INTERNATIONAL STANDARD ISO 18406:2017(E)
Underwater acoustics — Measurement of radiated
underwater sound from percussive pile driving
1 Scope
This document describes the methodologies, procedures, and measurement systems to be used for the
measurement of the radiated underwater acoustic sound generated during pile driving using percussive
blows with a hammer.
A major motivation for undertaking measurements of the sound radiated during percussive pile
driving is as part of an assessment of impact on aquatic fauna required by regulatory frameworks. This
document describes a generic approach to measurements that can be applied to different regulatory
requirements.
This document is suitable for measurement of percussive pile driving undertaken for offshore
installation of foundations (monopiles, jackets, tripods, etc.) used in construction of offshore wind
farms, oil and gas platforms, and other inshore structures such as bridge foundations and aquatic
renewable energy devices. This document does not cover measurement of the sound radiated by vibro-
piling or sheet piling. This document does not cover piling in water of depth less than 4 m or greater
than 100 m.
The procedures described herein provide guidance on making measurements to satisfy the following
objectives:
— to monitor source output during piling, for example, for regulatory purposes;
— to provide consistency in comparison of piling noise from different construction projects;
— for validation of modelling or predictions.
This document covers only the measurement of the sound field radiated during percussive pile driving.
The scope of this document does not include the assessment of exposure metrics, or the use of exposure
criteria. No attempt is made to prescribe a methodology for generating maps of the acoustic field in the
vicinity of the source.
In the normative part of this document, requirements and procedures are described for measurement of
the sound field at specific ranges from the pile being driven. In this part of the document, no procedure
is provided for determination of an acoustic output metric that is independent of the propagation path
between source and receiver (such as a source level). Ideally, such a metric would have some predictive
utility (for example, in calculating noise impact zones and noise maps). However, some information on
the determination of a possible acoustic output metric is provided in Annex A.
This document covers only the measurement of sound pressure in the water column. The scope does
not include measurement of sound particle velocity in the water column due to the propagating sound
wave, or seabed vibration caused by waves propagating across the sea-floor. This exclusion does not
imply that such measures are unimportant; indeed, their importance in assessing the impact on aquatic
life is recognized. However, at the time of drafting, measurement of these quantities is not yet mature
enough for standardization.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
© ISO 2017 – All rights reserved 1

---------------------- Page: 7 ----------------------
ISO 18406:2017(E)

ISO 18405, Underwater acoustics — Terminology
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 18405 (especially: sound
pressure, sound pressure level, mean-square sound pressure level, sound exposure, sound exposure
level, peak sound pressure, peak sound pressure level) and the following apply.
NOTE Although the definitions of sound exposure and sound exposure level are taken from ISO 18405,
specific nomenclature is used in this document for sound exposure level calculated over the duration of one
acoustic pulse, and over the duration of multiple acoustic pulses; this nomenclature is described in 3.2.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http:// www .electropedia .org/
— ISO Online browsing platform: available at http:// www .iso .org/ obp
3.1
pulse duration
percentage energy signal duration over the acoustic pulse
Note 1 to entry: The percentage energy signal duration is defined in ISO 18405.
Note 2 to entry: The energy percentage over which the pulse duration has been calculated should be stated with
the result. For the purposes of this document, the energy percentage for the pulse duration is 90 %.
Note 3 to entry: In general, in shallow water, the acoustic pulse includes multiple arrivals of the outgoing
acoustic waves, including multi-path signal arrivals from surface and seabed. In reverberant environments such
as harbours, where sound waves may be reflected by boundaries such as harbour walls, it may be difficult to
identify individual outgoing acoustic pulses.
3.2
sound exposure level
SEL
level of the sound exposure, for a specified reference value
Note 1 to entry: The sound exposure level is as defined in ISO 18405.
Note 2 to entry: The sound exposure level for an individual acoustic pulse (corresponding to a single hammer
strike) is calculated over the pulse duration on the basis of 100 % of the pulse energy. For the purposes of this
document, this is termed the single strike sound exposure level (abbreviated as SEL ). It is recognized that in the
ss
scientific literature, this parameter is sometimes called the single pulse sound exposure level.
Note 3 to entry: The sound exposure level over a defined period of time, which includes multiple acoustic pulses,
is, for the purposes of this document, termed the cumulative sound exposure level (abbreviated as SEL ). When
cum
reporting the cumulative sound exposure level, the number of pulses and the time duration over which the
cumulative sound exposure level has been calculated are stated.
Note 4 to entry: In the acoustic near field, sound exposure is not related to the sound intensity or energy in the
straightforward manner that applies for the acoustic far field. Therefore, care should be taken when interpreting
measurements of SEL made in the acoustic near field.
3.3
pulse repetition frequency
pulse repetition rate
number of hammer strikes per unit time
Note 1 to entry: Typically stated as the number of strikes (or acoustic pulses) per second.
Note 2 to entry: It is common for the pulse repetition frequency to be less than 1 per second.
2 © ISO 2017 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 18406:2017(E)

