ISO 3545-3:1989

Steel tubes and fittings - Symbols for use in specifications - Part 3: Tubular fittings with circular cross-section

This part defines the most common symbols with the aim of standardizing and facilitating the use of terminology in standards for steel hollow sections and associated products. Five figures illustrate the meaning of the text. Annex A contains the bibliography.

Tubes et raccords en acier — Symboles à utiliser dans les spécifications — Partie 3: Accessoires tubulaires à section circulaire

La présente partie de l'ISO 3545 définit les symboles les plus usuels en vue de faciliter et d'unifier le langage dans le domaine des normes pour accessoires tubulaires en acier susceptibles d'être élaborées.

Jeklene cevi in fitingi - Simboli za rabo v specifikacijah - 3. del: Cevni fitingi s krožnim prerezom

General Information

• Status: Published
• Publication Date: 29-Nov-1989
• ICS: 23.040.40 - Metal fittings
• Technical Committee: ISO/TC 5/SC 1 - Steel tubes
• Drafting Committee: ISO/TC 5/SC 1 - Steel tubes
• Current Stage: 9599 - Withdrawal of International Standard
• Start Date: 08-Dec-2025
• Completion Date: 13-Dec-2025
• Ref Project: SIST ISO 3545-3:1995 - Steel tubes and fittings -- Symbols for use in specifications -- Part 3: Tubular fittings with circular cross-section

Relations

• Revises: ISO 3545:1981 - Steel tubes and tubular shaped accessories with circular cross-section - Symbols to be used in specifications
• Effective Date: 15-Apr-2008

Overview

ISO 3545-3:1989 is an international standard developed by the International Organization for Standardization (ISO) that focuses on the symbols used in specifications for steel tubular fittings with circular cross-sections. This standard provides a unified set of symbols aimed at standardizing terminology in relation to steel tubes and fittings, specifically those with circular profiles. It helps manufacturers, engineers, and technical professionals accurately communicate dimensions, tolerances, and service conditions related to steel tubular fittings.

The document is part of the broader ISO 3545 series which addresses symbols for steel tubes and fittings in various cross-sections, promoting clarity and consistency across industry documentation and technical standards.

Key Topics

• Standardized Symbols: The standard defines symbols for dimensions including outside and inside diameters, thicknesses adjacent to major and minor diameters, lengths of straight ends, bending radii, nominal sizes, and pressures.
• Symbols for Service Conditions: Includes specification of nominal and service pressures and temperatures, critical for engineering and safety assessments.
• Tolerances and Alignment Symbols: Addresses angular and perpendicular alignment tolerances to ensure accurate engineering and fitting of parts.
• Types of Tubular Fittings Covered: Symbols are provided for common fittings such as:
  • Bends (with detailed bending radii identification)
  • Reducers (both concentric and eccentric)
  • Tees (equal and reducing)
  • Caps
• Illustrative Figures: Five figures accompany the text to visually explain the symbols and their application on tubular fittings.
• Annex A - Bibliography: Provides references to related ISO standards on steel fittings for additional context.

Applications

ISO 3545-3:1989 is essential for industries involved in the design, production, and use of steel tubular fittings, including:

• Oil and Gas: For pipelines and pressure vessel construction requiring clear dimensional specifications and pressure ratings.
• Construction and Civil Engineering: In structural frameworks where steel tubes with circular sections are prevalent.
• Mechanical Engineering: For machinery and equipment involving fluid transport through tubular steel components.
• Manufacturing: Facilitates standardized production drawings and specifications, minimizing errors and misinterpretations.
• Quality Control: Enables consistent inspection protocols based on recognized symbols and tolerances.

Using ISO 3545-3 greatly improves communication between international suppliers, manufacturers, and end-users by ensuring that all parties understand the precise nature of tubular fittings as described in specifications.

Related Standards

• ISO 3545-1: Symbols for steel tubes and fittings - General terms.
• ISO 3545-2: Symbols for steel tubes and fittings - Square and rectangular hollow sections.
• ISO 5252:1977: Steel tubes - Tolerances systems, complementing the tolerance symbols used in ISO 3545-3.
• ISO 3419:1981: Non-alloy and alloy steel butt-welding fittings – relevant for butt-welding joint specifications.
• ISO 5251:1981: Stainless steel butt-welding fittings, related to material-specific applications of fittings.

---

Adopting ISO 3545-3:1989 ensures accurate and universally understood specifications for tubular steel fittings with circular cross-sections, supporting efficient design, manufacture, and quality assurance processes worldwide. This standard is a key reference point in steel tubing industries aiming for high-quality, consistent documentation of tubular fittings.

Standards Content (Sample)
