Execution of concrete structures

(1) This European Standard gives common requirements for execution of concrete structures, it applies to both in-situ works and construction using prefabricated concrete elements.
(2) This standard expects the execution specification to state all the specific requirements relevant to the particular structure.
(3) This standard is applicable to permanent as well as temporary concrete structures.
(4) Additional or different requirements should be considered and, if required, given in the execution specification when using:
a) lightweight aggregate concrete;
b) other materials (e.g. fibres) or constituent materials;
c) special technologies/innovative designs.
(5) This standard does not apply to concrete members used only as equipment or construction aids for the execution.
(6) This standard does not cover the specification, production and conformity of concrete.
(7) This standard is not applicable to the production of precast concrete elements made in accordance with product standards.
(8) This standard does not cover safety and health aspects of execution, or third party safety requirements.
(9) This standard does not cover contractual issues or responsibilities for the identified actions.

Ausführung von Tragwerken aus Beton

1)   Diese Europäische Norm enthält die allgemein üblichen Anforderungen an die Ausführung von Tragwerken aus Beton. Sie gilt sowohl für Ortbetonarbeiten als auch für die Ausführung unter Verwendung von Betonfertigteilen.
2)   Diese Norm setzt voraus, dass die bautechnischen Unterlagen für die Bauausführung alle relevanten Anforderungen enthalten, die für das jeweilige Tragwerk von Bedeutung sind.
3)   Diese Norm ist sowohl für dauerhafte als auch für vorübergehend errichtete Betontragwerke anwendbar.
4)   Zusätzliche oder abweichende Anforderungen sollten berücksichtigt und, falls erforderlich, in den bau-technischen Unterlagen angegeben werden, wenn:
a)   Leichtbeton;
b)   besondere Baustoffe (z. B. Fasern) oder Betonausgangsstoffe;
c)   besondere Technologien / neue Bemessungsmethoden
zur Anwendung kommen.
5)   (Diese Norm gilt nicht für Betonbauteile, die lediglich als Bauhilfsmaßnahmen bei der Bauausführung dienen.
6)   Diese Norm behandelt nicht die Festlegung, Herstellung und Konformität von Beton.
7)   Diese Norm gilt nicht für die Herstellung von Betonfertigteilen, die nach Produktnormen gefertigt werden.
8)   Diese Norm behandelt keine Gesichtspunkte des Arbeitsschutzes bei der Bauausführung oder Sicher-heitsanforderungen durch Dritte.
9)   Diese Norm behandelt keine vertraglichen Aspekte oder Verantwortlichkeiten für die ausgewiesenen Tätigkeiten.
ANMERKUNG   Das Konzept dieser Norm sieht vor, dass ergänzende Anforderungen für einzelne Projekte in den bau¬technischen Unterlagen festgelegt werden können. Auf nationaler Ebene können Festlegungen in einem nationalen Anhang erfolgen, oder allgemein in Europäischen Normen für spezielle Anwendungen, z. B. Normen für den Spezial¬tiefbau.

Exécution des structures en béton

(1) La présente Norme européenne fournit les prescriptions communes pour l'exécution des structures en
béton, elle s'applique à la fois aux travaux sur site et aux constructions utilisant des éléments préfabriqués en
béton.
(2) La présente norme compte sur les spécifications d’exécution pour établir toutes les exigences spécifiques
appropriées pour une structure particulière.
(3) La présente norme est applicable aux ouvrages en béton provisoires aussi bien que définitifs.
(4) Il convient de considérer des prescriptions additionnelles ou différentes, définies le cas échéant par les
spécifications d’exécution, lors de l'emploi :
a) de béton léger ;
b) d'autres matériaux (par exemples fibres) ou constituants ;
c) de technologies particulières/projets innovants.
(5) La présente norme ne s'applique pas aux éléments en béton utilisés uniquement comme matériels ou
équipements d’appoint.
(6) La présente norme ne couvre pas la spécification, la production et la conformité du béton.
(7) La présente norme ne s'applique pas à la production des éléments en béton préfabriqués, réalisés en
conformité avec des normes de produits.
(8) La présente norme ne couvre pas les aspects d'hygiène et de sécurité sur le chantier, ni les mesures de
sécurité assurées par une tierce partie.
(9) La présente norme ne couvre pas les aspects contractuels ni les responsabilités qui s'attachent aux
tâches identifiées.
NOTE La présente norme est conçue pour pouvoir être complétée par des prescriptions supplémentaires pour le
projet individuel dans les spécifications d'exécution, à un niveau national dans une annexe nationale, ou sur une base
générale dans des Normes européennes pour des applications spéciales, par exemple dans des normes pour les travaux
géotechniques spéciaux.

