INTERNATIONAL STANDARD ISO 21746:2019(E)
Composites and metal assemblies — Galvanic corrosion
tests of carbon fibre reinforced plastics (CFRPs) related
bonded or fastened structures in artificial atmospheres —
Salt spray tests
1 Scope

This document specifies the apparatus, the reagents and the procedure to be used in conducting the

neutral salt spray (NSS), acetic acid salt spray (AASS) and copper-accelerated acetic acid salt spray

(CASS) tests for assessment of the galvanic corrosion resistance of joints and bonded structures

between carbon fibre reinforced plastics (CFRPs) and metallic materials, with or without permanent or

temporary insulation for the galvanic current.
2 Normative references

The following documents are referred to in the text in such a way that some or all of their content

constitutes requirements of this document. For dated references, only the edition cited applies. For

undated references, the latest edition of the referenced document (including any amendments) applies.

ISO 1514, Paints and varnishes — Standard panels for testing
ISO 2808, Paints and varnishes — Determination of film thickness
ISO 3574, Cold-reduced carbon steel sheet of commercial and drawing qualities

ISO 6361-2, Wrought aluminium and aluminium alloys — Sheets, strips and plates — Part 2: Mechanical

properties
ISO 8044, Corrosion of metals and alloys — Basic terms and definitions

ISO 8407, Corrosion of metals and alloys — Removal of corrosion products from corrosion test specimens

ISO 17872, Paints and varnishes — Guidelines for the introduction of scribe marks through coatings on

metallic panels for corrosion testing
3 Terms and definitions

For the purposes of this document, the terms and definitions given in ISO 8044 and the following apply.

ISO and IEC maintain terminological databases for use in standardization at the following addresses:

— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
reference material
material with known test performance
3.2
reference specimen

portion of the reference material that is to be exposed with the intention to check the reproducibility

and repeatability of the test results for the test cabinet in use
© ISO 2019 – All rights reserved 1
---------------------- Page: 6 ----------------------
ISO 21746:2019(E)
3.3
test specimen
specific portion of the samples upon which the testing is to be performed
3.4
substitute specimen

specimen made of inert materials (such as ceramic or glass) used for the substitute of a test specimen

Note 1 to entry: Examples of inert materials are ceramic or glass.
3.5
control specimen

specimen made of CFRP, which is identical to the CFRPs of test specimen, used to check the

reproducibility, repeatability and deviation or drift by solution absorption of the test results

3.6
neutral salt spray test
NSS

test method in which a 5 % sodium chloride solution is atomized under a controlled environment

Note 1 to entry: It particularly applies to:
— CFRPs and metals or their alloys in fastened or bonded form;
— sacrificial protections (anodic and cathodic);
— organic coatings on pinned or riveted joints of CFRPs and metals.
3.7
acetic acid salt spray test
AASS

test method in which a 5 % sodium chloride solution with the addition of glacial acetic acid is atomized

under a controlled environment

Note 1 to entry: It is especially useful for testing CFRPs with lightning strike protection layer (LSP) of Cu or Al

mesh or foil in acid-rain or exhaust gas environment.
3.8
copper-accelerated acetic acid salt spray test
CASS

test method in which a 5 % sodium chloride solution with the addition of copper chloride and glacial

acetic acid is atomized under a controlled environment

Note 1 to entry: It is useful for modelling an aged structure of CFRPs with LSPs and Al alloys in fastened or

bonded form in acid-rain or exhaust gas environment.
3.9
scribed specimen

specimen with organic or inorganic coating, which is intentionally line-damaged with scriber needle

3.10
purity of salt
mass fraction of sodium chloride excluding contaminant
4 Test solutions
4.1 Preparation of the sodium chloride solution

Dissolve a sufficient mass of sodium chloride in distilled or deionized water with a conductivity not

higher than 20 μS/cm at 25 °C ± 2 °C to produce a concentration of 50 g/ l ± 5 g/l. The conductivity shall

be measured just before the preparation, as dissolution of carbon dioxide in atmospheric environment

2 © ISO 2019 – All rights reserved
---------------------- Page: 7 ----------------------
ISO 21746:2019(E)

can drift the value. The sodium chloride concentration of the sprayed solution collected shall be

50 g/l ± 5 g/l. The specific gravity range of a 50 g/l ± 5 g/l solution is from 1,029 to 1,036 at 25 °C.

The sodium chloride shall contain less than 0,001 % mass fraction of copper and less than 0,001 %

mass fraction of nickel, as determined by atomic absorption spectrophotometry or another analytical

method of similar sensitivity. It shall not contain more than 0,1 % of a mass fraction of sodium iodide,

or more than 0,5 % of a mass fraction of total impurities calculated for dry salt. Industrial salt is not

recommended due to possible deviation of the impurities.
4.2 pH adjustment
4.2.1 pH of the salt solution

If necessary, control the pH of distilled or deionized water to 7,0 by the aeration of nitrogen gas

- dissolution of carbon dioxide can drift the pH – in the preparation of the sodium chloride solution.

