SIST EN 22876:1996

Packaging - Complete, filled transport packages - Rolling test (ISO 2876:1985)

Principle: Rolling of the test pacckage so as to impact on each face in turn. The toppling test is recommended for packages where the ratio of the longest to the shortest sides is of the order of 3:1 or greater. Apparatus, package preparation, procedure for parallelepipedal and packages of other shapes and the test report are specified.

Verpackung - Versandfertige Packstücke - Umkipp-Prüfung (sequentiell) (ISO 2876:1985)

Emballages - Emballages d'expédition complets et pleins - Essai de roulement (ISO 2876:1985)

La présente Norme internationale spécifie une méthode d'essai de roulement des emballages d'expédition complets et pleins. Un tel essai peut être effectué comme essai simple dans le but d'examiner les effets du roulement, ou il peut faire partie d'une série d'essais destinés à mesurer la résistance d'un emballage dans un système de distribution qui comprend un risque de roulement.
NOTE -- Un essai de basculement peut être plus convenable pour des emballages de grande hauteur par rapport à leurs dimensions de base, ou dont la hauteur est petite comparativement aux dimensions de base mais qui peuvent être stockés ou transportés en étant posés sur un côté. L'essai de basculement est recommandé pour des emballages dont le rapport du côté le plus long au côté le plus court est de l'ordre de 3 : 1 ou supérieur. Une méthode d'essai de chute par basculement sur des emballages complets et pleins est en préparation.

Embalaža - Celovita, napolnjena transportna embalaža - Preskus s prevračanjem (ISO 2876:1985)

General Information

• Status: Published
• Publication Date: 31-Jul-1996
• ICS: 55.180.40 - Complete, filled transport packages
• Technical Committee: EPO - Packaging - sales and grouped
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Aug-1996
• Due Date: 01-Aug-1996
• Completion Date: 01-Aug-1996
• Directive: 80/232/EEC - Ranges of nominal quantities and nominal capacities permitted for certain pre-packaged products
• Directive: 87/356/EEC - Ranges of nominal quantities and nominal capacities permitted for certain pre-packged products (Dir. 80/232/EEC amendment)
• Ref Project: EN 22876:1992 - Packaging - Complete, filled transport packages - Rolling test (ISO 2876:1985)

Relations

• Replaces: SIST ISO 2876:1996 - Packaging -- Complete, filled transport packages -- Rolling test
• Effective Date: 01-Aug-1996

Overview

SIST EN 22876:1996 is a European standard that specifies the method for conducting rolling tests on complete, filled transport packages based on ISO 2876:1985. This test evaluates the robustness of packaging as it undergoes mechanical stresses during transport and handling. The rolling test is particularly essential for assessing a package’s ability to withstand impacts on each face by simulating real-world rolling hazards during transportation.

The standard covers procedures for different package shapes, including parallelepipedal packages and other geometries, specifying apparatus requirements, package preparation, testing steps, and reporting. It ensures packaging maintains integrity, protecting contents throughout distribution.

Key Topics

• Rolling Test Principle
  Rolling the complete, filled transport package so that each face impacts the designated rigid surface in turn, replicating the physical rolling hazards encountered during transport.

• Toppling Test Recommendation
  For packages with a length-to-width ratio of 3:1 or greater, a toppling test may be more suitable. This is particularly applicable to tall or elongated packages that may topple instead of rolling.

• Apparatus Requirements
  The impact surface must be a flat, rigid, immovable platform with specific flatness and rigidity criteria:

  • Mass at least 50 times the heaviest test package.
  • Flatness variation no greater than 2 mm (or a max of 5 mm for surfaces over 1000 mm).
  • Deformation under static load not exceeding 0.1 mm.

• Package Preparation
  Packages shall be filled with intended contents or close physical and dimensional simulants. Normal closure methods must be used to simulate actual distribution conditions accurately.

• Conditioning
  Test packages must be conditioned according to ISO 2233 to ensure consistent atmospheric conditions affecting the package materials before testing.

• Test Procedure
  Detailed steps for rolling the package over the impact surface, starting with surface 1 uppermost and following a defined sequence of tilting and rolling across edges to impact each face sequentially.

• Inspection and Evaluation
  After testing, packages and their contents are inspected for damage or failure. Observations help determine the package's effectiveness in withstanding rolling hazards.

• Reporting Requirements
  Test reports must include package details, conditioning parameters, deviations from the method, test results, environmental conditions, and tester's signature to maintain traceability and consistency.

