IEC 61084-2-1:2017

Cable trunking systems and cable ducting systems for electrical installations - Part 2-1: Particular requirements - Cable trunking systems and cable ducting systems intended for mounting on walls and ceilings

IEC 61084-2-1:2017 specifies requirements and tests for cable trunking systems (CTS) and cable ducting systems (CDS) intended for the accommodation, and where necessary for the electrically protective separation, of insulated conductors, cables and possibly other electrical equipment in electrical and/or communication systems installations. The maximum voltage of these installations is 1 000 V AC and 1 500 V DC.
These systems are intended for mounting on walls and/or ceilings. They can be embedded, installed in a flush or semi-flush state, surface mounted or mounted away from the surface using fixing devices.
This document does not apply to conduit systems, cable tray systems, cable ladder systems, power track systems or equipment covered by other standards.
This second edition cancels and replaces the first edition published in 1996. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
- classification;
- construction;
- mechanical and electrical properties.
This International Standard is to be used in conjunction with IEC 61084-1:2017.

Systèmes de goulottes et systèmes de conduits-profilés pour installations électriques - Partie 2-1: Exigences particulières - Systèmes de goulottes et systèmes de conduits-profilés prévus pour être montés sur les murs et les plafonds

La présente partie de la série IEC 61084 spécifie les exigences et les essais pour les systèmes de goulottes (SG) et les systèmes de conduits-profilés (SCP) destinés au logement de conducteurs isolés, câbles et éventuels autres équipements électriques et, si nécessaire, à leur séparation de protection électrique, dans des installations électriques et/ou de systèmes de communication. La tension maximale de ces installations est de 1 000 V en courant alternatif et 1 500 V en courant continu.
Ces systèmes sont destinés à être montés sur les murs et/ou les plafonds. Ils peuvent être noyés, encastrés, semi-encastrés, montés en saillie ou montés écartés de la surface d’appui avec des dispositifs de fixation.
Le présent document ne s’applique pas aux systèmes de conduits, systèmes de chemins de câbles, systèmes d’échelles à câbles, systèmes de canalisations préfabriquées ou aux équipements couverts par d’autres normes.
Cette deuxième édition annule et remplace la première édition parue en janvier 1996. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- classification;
- construction;
- propriétés mécaniques et électriques.
Cette Norme internationale doit être utilisée conjointement avec l’IEC 61084-1:2017.

General Information

• Status: Published
• Publication Date: 06-Mar-2024
• ICS: 29.060.01 - Electrical wires and cables in general
• ICS: 29.120.10 - Conduits for electrical purposes
• Technical Committee: SC 23A - Cable management systems
• Drafting Committee: MT 5 - TC 23/SC 23A/MT 5
• Current Stage: PPUB - Publication issued
• Start Date: 22-Mar-2017
• Completion Date: 07-Apr-2017

Relations

• Amended By: IEC 61084-2-1:2017/AMD1:2024 - Amendment 1 - Cable trunking systems and cable ducting systems for electrical installations - Part 2-1: Particular requirements - Cable trunking systems and cable ducting systems intended for mounting on walls and ceilings
• Effective Date: 05-Sep-2023

Overview

IEC 61084-2-1:2017 is an international standard developed by the International Electrotechnical Commission (IEC) that defines particular requirements for cable trunking systems (CTS) and cable ducting systems (CDS) intended for mounting on walls and ceilings. This standard focuses on systems used to accommodate and provide electrically protective separation for insulated conductors, cables, and other electrical or communication equipment operating at voltages up to 1,000 V AC and 1,500 V DC.

The scope covers various installation methods including embedded, flush or semi-flush mounting, surface mounting, or mounting away from surfaces using fixing devices. It excludes conduit systems, cable trays, ladder systems, and power track systems, which are covered by other standards. The 2017 edition updates the original 1996 version, introducing technical revisions concerning classification, construction, and mechanical and electrical properties of the systems.

Key Topics

• Classification of Cable Trunking and Ducting Systems: The standard categorizes CTS and CDS into three main types:
  • Type 1: Systems that do not meet criteria of types 2 or 3.
  • Type 2 (Distribution CTS/CDS): Offers functions such as inline junctions, changes of direction (internal, external, flat), "T" junctions, and termination points.
  • Type 3 (Installation CTS/CDS): Provides all functions of Type 2 plus apparatus mounting capability.
• Construction and Design Requirements: The standard sets strict guidelines for dimensions, materials, and build quality to ensure system integrity, safe accommodation of cables and equipment, and compliance with electrical and mechanical properties.
• Mechanical Properties: Testing procedures including impact resistance, linear deflection, cable support under load, and compression tests ensure robustness for wall or ceiling installation environments.
• Electrical Properties and Safety: Requirements cover electrical insulation, protective separation, and electromagnetic compatibility for secure and reliable performance.
• Thermal and Fire Safety: Systems must meet thermal resistance limits and fire hazard assessments to enhance overall installation safety.
• Marking and Documentation: Clear marking for identification and detailed product documentation are mandated to support installation and maintenance operations.

Applications

IEC 61084-2-1:2017 is essential for manufacturers, designers, and installers of cable management systems used in electrical installations within commercial, industrial, and residential buildings. Applications include:

• Organizing and protecting power and communication cables on walls and ceilings.
• Ensuring electrically separated routing to prevent faults or short circuits.
• Facilitating neat, accessible cable runs in installations requiring compliance with international safety and quality standards.
• Providing support solutions where cable trunking or ducting systems must be surface-mounted, flush-mounted, or embedded.

This standard helps ensure cable management systems are reliable, durable, and safe, minimizing the risk of electrical hazards while supporting efficient installation and future maintenance.

Related Standards

• IEC 61084-1:2017: General requirements for cable trunking and ducting systems, which IEC 61084-2-1 supplements with particular requirements for wall and ceiling mounting.
• IEC 60068-2-75:2014: Environmental testing standards including hammer tests for mechanical robustness.
• IEC 60228:2004: Specifies conductors for insulated cables used within cable management systems.
• ISO 535:2023 and ISO 536:2019: Methods for determining paper and board water absorptiveness and grammage, applicable for packaging or labeling elements associated with cable trunking systems.
• Other IEC standards covering conduit systems, cable trays, cable ladders, and power track systems which are excluded from IEC 61084-2-1’s scope.

---

Keywords: IEC 61084-2-1, cable trunking systems, cable ducting systems, electrical installations, wall mounting, ceiling mounting, cable management, electrical safety, cable protection, IEC standards, cable ducting classification, electrical separation, mechanical properties, electromagnetic compatibility.

Standards Content (Sample)
