ISO/IEC TR 11801-9907:2019

Information technology - Generic cabling for customer premises - Part 9907: Specifications for direct attach cabling

ISO/IEC TR 11801-9907:2019(E), which is a Technical Report, provides definitions for, and examples of, direct attach cabling configurations. This document provides performance specifications for Classes D, E, EA, F, FA, I and II direct attach cabling by reference to ISO/IEC 11801-1. Informative limits for Class I direct attach cabling to support 5 m short reach mode application according to ISO/IEC/IEEE 8802 3:2017/AMD3, i.e. 25GBASE-T and 40GBASE-T, are provided in Annex A. Test methods will be provided in the second edition of ISO/IEC 14763-4. Direct attach cabling connects two pieces of equipment, it has connectors at each end, and no intermediate connecting hardware.

General Information

• Status: Published
• Publication Date: 15-Jul-2019
• ICS: 35.200 - Interface and interconnection equipment
• Technical Committee: ISO/IEC JTC 1/SC 25 - Interconnection of information technology equipment
• Current Stage: PPUB - Publication issued
• Start Date: 16-Jul-2019
• Completion Date: 21-Aug-2019

Overview

ISO/IEC TR 11801-9907:2019 is a Technical Report that defines and specifies direct attach cabling for customer premises as part of the ISO/IEC 11801 generic cabling family. It describes direct-attach configurations (cables with connectors at both ends and no intermediate connecting hardware) and provides performance specifications for Classes D, E, EA, F, FA, I and II by reference to ISO/IEC 11801-1. The report is informative and intended to help designers, manufacturers and installers verify direct-attach assemblies and their ability to support modern link applications.

Key Topics

• Definitions and configurations for direct attach cabling (connectorized cable assemblies connecting two pieces of equipment).
• Performance specifications (Clause 6) referenced to ISO/IEC 11801-1, including parameters such as:
  • Return loss and insertion loss
  • NEXT / PS NEXT and ACR-N / PS ACR-N
  • ACR-F / PS ACR-F, TCL, ELTCTL
  • Coupling attenuation and alien crosstalk
  • DC loop resistance and pair resistance unbalance
  • Propagation delay and delay skew
• Testing regimes for reference and installation performance (reference to test regimes and Table 1) and guidance on installation performance verification.
• Annex A (informative): provides short-reach Class I limits to support 5 m short-reach mode applications (per ISO/IEC/IEEE 8802-3:2017/AMD3) such as 25GBASE-T and 40GBASE-T.
• Note: Formal test methods for direct attach cabling will be published in the second edition of ISO/IEC 14763-4.

Applications and Who Uses It

• Network and data center designers selecting or specifying direct-attach copper assemblies.
• Cable and connector manufacturers developing connectorized cable assemblies to meet Class D–II performance.
• Installation contractors and cabling testers responsible for performance verification and acceptance testing.
• Standards writers and procurement teams specifying cabling for short-reach, high-speed Ethernet (including 25G/40GBASE-T) or equipment-to-equipment links.
• Useful where equipment is linked directly without patch panels or intermediate connectivity (e.g., server-to-switch short connections).

Related Standards

• ISO/IEC 11801-1 - General requirements for generic cabling (normative reference).
• ISO/IEC 14763-4 - Test methods for end-to-end links (second edition will include direct attach methods).
• ISO/IEC/IEEE 8802-3:2017/AMD3 - Ethernet amendment referenced for 5 m short-reach mode (25G/40GBASE-T).
• ISO/IEC TR 11801-9903 - Modelling techniques referenced for performance derivation.

This Technical Report is essential reading when specifying or validating connectorized, equipment-to-equipment cabling where consistent Class-based performance and short-reach high-speed support are required.
