service Centre (see below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:
Email: [e-mail]
Tel: [phone]
Fax: [phone]
TECHNICAL IEC
REPORT
TR 61010-3-031
First edition
2003-04
Safety requirements for electrical equipment
for measurement, control, and laboratory use –
Part 3-031:
Conformity verification report for
IEC 61010-031:2002 –
Safety requirements for hand-held probe
assemblies for electrical test and measurement
Règles de sécurité pour appareils électriques
de mesurage, de régulation et de laboratoire –
Partie 3-031:
Rapport de vérification de la conformité
de la CEI 61010-031:2002 –
Prescriptions de sécurité pour sondes équipées
tenues à la main pour mesurage et essais électriques

 IEC 2003  Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: [phone] Telefax: [phone] E-mail: [e-mail]  Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale
U
International Electrotechnical Commission
Международная Электротехническая Комиссия
For price, see current catalogue

– 2 – TR 61010-3-031  IEC:2003(E)

CONTENTS
FOREWORD . 3

Conformity verification report for IEC 61010-031:2002 . .5

5 Marking and documentation .10

6 Protection against electric shock.12

7 Protection against mechanical hazards .14

8 Mechanical resistance to shock and impact .14

9 Temperature limits and protection against the spread of fire .15
10 Resistance to heat .15
11 Protection against hazards from fluids .15
12 Components .15
Table 1 – Documents attached to this report . 7
Table 2 – Test equipment list . 8
Table 3 – List of components and circuits relied on for safety. 9
Form A.1 to Form A.11.16 to 26

TR 61010-3-031  IEC:2003(E) – 3 –

INTERNATIONAL ELECTROTECHNICAL COMMISSION

___________
SAFETY REQUIREMENTS FOR ELECTRICAL EQUIPMENT

FOR MEASUREMENT, CONTROL, AND LABORATORY USE –

Part 3-031: Conformity verification report for IEC 61010-031:2002

Safety requirements for hand-held probe assemblies

for electrical test and measurement

FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International
Organization for Standardization (ISO) in accordance with conditions determined by agreement between the
two organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this Technical Report may be the subject of
patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
The main task of IEC technical committees is to prepare International Standards. However, a
technical committee may propose the publication of a technical report when it has collected
data of a different kind from that which is normally published as an International Standard, for
example “state of the art”.
IEC 61010-3-031, which is a technical report, has been prepared by IEC technical committee
66: Safety of measuring, control, and laboratory equipment.

The text of this technical report is based on the following documents:
Enquiry draft Report on voting
66/276/CDV 66/303/RVC
Full information on the voting for the approval of this technical report can be found in the
report on voting indicated in the above table.
This publication has been drafted in accordance with the IEC/ISO Directives, Part 3.
This report is for use by test houses and other users to assist them with determining and
recording verification of conformity of the equipment under test with the requirements of
IEC 61010-031:2002.
– 4 – TR 61010-3-031  IEC:2003(E)

The protocol for completion of this report is contained in publication IEC 61010-3: 1997.

The IEC sells read-only PDF files as a general rule. In the present instance, and quite

exceptionally, to enable the user to fill in the forms, a revisable file is included in a pocket

affixed to the back cover of this publication.

This file can also be downloaded from the Web as a PDF file. There is, however, at the end

of the document, a revisable file containing the forms. Please use the zip/unzip function.

