IEC 61158-6:2000

Digital data communications for measurement and control - Fieldbus for use in industrial control systems - Part 6: Application Layer protocol specification

Please note that this part is also available as part of a special CD-ROM containing IEC 61158-2 (with 2 amendments), IEC 61158-3, IEC 61158-4, IEC 61158-5 and IEC 61158-6 for a price of CHF 459,00

General Information

• Status: Published
• Publication Date: 26-Jan-2000
• ICS: 25.040.40 - Industrial process measurement and control
• ICS: 35.100.70 - Application layer
• ICS: 35.240.50 - IT applications in industry
• Technical Committee: SC 65C - Industrial networks
• Current Stage: DELPUB - Deleted Publication
• Start Date: 27-May-2003
• Completion Date: 26-Oct-2025

Relations

• Replaces: IEC TS 61158-6:1999 - Digital data communications for measurement and control - Fieldbus for use in industrial control systems - Part 6: Application Layer protocol specification
• Effective Date: 05-Sep-2023
• Revised: IEC 61158-6:2003 - Digital data communications for measurement and control - Fieldbus for use in industrial control systems - Part 6: Application layer protocol specification
• Effective Date: 05-Sep-2023

Overview

IEC 61158-6:2000 is the International Electrotechnical Commission (IEC) standard specifying the Application Layer protocol for Fieldbus systems used in industrial control and measurement. As Part 6 of the IEC 61158 Fieldbus series, this second-edition document defines the application-layer syntax, services, object and class models, state-machine conventions and messaging behaviour required to support reliable digital data communications between controllers, I/O devices, instruments and supervisory systems. Note: this part is also sold as part of a consolidated CD-ROM bundle (includes IEC 61158‑2, ‑3, ‑4, ‑5 and ‑6) for CHF 459.00.

Key topics and requirements

• Application layer specification: Abstract syntax and protocol data units (PDUs) for Fieldbus application interactions (e.g., confirmed and unconfirmed send services).
• Object and class model: Definitions for application objects, instances, attributes, class codes and class-specific services to ensure interoperable device behaviour.
• Services and primitives: Common and object-specific services (client/server, producer/consumer models, unconnected services, UCMM) governing data exchange and control.
• Connection types: Point‑to‑point, multicast and cyclic communication models, connection identifiers and path definitions.
• State machines and conventions: Formal state-machine notation and conventions for deterministic behaviour and implementation consistency.
• Diagnostics & configuration: Definitions for device-related diagnosis, configuration identifiers, address assignment and consistency checks to support maintenance and commissioning.
• Terminology & references: Extensive normative references to ISO/IEC standards and IEC vocabularies (e.g., ISO/IEC 7498‑1) plus abbreviations and encoding conventions.

Applications and who uses it

IEC 61158-6 is aimed at professionals and organizations implementing or integrating industrial fieldbus networks, including:

• Device manufacturers building Fieldbus-enabled PLCs, I/O modules, sensors and actuators implementing application-layer behaviour.
• Control system integrators ensuring interoperability across multi-vendor systems and configuring connection types and communication classes.
• Automation software developers implementing protocol stacks, PDUs, state machines and UCMM/unconnected messaging.
• Test and certification labs validating compliance with Fieldbus application-layer requirements.
• Plant engineers and maintenance teams using diagnostic and configuration models for commissioning and troubleshooting distributed control systems.

Related standards

• IEC 61158 series (other parts: ‑2, ‑3, ‑4, ‑5, etc.)
• ISO/IEC references cited in the standard (e.g., ISO/IEC 7498‑1, ISO/IEC 8822, 9545)
• IEC vocabulary and symbol standards (e.g., IEC 60050, IEC 60027, IEC 60417)

Keywords: IEC 61158-6, Fieldbus, application layer, industrial control systems, protocol specification, digital data communications, measurement and control, Fieldbus protocol.