Izvajanje betonskih konstrukcij

(1)Ta evropski standard podaja skupne zahteve za izvajanje betonskih konstrukcij in velja za dela in situ ter za gradnjo z uporabo montažnih betonskih elementov. (2) Ta standard pričakuje, da specifikacija izvajanja navaja vse specifične zahteve, pomembne za določeno konstrukcijo. (3) Ta standard velja za stalne in začasne betonske konstrukcije. (4) Preučiti je treba dodatne ali drugačne zahteve in jih po potrebi navesti v specifikaciji izvajanja, kadar se uporabljajo: a) lahki agregati za beton, b) drugi materiali (npr. vlakna) ali sestavni materiali, c) posebne tehnologije/inovativne zasnove. (5) Ta standard ne velja za betonske elemente, ki se uporabljajo le kot oprema ali gradbena pomoč pri izvajanju. (6) Ta standard ne zajema specifikacije, proizvodnje in skladnosti betona. (7) Ta standard ne velja za proizvodnjo montažnih betonskih elementov, narejenih v skladu s standardi za proizvode. (8) Ta standard ne zajema varnostnih in zdravstvenih vidikov izvajanja ali varnostnih zahtev tretje strani. (9) Ta standard ne zajema pogodbenih vprašanj ali odgovornosti za opredeljene ukrepe.

General Information

Status
Published
Public Enquiry End Date
29-Jun-2009
Publication Date
01-Feb-2010
Current Stage
6100 - Translation of adopted SIST standards (Adopted Project)
Start Date
25-Mar-2010
Due Date
24-Mar-2011
Completion Date
18-Oct-2010

Relations

Buy Standard

Standard
SIST EN 13670:2010
English language
66 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day
Standard – translation
SIST EN 13670:2010
Slovenian language
66 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Izvajanje betonskih konstrukcijAusführung von Tragwerken aus BetonExécution des structures en bétonExecution of concrete structures91.080.40Betonske konstrukcijeConcrete structuresICS:Ta slovenski standard je istoveten z:EN 13670:2009SIST EN 13670:2010en,de01-marec-2010SIST EN 13670:2010SLOVENSKI

STANDARDSIST ENV 13670-1:20031DGRPHãþD
SIST EN 13670:2010
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 13670
December 2009 ICS 91.080.40 Supersedes ENV 13670-1:2000English Version
Execution of concrete structures
Exécution des structures en béton

Ausführung von Tragwerken aus Beton This European Standard was approved by CEN on 17 September 2009.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.

This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,

B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 13670:2009: ESIST EN 13670:2010

EN 13670:2009 (E) 2 Contents Page Foreword ..............................................................................................................................................................5Introduction .........................................................................................................................................................61 Scope ......................................................................................................................................................72 Normative references ............................................................................................................................73 Definitions ..............................................................................................................................................84 Execution management ..................................................................................................................... 114.1 Assumptions ....................................................................................................................................... 114.2 Documentation .................................................................................................................................... 114.2.1 Execution specification ...................................................................................................................... 114.2.2 Quality Plan ......................................................................................................................................... 124.2.3 Execution record documentation ...................................................................................................... 124.2.4 Special record documentation .......................................................................................................... 124.3 Quality Management ........................................................................................................................... 124.3.1 Execution classes ............................................................................................................................... 124.3.2 Inspection of materials and products ............................................................................................... 134.3.3 Inspection of execution ...................................................................................................................... 134.4 Action in the event of a non-conformity ........................................................................................... 145 Falsework and formwork ................................................................................................................... 155.1 Basic requirements............................................................................................................................. 155.2 Materials .............................................................................................................................................. 155.2.1 General ................................................................................................................................................. 155.2.2 Release agents .................................................................................................................................... 155.3 Design and installation of falsework ................................................................................................ 155.4 Design and installation of formwork................................................................................................. 165.5 Special formwork ................................................................................................................................ 165.6 Inserts in formwork and embedded components ........................................................................... 165.6.1 General ................................................................................................................................................. 165.6.2 Making good of temporary recesses and holes .............................................................................. 175.7 Removal of formwork and falsework ................................................................................................ 176 Reinforcement ..................................................................................................................................... 176.1 General ................................................................................................................................................. 176.2 Materials .............................................................................................................................................. 176.3 Bending, cutting, transport and storage of the reinforcement ...................................................... 186.4 Welding ................................................................................................................................................ 196.5 Joints ................................................................................................................................................... 197 Prestressing ........................................................................................................................................ 197.1 General ................................................................................................................................................. 197.2 Materials for prestressing .................................................................................................................. 207.2.1 Post-tensioning systems ................................................................................................................... 207.2.2 Sheaths ................................................................................................................................................ 207.2.3 Tensile elements ................................................................................................................................. 207.2.4 Anchorage elements and accessories ............................................................................................. 207.2.5 Tendon supports................................................................................................................................. 207.2.6 Cement-based grout ........................................................................................................................... 217.2.7 Grease, wax or other products .......................................................................................................... 217.3 Transport and storage ........................................................................................................................ 217.4 Installation of tendons ....................................................................................................................... 217.4.1 General ................................................................................................................................................. 21SIST EN 13670:2010