Applications

• Transport Packaging Validation
  Ensures packages used in logistics and supply chains can withstand rolling stresses encountered during shipment by road, rail, or sea.

• Packaging Design and Quality Control
  Assists manufacturers and quality assurance teams in verifying packaging strength and durability to reduce product damage and loss.

• Regulatory Compliance
  Supports compliance with transportation regulations and customer requirements by providing a standardized test method for shipping packages.

• Risk Assessment for Fragile Shipments
  Valuable for assessing risks to sensitive or high-value goods and optimizing cushioning and blocking solutions.

Related Standards

• ISO 2876:1985 – International equivalent standard providing detailed rolling test methodology for filled transport packages.
• ISO 2206 – Packaging - Identification of parts during testing, useful for defining package edges and surfaces.
• ISO 2233 – Packaging - Conditioning for testing; specifies conditioning atmosphere requirements for reliable test results.
• EN standards for Transport Packaging – Various other EN standards addressing different aspects of packaging testing and design.

---

Keywords: EN 22876, rolling test, transport packaging, filled packages, packaging testing, ISO 2876, package conditioning, toppling test, packaging durability, transport package standards, packaging quality control, test apparatus, packaging inspection.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.SUHYUDþDQMHPVerpackung - Versandfertige Packstücke - Umkipp-Prüfung (sequentiell) (ISO 2876:1985)Emballages - Emballages d'expédition complets et pleins - Essai de roulement (ISO 2876:1985)Packaging - Complete, filled transport packages - Rolling test (ISO 2876:1985)55.180.40Celovita, napolnjena transportna embalažaComplete, filled transport packagesICS:Ta slovenski standard je istoveten z:EN 22876:1992SIST EN 22876:1996en01-avgust-1996SIST EN 22876:1996SLOVENSKI
STANDARDSIST ISO 2876:19961DGRPHãþD

International Standard INTERNATIONAL ORGANIZATION FOR STANDARDIZATION.MEX~YHAPO~HAR OPI-AHM3ALWlR fl0 CTAHPIAPTM3AL(MM.ORGANISATION INTERNATIONALE DE NORMALISATION Packaging - Complete, filled transport packages - Rolling test EmbaJJages - EmbaJJages d’expedition complets et pleins - Essai de roulement Second edition - 1985-11-15 ~~ UDC 621.798.1 : 620.1657 Descriptors : packing, transport packing, complete and filled packages, tests, roiling tests. Ref. No. ISO 28764985 (EI Price based on 2 pages SIST EN 22876:1996

Foreword ISO (the International Organization for Standardization) is a worldwide federation of national Standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Esch member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, govern- mental and non-governmental, in liaison with ISO, also take part in the work. Draft International Standards adopted by the technical committees are circulated to the member bodies for approval before their acceptance as International Standards by the ISO Council. They are approved in accordance with ISO procedures requiring at least 75 % approval by the member bodies voting. International Standard ISO 2876 was prepared by Technical Committee ISO/TC 122, Packaging. ISO 2876 was first published in 1973. This second edition cancels and replaces the first edition, which has been technically revised as follows : - - a note has been added to clause 1; a new clause on “Package preparation” has been added; a new sub-clause (“lnspection” 7.3) has been added. Users should note that all International Standards undergo revision from time to time and that any reference made herein to any other International Standard implies its latest edition, unless otherwise stated. 0 International Organkation for Standardkation, 1985 Printed in Switzerland SIST EN 22876:1996

INTERNATIONAL STANDARD ISO 28764985 (E) Packaging - Complete, filled transport packages - Rolling test 1 Scope and field of application This International Standard specifies a method for conducting rolling tests on a complete, filled transport package. lt may be performed either as a Single test to investigate the effects of rolling or as part of a sequence of tests designed to measure the ability of a package to withstand a distribution System that in- Ades a rolling hazard. NOTE - A toppling test may be more suitable for packages which are tall in relation to their base dimensions, or the height of which is small by comparison with base dimensions but which may be stored or transported resting on a side face. The toppling test is recommended for packages where the ratio of the longest to the shortest sides is of the Order of 3 : 1, or greater. A method of carrying out a toppling test on a complete, filled transpart package is under preparation. 2 References ISO 2206, Packaging - Compfete, filled transport packages - ldentifica tion of Parts wben testing. ISO 2233, Packaging - Complete,
...