Adjust the pH of the salt solution to the desired value on the basis of the pH of the sprayed solution

collected.
4.2.2 Neutral salt spray test (NSS)

Adjust the pH of the salt solution (see 4.1) so that the pH of the sprayed solution collected within the

test cabinet (5.2) is 6,5 to 7,2 at 25 °C ± 2 °C. Check the pH using electrometric measurement or in

routine checks, with a short-range pH paper, which can be read in increments or 0,2 pH units or less.

If pH electrodes are used, they shall be suitable for measuring pH in weakly buffered sodium chloride

solutions in de-ionized water. Make any necessary corrections by adding hydrochloric acid, sodium

hydroxide or sodium bicarbonate solution of analytical grade.
4.2.3 Acetic acid salt spray test (AASS)

Add a sufficient amount of glacial acetic acid to the salt solution (see 4.1) to ensure that the pH of

samples of sprayed solution collected in the test cabinet (see 5.2) is between 3,1 and 3,3. If the pH of the

solution initially prepared is 3,0 to 3,1, the pH of the sprayed solution is likely to be within the specified

limits. Check the pH using electrometric measurement at 25 °C ± 2 °C. If pH electrodes are used, they

shall be suitable for measuring pH in weakly buffered sodium chloride solutions in de-ionized water.

Make any necessary corrections by adding glacial acetic acid or sodium hydroxide of analytical grade.

4.2.4 Copper-accelerated acetic acid salt spray test (CASS)

Dissolve a sufficient mass of copper (II) chloride dihydrate (CuCl ·2H O) in the salt solution (see 4.1) to

2 2

produce a concentration of 0,26 g/l ± 0,02 g/l [equivalent to (0,205 ± 0,015) g of CuCl per litre].

Adjust the pH using the procedures described in 4.2.3.
4.3 Filtration

Test solutions prepared using the procedures described in 4.1 and 4.2.1 in laboratory environment are

suitable for the spraying applications. However, if necessary, filter the solution before placing it in the

reservoir of the apparatus, to remove any solid matter or contaminant which might affect the apertures

of the spraying device. Any incident relating to the solid matter shall be reported as described in 13.2 r).

© ISO 2019 – All rights reserved 3
---------------------- Page: 8 ----------------------
ISO 21746:2019(E)
5 Apparatus

5.1 Component protection. All components in contact with the spray or the test solution shall

be made of, or lined with, materials resistant to corrosion by the sprayed solution and which do not

influence the corrosivity of the sprayed test solution.

If necessary, electric insulation shall be devised for the apparatus to prevent the influence from inside

or outside of the apparatus.

The supports for the test specimen shall be constructed such that different substrate types do not

influence each other. It shall also be constructed so that the supports themselves do not influence the

test specimens.

5.2 Spray cabinet. The cabinet for galvanic corrosion test shall be such that the conditions of

homogeneity and distribution of the spray are met. Due to the limited capacity of cabinets smaller than

0,4 m3, the effect of the loading of the cabinet on the distribution of the spray and temperature should

be carefully considered. The sprayed solution shall be fell down naturally on the test specimens, and the

upper parts of the cabinet shall be designed so that drops of spayed solution formed on its surface do not

fall on the test specimens being tested (see Annex A).

If a cabinet for galvanic corrosion test has been used once for an AASS or CASS test, or has been used for

any other purpose with a solution differing from that specified for the NSS test, it shall not be used for

the NSS test.

The size and shape of the cabinet shall be such that the collection rate of solution in the cabinet is within

the limits specified in Table 3, measured as specified in 9.3.

Preference shall be given to apparatus that has a means for properly dealing with fog after the test,

prior to releasing it from the building for environmental conservation, and for drawing water prior to

discharging it to the drainage system.

5.3 Heater and temperature control. An appropriate system for galvanic corrosion test maintains the

cabinet and its contents at the specified temperature (see Table 3). The temperature shall be measured

at least 100 mm from the walls.

5.4 Spraying device. The device for spraying the test solution comprises a supply of clean air, of

controlled pressure and humidity, a reservoir to contain the solution to be sprayed, and one or more

atomizers.

The compressed air supplied to the atomizers shall be filtered to remove all traces of contaminants

such as oil or solid matter, and the atomizing pressure shall be at an overpressure of 70 kPa to 170 kPa.

The pressure should be 98 kPa ± 10 kPa.

In order to prevent the evaporation of water from the sprayed droplets (aerosol), the air shall be

humidified before entering the atomizer by passing through a suitable humidifier. The humidified air

shall be saturated such that the concentration of the fallout solution falls within the specifications of

4.1. The humidified air shall also be heated such that when mixed with the salt solution, there is no

significant disturbance of the temperature in the cabinet. The appropriate temperature depends on

the pressure used and on the type of atomizer nozzle. Temperature, pressure or humidification, or

a combination thereof, shall be adjusted so that the rate of collection of the spray in the cabinet and

the concentration of the collected spray are kept within the specified limits (see 9.3). A common used

humidifier is the saturation tower, where temperature and pressure are controllable. Table 1 gives

guidance values on temperature and pressure combinations for the saturation tower.