EN 13670:2009 (E) 3 7.4.2 Pre-tensioned tendons ........................................................................................................................ 217.4.3 Post-tensioned bonded tendons ....................................................................................................... 227.4.4 Internal and external unbonded tendons .......................................................................................... 227.5 Tensioning ........................................................................................................................................... 227.5.1 General ................................................................................................................................................. 227.5.2 Pre-tensioned tendons ........................................................................................................................ 227.5.3 Post-tensioned bonded tendons ....................................................................................................... 237.5.4 Internal and external unbonded tendons .......................................................................................... 237.6 Protective measures (grouting, greasing) ........................................................................................ 237.6.1 General ................................................................................................................................................. 237.6.2 Pre-tensioned tendons ........................................................................................................................ 237.6.3 Post-tensioned bonded tendons ....................................................................................................... 237.6.4 Internal or external unbonded tendons ............................................................................................. 237.6.5 Grouting operations ............................................................................................................................ 237.6.6 Greasing operations ............................................................................................................................ 247.6.7 Sealing .................................................................................................................................................. 248 Concreting ............................................................................................................................................ 248.1 Specification of concrete .................................................................................................................... 248.2 Pre-concreting operations .................................................................................................................. 248.3 Delivery, reception and site transport of fresh concrete ................................................................ 258.4 Placing and compaction ..................................................................................................................... 258.4.1 General ................................................................................................................................................. 258.4.2 Lightweight Aggregate Concrete ....................................................................................................... 268.4.3 Self Compacting Concrete.................................................................................................................. 268.4.4 Sprayed concrete ................................................................................................................................ 268.4.5 Slipforming ........................................................................................................................................... 268.4.6 Underwater concreting ....................................................................................................................... 268.5 Curing and protection ......................................................................................................................... 268.6 Post-concreting operations ................................................................................................................ 288.7 Concreting of composite structures ................................................................................................. 288.8 Surface Finish ...................................................................................................................................... 289 Execution with precast concrete elements ....................................................................................... 289.1 General ................................................................................................................................................. 289.2 Factory produced precast elements .................................................................................................. 289.3 Site manufactured precast elements ................................................................................................. 299.4 Handling and storage .......................................................................................................................... 299.4.1 General ................................................................................................................................................. 299.4.2 Handling ............................................................................................................................................... 299.4.3 Storage ................................................................................................................................................. 299.5 Placing and adjustment ...................................................................................................................... 299.5.1 General ................................................................................................................................................. 299.5.2 Placing .................................................................................................................................................. 299.6 Jointing and completion works ......................................................................................................... 309.6.1 General ................................................................................................................................................. 309.6.2 In-situ works ........................................................................................................................................ 309.6.3 Structural connections ....................................................................................................................... 3010 Geometrical tolerances ....................................................................................................................... 3110.1 General ................................................................................................................................................. 3110.2 Reference system ................................................................................................................................ 3210.3 Base supports (foundations).............................................................................................................. 3210.4 Columns and walls .............................................................................................................................. 3210.5 Beams and slabs ................................................................................................................................. 3410.6 Sections ................................................................................................................................................ 3510.7 Surfaces and edge straightness ........................................................................................................ 3710.8 Tolerances for holes and inserts ....................................................................................................... 37Annex A (informative)