The committee has decided that the contents of this publication will remain unchanged until

2006. At this date, the publication will be
• reconfirmed;
• withdrawn;
• replaced by a revised edition, or
• amended.
TR 61010-3-031  IEC:2003(E) – 5 –

Conformity Verification Report

IEC 61010-3-031:
Safety requirements for electrical equipment for measurement, control, and laboratory use

Safety requirements for hand-held PROBE ASSEMBLIES for electrical test and measurement

Report reference No.:

Compiled by (+ signature).:

Approved by (+ signature).:

Date of issue.:
Testing organization.:
Address.:
Testing location .:
Applicant.:
Address.:
Standard.: IEC 61010-031:2002
Copyright blank test report.: This report has been prepared by IEC TC 66, which retains responsibility
for any changes or corrections required.
Test procedure.:
Procedure deviation.:
Non-standard test method.:
Type of item tested.:  Measurement

Trade mark.:
Model/type reference.:
Manufacturer.:
Rating.:
Copy of rating plate:
– 6 – TR 61010-3-031  IEC:2003(E)

Description of equipment function.:

INSTALLATION/OVERVOLTAGE CATEGORY.:

POLLUTION DEGREE:
Environmental rating: � Standard � Other (specify):

Equipment mobility: � Hand-held � Fixed
Operating conditions: � Continuous � Short-time � Intermittent
Marked degree of protection to IEC 60529:  IP___  ___
Accessories and detachable parts included in the evaluation:
Options:
NOTE – "(see Form A.X)" refers to a form appended to the report.

TR 61010-3-031  IEC:2003(E) – 7 –

Table 1 – Documents attached to this report

Document No. Document description Number of

pages
– 8 – TR 61010-3-031  IEC:2003(E)

Table 2 – Test equipment list
Calibration date
Type and Equipment
Item Comments
make No.
1)
Last Due
1)
or interval between calibrations.

TR 61010-3-031  IEC:2003(E)        – 9 –

Table 3 – List of components and circuits relied on for safety
Unique component Licence number,
reference or location Manufacturer and part number RATING file number or other
Application/Function Verdict
(including drawing (NOTE 1) (NOTE 2) documentary evidence
reference if required) of acceptance
NOTE 1 List all manufacturers concerned.
NOTE 2 Electrical, mechanical, flammability, etc.

– 10 – TR 61010-3-031  IEC:2003(E)

Cl. Requirement - Test Result - Remarks Verdict

5 MARKING AND DOCUMENTATION
5.1.1 General
Required  markings are:
- not put on parts which can be removed by an

OPERATOR
Letter symbols (IEC 60027) used

Graphic symbols used
symbol 10 used (see 5.4.1)
5.1.2 Identification
PROBE ASSEMBLY and its separate parts are
identified by:
5.1.2a) Manufacturer’s or supplier’s name or trademark
5.1.2b) For type B & C only:
- model number
- model name
- other means of identification
If designed for use only with a specific model of
equipment:
- clearly identified
- specific equipment or model marked on
assembly and included in documentation
5.1.3 Fuses
OPERATOR replaceable fuses – PROBE ASSEMBLY
marked with all details including:
- voltage RATING
- breaking capacity
If fuse selection for a particular application:
- symbol 10 on PROBE ASSEMBLY (see also
5.4.4)
- information in documentation
5.1.4 TERMINALS and operating devices
Where necessary for safety, indication of
purpose of TERMINALS, connectors and controls
marked and sequence of operations

5.1.5 Parts protected by DOUBLE INSULATION or
REINFORCED INSULATION
Protected throughout - symbol 7 used
Only partially protected - symbol 7 not used
5.1.6 RATING
PROBE ASSEMBLY RATING marked:
5.1.6a) For measurements within measurement category
I:
- RATED voltage-to-earth
- symbol 10
TR 61010-3-031 IEC:2003(E) – 11 –

Cl. Requirement - Test Result - Remarks Verdict

5.1.6b) For measurements within measurement category

II, III and IV:
- RATED voltage-to-earth
- relevant measurement category

Markings on PROBE ASSEMBLY:
- nature of voltage
- voltage RATING of REFERENCE CONNECTOR

For type A PROBE ASSEMBLIES only, markings
include:
- RATED current
- maximum RATED circuit -to-earth voltage
5.2 Warning markings
Visible when ready for NORMAL USE
Are near or on particular part
If necessary marked with symbol 10
Sta
...
