SIST EN 302 066-2 V1.2.1:2008 is the SIST adoption of an ETSI harmonized European standard for Ground- and Wall-Probing Radar (GPR/WPR) imaging systems. It specifies the article 3.2 radio spectrum and electromagnetic compatibility requirements for these radars, mainly for competent professional users and the people who design, test and assess them.

What does SIST EN 302 066-2 V1.2.1:2008 specify?

SIST EN 302 066-2 V1.2.1:2008 covers GPR/WPR equipment that works in close proximity to the material being investigated. It is a harmonized EN for the R&TTE Directive, and it focuses on the radio and emission conditions needed for conformity.

The scope includes ground probing radars that radiate downward into the ground and wall probing radars that radiate into walls or other absorbing structures such as bridge sides or mine walls. It also covers equipment with integral antennas and equipment with interchangeable imaging heads and an antenna connector. The document excludes radars operated from aircraft or spacecraft.

Annex	What it covers
Annex A	Normative HS Requirements and conformance Test specifications Table (HS-RTT)
Annex B	Informative EN title in the official languages
Annex C	Informative bibliography

The document is organized into scope, references, definitions, technical requirements, testing, and the annexes above.

What are the key requirements of SIST EN 302 066-2 V1.2.1:2008?

SIST EN 302 066-2 V1.2.1:2008 ties conformity to declared operating conditions, limits on operation and emissions, and the test steps that demonstrate those limits. In practice, a manufacturer has to declare the operating environment and power conditions, then show that the equipment stays within the specified radio limits.

Operating conditions

Clause 4.1 requires the equipment to comply within the declared environmental profile, and the provider has to declare that profile. Clause 4.1.2 says the equipment has to meet all requirements over the declared power-supply conditions. This matters because the device must still conform in the real supply and environment it is sold for.

Radio limits

Clause 4.2.1 limits the frequency band of operation to the limits in EN 302 066-1. Clause 4.2.2 limits undesired emissions to the limits in EN 302 066-1. Clause 4.2.3 requires calculation of the maximum mean e.i.r.p. spectral density from peak measurements, and the result must stay within the limits in EN 302 066-1. In practice, these are the core spectrum checks for the product.

Deactivation and testing

Clause 4.2.4 points to the deactivation mechanism requirements in EN 302 066-1. Clause 5 says tests must be run at representative points within the declared environmental profile, and over a sufficient range when performance varies with environment. Clause 5.2 makes the frequency-band and undesired-emission tests part of the essential radio test suite, and clause 5.3 applies the interpretation of results and measurement uncertainty rules from EN 302 066-1.

Annex A shows which requirements are unconditional and which have essential tests. For this standard, the frequency-band and undesired-emissions rows are essential tests, while the maximum mean e.i.r.p. spectral density calculation and deactivation mechanism rows have no test specified in the table.

What terms does SIST EN 302 066-2 V1.2.1:2008 define?

• Environmental profile - the declared range of environmental conditions within which the equipment has to comply.
• Ground Probing Radars (GPR) - radars used for survey and detection while radiating directly downward into the ground.
• Wall Probing Radars (WPR) - radars used for survey and detection by radiating into a wall or similar structure.
• Ground- and Wall-Probing Radar applications (GPR/WPR) - the equipment family covered by this standard.
• maximum mean e.i.r.p. spectral density - the emissions metric calculated from peak measurements and checked against the limits.
• HS-RTT - the table that links each essential requirement to its clause and test specification.

Who uses SIST EN 302 066-2 V1.2.1:2008?

SIST EN 302 066-2 V1.2.1:2008 is used by manufacturers, integrators and compliance teams working on GPR/WPR imaging systems. Test laboratories use it to plan and report the radio tests in clause 5 and Annex A. It is also relevant to conformity assessors and technical file authors who need evidence for article 3.2 of the R&TTE Directive.

What changed in SIST EN 302 066-2 V1.2.1:2008 from the previous edition?

This revision is stated to fully comply with the new ECC DEC (06)08 on GPR/WPR and to add a reference to the combined equipment guide TR 102 070-2. The document history records an earlier publication as V1.1.1 and the present publication as V1.2.1.

Which standards are used with SIST EN 302 066-2 V1.2.1:2008?

• ETSI EN 302 066-1 (V1.2.1) - the companion part that provides the technical characteristics, test methods, emission limits, deactivation mechanism requirements and uncertainty rules used throughout this part.
• ETSI EG 201 399 (V2.1.1) - the guide that shows the modular structure for ETSI standards under the R&TTE Directive.
• ETSI TR 102 070-2 - the combined equipment guide referenced in the revision note.

What does the SIST EN 302 066-2 V1.2.1:2008 document contain?

SIST EN 302 066-2 V1.2.1:2008 contains the technical requirements for operating band, undesired emissions, maximum mean e.i.r.p. spectral density and deactivation mechanism requirements. It also contains the compliance testing clauses for environmental conditions, the essential radio test suites, and the handling of measurement uncertainty. Annex A is the main requirements-to-test mapping table used for presumption of conformity work. Annex B gives the title in many official languages, and Annex C lists the bibliography and related policy documents.