Guidance on documentation ..................................................................................... 38Annex B (informative)

Guidance on Quality Management ............................................................................ 43SIST EN 13670:2010

EN 13670:2009 (E) 4 Annex C (informative)

Guidance on falsework and formwork ..................................................................... 45Annex D (informative)

Guidance on reinforcement ...................................................................................... 47Annex E (informative)

Guidance on prestressing ......................................................................................... 49Annex F (informative)

Guidance on concreting ............................................................................................ 52Annex G (informative)

Guidance on geometrical tolerances ....................................................................... 58Annex H (informative)

Guidance on National Annex .................................................................................... 65Bibliography ..................................................................................................................................................... 66 SIST EN 13670:2010

EN 13670:2009 (E) 5 Foreword This document (EN 13670:2009) has been prepared by Technical Committee CEN/TC 104 “Concrete and related products”, the secretariat of which is held by DIN. This European Standard shall be given the status of a national standard, either by publication of an identical text or by endorsement, at the latest by June 2010, and conflicting national standards shall be withdrawn at the latest by June 2010. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights. This document supersedes ENV 13670-1:2000. This document has been prepared under a mandate given to CEN by the European Commission and the European Free Trade Association, and supports essential requirements of EC Directive(s). Because of the close connection between design rules and rules for execution, CEN/TC 104/SC 2 has developed this standard in liaison with CEN/TC 250/SC 2, and CEN TC 229 According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.

.SIST EN 13670:2010

EN 13670:2009 (E) 6 Introduction This European Standard applies to the execution of concrete structures to achieve the intended level of safety and serviceability during its service life, as given by EN 1990, Eurocode – Basis of structural design, EN 1992, Eurocode 2 – Design of concrete structures and EN 1994, Eurocode 4 – Design of composite steel and concrete structures, with the Nationally Determined Parameters (NDPs) applicable in the place of use. This European Standard has three functions: a) to transfer the requirements set during design to the constructor i.e. to be a link between design and execution; b) to give a set of standardized technical requirements for the execution when ordering a concrete structure; c) to serve as a check list for the designer to ensure that he provides the constructor with all relevant technical information for the execution of the structure (see Annex A). In order to achieve these objectives, the design shall result in a set of documents and drawings giving all information required for the execution of the work in accordance with the plans. This set of documents is, in this European Standard, referred to as the "execution specification". This standard leaves a number of items open to be decided in the execution specification.

In areas where national provisions shall apply these should be referred to in the execution specification. It is recognised in this European Standard that areas such as detailed requirements for competence of personnel, and details related to the Quality Management are within the competence of the Member States.

If the national CEN member publishes a National Annex to this standard, it may refer to national standards approved and published by the CEN member or national provisions, which supplement this standard, alternatively the supplementing rules can be given directly in the National Annex

A detailed overview of the system of European Standards related to concrete works is shown in Figure 1.

Figure 1 — System of European Standards as basis for design, execution and materials selection for concrete works (only main modules) SIST EN 13670:2010

EN 13670:2009 (E) 7 1 Scope (1) This European Standard gives common requirements for execution of concrete structures, it applies to both in-situ works and construction using prefabricated concrete elements.

(2) This standard expects the execution specification to state all the specific requirements relevant to the particular structure. (3) This standard is applicable to permanent as well as temporary concrete structures. (4) Additional or different requirements should be considered and, if required, given in the execution specification when using: a) lightweight aggregate concrete; b) other materials (e.g. fibres) or constituent materials; c) special technologies/innovative designs. (5) This standard does not apply to concrete members used only as equipment or construction aids for the execution. (6) This standard does not cover the specification, production and conformity of concrete. (7) This standard is not applicable to the production of precast concrete elements made in accordance with product standards. (8) This standard does not cover safety and health aspects of execution, or third party safety requirements. (9) This standard does not cover contractual issues or responsibilities for the identified actions. NOTE It is within the concept of this standard that supplementing requirements can be given for the individual project in the execution specification, on a national level in a national annex, or on a general basis in European standards for special applications e.g. standards for special geotechnical works. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 206-1, Concrete

Part 1: Specification, performance, production and conformity EN 446, Grout for prestressing tendons

Grouting procedures EN 447, Grout for prestressing tendons
Basic requirements EN 523, Steel strip sheaths for prestressing tendons

