IEC 60115-2:2014
(Main)Fixed resistors for use in electronic equipment - Part 2: Sectional specification: Leaded fixed low power film resistors
Fixed resistors for use in electronic equipment - Part 2: Sectional specification: Leaded fixed low power film resistors
IEC 60115-2:2014 is applicable to leaded fixed low-power film resistors for use in electronic equipment. These resistors are typically described according to types (different geometric shapes) and styles (different dimensions) and product technology. The resistive element of these resistors is typically protected by a conformal lacquer coating. These resistors have wire terminations and are primarily intended to be mounted on a circuit board in through-hole technique. The object of this standard is to prescribe preferred ratings and characteristics and to select from IEC 60115-1, the appropriate quality assessment procedures, tests and measuring methods and to give general performance requirements for this type of resistor. This edition includes the following significant technical changes with respect to the previous edition:
- it includes test conditions and requirements for lead-free soldering and assessment procedures meeting the requirements of a "zero defect" approach;
- it introduces a product classification based on application requirements;
- it includes an extension of the list of styles and dimensions;
- it includes the use of an extended scope of stability class definitions;
- it includes the extension of the lists of preferred values of ratings;
- it includes test conditions and requirements for lead-free soldering, for periodic overload and for resistance to electrostatic discharge (ESD);
- it includes a new set of severities for a shear test;
- it includes definitions for a test board;
- it includes the replacement of assessment level E and possible others by the sole assessment level EZ, meeting the requirements of a "zero defect" approach;
- it includes an extended endurance test, a flammability test, a temperature rise test, vibration tests, an extended rapid change of temperature test, and a single pulse high-voltage overload test;
- it includes requirements applicable to 0-ohm resistors (jumpers);
- it includes recommendations for the denomination, description, packaging and quality assessment of radial formed styles;
- it includes prescriptions for endurance testing at room temperature, supplementary to the rulings of IEC 60115-1.
Résistances fixes utilisées dans les équipements électroniques - Partie 2: Spécification intermédiaire: Résistances fixes à broches à couches, à faible dissipation
L'IEC 60115-2:2014 est applicable aux résistances fixes à broches à couches, à faible dissipation utilisées dans les équipements électroniques. Ces résistances sont généralement décrites en fonction des types (formes géométriques différentes), des modèles (dimensions différentes) et de la technologie de produit. L'élément résistif de ces résistances est généralement protégé par un revêtement de laque conforme. Ces résistances comportent des fils de sortie et sont principalement destinées à être montées sur une carte de circuits avec la technique des trous traversants. L'objectif de la présente norme est de prescrire des valeurs assignées et des caractéristiques préférentielles et de sélectionner d'après l'IEC 60115-1 les procédures d'assurance de qualité, les essais et les méthodes de mesures appropriés, et de fournir des exigences générales pour ce type de résistance. Les modifications techniques majeures par rapport à la première édition sont les suivantes:
- inclut des conditions d'essai et des exigences pour le brasage sans plomb et des procédures d'évaluation satisfaisant aux exigences d'une approche "zéro défaut";
- introduction d'une classification de produit basée sur des exigences d'application;
- extension de la liste des modèles et dimensions;
- utilisation d'un domaine d'application élargi des définitions de classes de stabilité;
- extension des listes de valeurs assignées préférentielles;
- introduction de conditions d'essais et d'exigences pour la brasure sans plomb, pour les surcharges périodiques et pour la résistance aux décharges électrostatiques (ESD);
- introduction de nouvelles sévérités pour un essai de cisaillement;
- introduction de définitions pour une carte d'essai;
- remplacement du niveau d'assurance E et d'autres niveaux possibles par le seul niveau d'assurance EZ, satisfaisant aux exigences d'une approche "zéro défaut";
- introduction d'un essai d'endurance prolongée, d'un essai d'inflammabilité, d'un essai d'échauffement, d'un essai de vibrations, d'un essai de variation rapide de température étendu et d'un essai de surcharge haute tension à une seule impulsion;
- introduction d'exigences applicables aux résistances de 0 (câbles de liaison);
- introduction de recommandations pour la dénomination, la description, l'emballage et l'évaluation de la qualité des modèles de forme radiale;
- introduction de prescriptions pour les essais d'endurance à la température ambiante, en complément des règles de l'IEC 60115-1.