3.4
background noise
all sound recorded by the hydrophone in the absence of the pile driving signal for a specified pile driving
acoustic signal being measured
3.5
measurement system
data acquisition system consisting of, but not limited to, one or more hydrophone(s), conditioning
preamplifier(s), analogue-to-digital converter(s), computer and ancillary peripherals
3.6
frequency range
span from the lowest frequency to the highest frequency over which the measurement system is able to
measure, for a given uncertainty
Note 1 to entry: The frequency range is expressed as the lowest frequency to the highest frequency.
3.7
dynamic range
amplitude range over which a measurement system is able to measure, for a given tolerance of
distortion, expressed as a range from the lowest to the highest amplitude
Note 1 to entry: Dynamic range can also be expressed in decibels representing the difference between the level of
the noise floor created by the system self-noise and the maximum level which can be measured with a specified
maximum allowable distortion. It can be expressed for a single frequency or at a range of frequencies.
3.8
field calibration
method of using known inputs, possibly using physical stimuli (such as a known and calibrated/traceable
acoustic or vibration source) or electrical input (charge or voltage signal injection) at the input (or other
stage) of a measurement system in order to ascertain that the system is, in fact, responding properly
(i.e. within the system’s stated uncertainty) to the known stimulus
[23]
[SOURCE: ISO 17208-1:2016, 3.9]
3.9
measurement uncertainty
estimate of the range (or dispersion) of values within which the true value is considered to lie to a
specified degree of confidence (for example, for a confidence level of 95 %)
[SOURCE: ISO/IEC Guide 98-3:2008]
3.10
hydrophone
underwater sound transducer that provides an electrical signal in response to fluctuations in pressure,
and is designed to respond to the pressure of a sound wave
Note 1 to entry: If the electrical signal is proportional to the incident sound pressure, the hydrophone is said to
have a linear response.
3.11
hammer energy
kinetic energy of the hammer used for the pile driving for a specific blow
Note 1 to entry: This is equal to the kinetic energy with which the hammer mass strikes the pile.
Note 2 to entry: The hammer energy is expressed in kJ.
3.12
pile dimensions
dimensions of the pile in terms of the overall length, diameter and wall thickness (if hollow)
© ISO 2017 – All rights reserved 3

---------------------- Page: 9 ----------------------
ISO 18406:2017(E)

3.13
offshore
marine area, including coastal areas, regional seas and continental shelf, but excluding harbours,
coastal inlets, inland waterways, river estuaries, and rivers
3.14
inshore
marine or aquatic region, including harbours, coastal inlets, inland waterways, river estuaries, and
rivers, but excluding regional seas, continental shelf and coastal areas
3.15
equivalent bandwidth noise pressure
p
w
ratio of the root-mean-square noise voltage at a specified central frequency in the relevant frequency
band present at the electrical terminals of the hydrophone, in the absence of pressure fluctuations at the
hydrophone input, to its free-field open-circuit hydrophone voltage sensitivity at a specified frequency
Note 1 to entry: Equivalent bandwidth noise pressure is expressed in pascals, Pa.
[24]
[SOURCE: IEC 60500:—]
3.16
equivalent bandwidth noise pressure level
ten times the logarithm to the base 10 of the ratio of the square of the value of equivalent bandwidth
noise pressure, p , of a hydrophone to the square of a reference pressure, p , in decibels
w 0
Note 1 to entry: Equivalent bandwidth noise pressure level is expressed in decibels, dB.
Note 2 to entry: The value of the reference pressure, p , is 1 μPa.
0
[24]
[SOURCE: IEC 6050
...
