SIST EN 60534-5:2004

Industrial-process control valves -- Part 5: Marking

specifies mandatory and supplementary markings of control valves. Some mandatory markings may be inappropriate for some valves of special design, and some supplementary markings may be appropriate only to specific types of control valves. It is recommended that the marking of all valves conform to this standard whenever possible unless otherwise agreed between the manufacturer and purchaser.

Stellventile für die Prozessregelung -- Teil 5: Kennzeichnung

Vannes de régulation des processus industriels -- Partie 5: Marquage

spécifie les marquages obligatoires et supplémentaires des vannes de régulation. Certains marquages obligatoires peuvent ne pas convenir à des vannes de certains types ou de conception spéciale, et quelques marquages supplémentaires peuvent seulement convenir à des types spécifiques de vannes de régulation. Il est recommandé, dans la mesure du possible, que les marquages pour toutes les vannes soient conformes à la présente norme à moins d'un accord entre le fabricant et l'acheteur.

Industrial-process control valves - Part 5: Marking

General Information

• Status: Published
• Publication Date: 31-May-2004
• ICS: 23.060.40 - Pressure regulators
• ICS: 25.040.40 - Industrial process measurement and control
• Technical Committee: MKP - Industrial-process measurement and control
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jun-2004
• Due Date: 01-Jun-2004
• Completion Date: 01-Jun-2004
• Ref Project: EN 60534-5:2004 - Industrial-process control valves - Part 5: Marking

Overview

EN 60534-5:2004 (IEC 60534-5:2004) defines the marking requirements for industrial-process control valves. The standard specifies which markings are mandatory and which are supplementary, how and where markings should be applied (integral on the body, on a marking plate or on an identification plate), and guidance when space or special designs limit marking. EN 60534-5:2004 supports traceability, safe installation, correct valve selection and ongoing maintenance by standardizing valve identification and labelling.

Key topics and requirements

• Mandatory vs supplementary markings: Mandatory markings are normally integral or on a marking plate and must be permanent; supplementary markings are typically on an identification plate.
• Mandatory items (examples):
  • Nominal size (DN, NPS)
  • Pressure rating (PN, Class)
  • Material of body shell
  • Manufacturer’s name or trade mark
  • Serial number or permanent identification
• Supplementary items (examples):
  • Manufacturer’s type/model
  • Material of trim or lining
  • Rated flow coefficient (Kv, Cv)
  • Rated travel, inherent flow characteristic, tag number, actuator bench setting
• Location rules:
  • Body markings must be permanent and integral or on a securely fixed marking plate.
  • Flange/end-connection specifics (e.g., ring joint number) must be marked on flanges if applicable.
  • Identification plates may be removable when user-modifiable characteristics are recorded.
• Special cases and limitations:
  • Valves smaller than DN 50 (NPS 2) may omit some body markings; these should then appear on the identification plate.
  • Special-service valves (oxygen, nuclear, fugitive emissions) should carry additional agreed markings.
• Symbol and material notation: Use ISO references where possible; recognized abbreviations (e.g., CF8M / 316) are acceptable.

Applications and users

EN 60534-5:2004 is essential for:

• Valve manufacturers (ensuring compliant, traceable products)
• Plant engineers and procurement professionals (specifying and verifying valve identity and ratings)
• Piping and instrumentation (P&ID) engineers and maintenance teams (correct installation, replacement and repair)
• Inspectors and QA/quality control (verifying conformity and safety) Practical uses include procurement specifications, asset tagging, maintenance records, and ensuring compatibility with piping and pressure systems.

Related standards

• EN 19 - Marking of metallic valves
• IEC 60534-1 - Control valve terminology and general considerations
• ISO 5209 - General purpose industrial valves - Marking
• EN 1092 / ISO 7005 - Flange identification and PN/class definitions
• EN 1333 - Definition and selection of PN

Using EN 60534-5:2004 for valve marking improves safety, traceability and interoperability across industrial installations.