4 © ISO 2019 – All rights reserved
---------------------- Page: 9 ----------------------
ISO 21746:2019(E)

Table 1 — Guiding values of galvanic corrosion test for the solution temperature in the

saturation tower
Guiding values for the temperature, in °C, of the hot water in the sat-
Atomizing overpressure
uration tower when performing the different salt spray test
Neutral salt spray (NSS) and ace- Copper-accelerated acetic acid
kPa
tic acid salt spray (AASS) salt spray (CASS)
70 45 61
84 46 63
98 48 64
112 49 66
126 50 67
140 52 69

The atomizers shall be made of inert material such as ceramic and glass. Baffles may be used to prevent

direct impact of the spray on the test specimens, and the use of adjustable baffles is helpful in obtaining

uniform distribution of the spray within the cabinet. For this purpose, a dispersion tower equipped

with an atomizer may also be helpful.

The supply salt solution to the nozzle shall be kept stable to ensure a continuous and uniform fall out as

described in 9.3. A stable level of spraying can be achieved by either controlling the level of salt solution

in the reservoir or restricting the flow of salt solution to the nozzle such that a continuous spray is

achieved.

Distilled or deionized water with a conductivity not higher than 20 μS/cm at 25 °C ± 2 °C shall be used

for humidifier.

5.5 Collecting devices. Suitable collecting devices for galvanic corrosion test shall be available in such

number that the homogeneity of the cabinet can be checked, at least two, consisting of funnels made of

chemically inert material, with the stems inserted into graduated cylinders or other similar containers.

Suitable funnels have a diameter of 100 mm, which corresponds to a collecting area of approximately

80 cm . The collecting devices shall be placed in the zone of the cabinet where the test specimens are

placed, one close to an inlet of spray and one remote from an inlet. They shall be placed so that only mist,

and not liquid falling from specimens or from parts or the cabinet, is collected.

6 Method for evaluating cabinet corrosivity
6.1 General

To check the reproducibility and repeatability of the galvanic corrosion test results for one piece

of apparatus, or for similar items of apparatus in different laboratories, it is necessary to verify the

apparatus at regular intervals as described in 6.2 to 6.4.

To determine the corrosivity of the tests, reference-metal specimens made of steel or aluminium shall

be used.

As a complement to the reference-metal specimens made of steel or aluminium, high-purity zinc

reference-metal specimens may also be exposed in the tests in order to determine the corrosivity

against this metal as described in Annex B.
6.2 Reference specimens

To verify the apparatus, use four or six reference specimens of 1 mm ± 0,2 mm thickness and

150 mm × 70 mm, of CR4-grade steel in accordance with ISO 3574, or aerospace grade A1050 pure

aluminium in accordance with ISO 6361-2, with an essentially faultless surface and a matt finish

© ISO 2019 – All rights reserved 5
---------------------- Page: 10 ----------------------
ISO 21746:2019(E)

(arithmetical mean deviation of the profile Ra = 0,8 μm ± 0,3 μm). Cut these reference specimens from

cold-rolled plates or strips.

Clean the reference specimens carefully, immediately prior to testing. Besides the specifications given

in 7.2 and 7.3, cleaning shall eliminate all those traces (dirt, oil, protective resin or other foreign matter)

that could influence the test results.

Thoroughly clean the reference specimens with an appropriate organic solvent (such as a hydrocarbon

with a boiling point between 60 °C and 120 °C) using a clean soft brush or an ultrasonic cleaning device.

Carry out the cleaning in a vessel full of solvent. After cleaning, rinse the reference specimens with

fresh solvent and then dry them.

Determine the mass of the reference specimens to ±1 mg. Protect one face of the reference specimens

with a removable coating, for example an adhesive plastic film. The edges of the reference test

specimens may be protected by the adhesive tape as well.
6.3 Arrangement of the reference specimens

Position four steel or aluminium reference specimens in four quadrants (if six specimens are available,

place them in six different positions including four quadrants) in the zone of the cabinet where the test

specimens are placed, with the unprotected face upwards, and at an angle of 20° ± 5° from the vertical.

The support for the reference specimens shall be made of, or coated with, inert materials such as

plastics. The lower edge of the reference specimens shall be level with the top of the salt spray collector.

The cabinet should be verified during the testing of specimens. If this is the case, great care shall be

taken that the specimens do not affect each other. Otherwise, the cabinet shall be filled with substitute

specimens to maintain the homogeneity of the cabinet. The verification procedure shall be performed

using the same settings as for the test runs.
6.4 Duration of tests
Neutral salt spray test (NSS): 48 h.
Acetic acid salt spray test (AASS): 24 h.
Copper-accelerated acetic acid salt spray test (CASS): 24 h.
6.5 Determination of mass lo
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
