Electrical insulation systems (EIS) - Thermal evaluation of combined liquid and solid components - Part 3: Hermetic motor-compressors

IEC TS 62332-3:2016 is applicable to EIM and EIS containing solid and liquid components where the refrigerant, oil and thermal stresses are the dominant ageing factor, without restriction to voltage class.

Systèmes d'isolation électrique (SIE) - Évaluation thermique de composants liquides et solides combinés - Partie 3: Motocompresseurs hermétiques

L'IEC TS 62332-3:2016 est applicable aux MIE et aux SIE contenant des composants solides et liquides, et pour lesquels le fluide frigorigène, l'huile et les contraintes thermiques constituent les facteurs de vieillissement prédominants, indépendamment de la classe de tension.