Terminology, requirements, quality control EN 10080, Steel for the reinforcement of concrete

Weldable reinforcing steel
General EN ISO 17660-1, Welding
Welding of reinforcing steel
Part 1: Load-bearing welded joints (ISO 17660-1:2006) EN ISO 17660-2, Welding
Welding of reinforcing steel
Part 2: Non load-bearing welded joints (ISO 17660-2:2006) SIST EN 13670:2010

EN 13670:2009 (E) 8 ETAG 013, Guideline for European Technical Approval of Post-tensioning kits for prestressing of structures These are commonly called post-tensioning systems1)

3 Terms and definitions For the purposes of this document, the following terms and definitions apply. 3.1 backpropping propping installed at levels below the slab that supports the falsework in order to distribute the load to suitable support 3.2 chair for reinforcement device used to secure the position between reinforcement layers e.g. supporting top reinforcement in a slab 3.3 construction works everything that is constructed or results from construction operations [EN 1990] NOTE The term covers both building and civil engineering works. It refers to the complete construction works comprising structural and non-structural and geotechnical elements. 3.4 constructor organization executing the works 3.5 erection specification documents covering all drawings, technical data and requirements required for the safe erection of precast elements 3.6 execution all activities carried out for the physical completion of the work, i.e. procurement, scaffolding, formwork, reinforcing, concreting, curing, erection of precast elements etc., and the inspection and documentation thereof 3.7 execution class classified set of requirements specified for the execution of the works as a whole or an individual component 3.8 execution specification documents covering all drawings, technical data and requirements necessary for the execution of a particular project NOTE The execution specification is not one document but signifies the total sum of documents required for the execution of the work as provided by the designer to the constructor. It includes the project specification prepared to supplement and qualify the requirements of this European Standard, as well as referring to the national provisions relevant in the place of use.

1) Available free online at www.eota.be SIST EN 13670:2010

EN 13670:2009 (E) 9 3.9 falsework temporary support for a part of a structure while it is not self-supporting and for associated service load 3.10 formwork structure, permanent or temporary, for containing poured concrete, moulding it to the required dimensions and supporting it until it is able to support itself NOTE Formwork consists of the face contact material and the bearers directly supporting the face contact material. 3.11 inspection conformity evaluation by observation and judgement accompanied as appropriate by measurement, testing or gauging

[EN ISO 9000] 3.12 method statement documentation describing the methods and procedures to be used to perform the work 3.13 permitted deviation permitted algebraic differences between the limits of size and the corresponding reference size [Adapted from ISO 1803:1997, 3.8] 3.14 precast concrete element concrete element cast and cured in a place other than the final location of use (factory produced or site manufactured) NOTE 1 Precast concrete element manufactured in compliance with relevant European product standard is called precast concrete product. NOTE 2 In this standard the shorter terms "precast element" and "precast product" are used. 3.15 project specification project specific document describing the requirements applicable for the particular project 3.16 quality plan document specifying which procedures and associated resources shall be applied by whom and when to a specific project, product, process or contract [EN ISO 9000:2005, 3.7.5] NOTE Guidance might be found in EN ISO 9000 concerning the content of a quality plan. 3.17 reference line line defined in the execution specification to which positions are related SIST EN 13670:2010

EN 13670:2009 (E) 10 3.18 secondary line any line used for the purpose of setting-out the proposed building and for checking and compliance of the building or building parts [ISO 4463-1:1989, 4.4] 3.19 spacer device used to secure correct spacing between the formwork and the reinforcement 3.20 surface finish description of the appearance of the concrete surface including aspects of geometry, texture, colour etc. 3.21 temporary structure structure designed for a short design working life 3.22 tolerance difference between upper limit of size and the lower limit of size

[ISO 1803:1997, 3.11] NOTE 1 Geometrical tolerances for precast concrete elements are subdivided as follows: a) production tolerances as defined in the product standards; b) erection tolerances i.e. geometrical tolerances relating to location, verticality, horizontality or other characteristics of the construction assembly; c) construction tolerances i.e. geometrical tolerances that are a combination of production, site construction and erection tolerances. NOTE 2 Tolerance is an absolute value without sign, it is however commonly expressed by "the sum of the ± permitted deviation" so that the value of the tolerance is implicit. 3.23 normal tolerances basic l

...
