SIST EN 62041:2011
EUROPEAN STANDARD
EN 62041
NORME EUROPÉENNE
December 2010
EUROPÄISCHE NORM
ICS 29.180; 33.100 Supersedes EN 62041:2003
English version
Safety of transformers, reactors, power supply units and combinations
thereof -
EMC requirements
(IEC 62041:2010)
Sécurité des transformateurs, bobines Sicherheit von Transformatoren, Drosseln,
d'inductance, blocs d'alimentation et des Netzgeräten und entsprechenden
combinaisons de ces éléments - Kombinationen -
Exigences CEM EMV-Anforderungen
(CEI 62041:2010) (IEC 62041:2010)
This European Standard was approved by CENELEC on 2010-12-01. CENELEC members are bound to comply
with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard
the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on
application to the Central Secretariat or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CENELEC member into its own language and notified
to the Central Secretariat has the same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus,
the Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy,
Latvia, Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia,
Spain, Sweden, Switzerland and the United Kingdom.
CENELEC
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
Management Centre: Avenue Marnix 17, B - 1000 Brussels
© 2010 CENELEC - All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 62041:2010 E
---------------------- Page: 3 ----------------------
SIST EN 62041:2011
EN 62041:2010 - 2 -
Foreword
The text of document 96/358/FDIS, future edition 2 of IEC 62041, prepared by IEC TC 96, Transformers,
reactors, power supply units, and combinations thereof, was submitted to the IEC-CENELEC parallel vote
and was approved by CENELEC as EN 62041 on 2010-12-01.
This European Standard supersedes EN 62041:2003.
This EN 62041:2010 includes the following significant technical changes with respect to EN 62041:2003:
– the frequency range for tests according to EN 61000-4-3 has been extended above 1 GHz according
to technologies used in this frequency area;
– the testing requirements according to EN 61000-4-11 have been amended significantly;
– the inclusion of a clause on tests in series production;
– the inclusion of a new clause on measurement uncertainly; and
– the inclusion of requirements on DC power ports and telecommunication ports.
It has the status of a product family EMC standard in accordance with IEC Guide 107:2009,
Electromagnetic compatibility – Guide to the drafting of electromagnetic compatibility publications.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN and CENELEC shall not be held responsible for identifying any or all such patent
rights.
The following dates were fixed:
– latest date by which the EN has to be implemented
at national level by publication of an identical
(dop) 2011-09-01
national standard or by endorsement
– latest date by which the national standards conflicting
(dow) 2013-12-01
with the EN have to be withdrawn
Annex ZA has been added by CENELEC.
__________
Endorsement notice
The text of the International Standard IEC 62041:2010 was approved by CENELEC as a European
Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standards indicated:
IEC 60065 NOTE Harmonized as EN 60065.
IEC 60601-1 NOTE Harmonized as EN 60601-1.
IEC 60950-1 NOTE Harmonized as EN 60950-1.
IEC 61010-1 NOTE Harmonized as EN 61010-1.
IEC 61204-3 NOTE Harmonized as EN 61204-3.
IEC 61347-1 NOTE Harmonized as EN 61347-1.
IEC 62040-2 NOTE Harmonized as EN 62040-2.
CISPR 11 NOTE Harmonized as EN 55011.
---------------------- Page: 4 ----------------------
SIST EN 62041:2011
- 3 - EN 62041:2010
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
NOTE When an international publication has been modified by common modifications, indicated by (mod), the relevant EN/HD
applies.
Publication Year Title EN/HD Year
IEC 61000-3-2 - Electromagnetic compatibility (EMC) - EN 61000-3-2 -
Part 3-2: Limits - Limits for harmonic current
emissions (equipment input current ≤ 16 A per
phase)
IEC 61000-3-3 - Electromagnetic compatibility (EMC) - EN 61000-3-3 -
Part 3-3: Limits - Limitation of voltage
changes, voltage fluctuations and flicker in
public low-voltage supply systems, for
equipment with rated current ≤16 A per phase
and not subject to conditional connection
IEC 61000-3-11 - Electromagnetic compatibility (EMC) - EN 61000-3-11 -
Part 3-11: Limits - Limitation of voltage
changes, voltage fluctuations and flicker in
public low-voltage supply systems -
Equipment with rated current ≤ 75 A and
subject to conditional connection
IEC 61000-3-12 - Electromagnetic compatibility (EMC) - EN 61000-3-12 -
Part 3-12: Limits - Limits for harmonic currents
produced by equipment connected to public
low-voltage systems with input current > 16 A
and ≤ 75 A per phase
IEC 61000-4-2 - Electromagnetic compatibility (EMC) - EN 61000-4-2 -
Part 4-2: Testing and measurement
techniques - Electrostatic discharge immunity
test
IEC 61000-4-3 - Electromagnetic compatibility (EMC) - EN 61000-4-3 -
Part 4-3: Testing and measurement
techniques - Radiated, radio-frequency,
electromagnetic field immunity test
IEC 61000-4-4 - Electromagnetic compatibility (EMC) - EN 61000-4-4 -
Part 4-4: Testing and measurement
techniques - Electrical fast transient/burst
immunity test
IEC 61000-4-5 - Electromagnetic compatibility (EMC) - EN 61000-4-5 -
Part 4-5: Testing and measurement
techniques - Surge immunity test
---------------------- Page: 5 ----------------------
SIST EN 62041:2011
EN 62041:2010 - 4 -
Publication Year Title EN/HD Year
IEC 61000-4-6 - Electromagnetic compatibility (EMC) - EN 61000-4-6 -
Part 4-6: Testing and measurement
techniques - Immunity to conducted
disturbances, induced by radio-frequency
fields
IEC 61000-4-11 - Electromagnetic compatibility (EMC) - EN 61000-4-11 -
Part 4-11: Testing and measurement
techniques - Voltage dips, short interruptions
and voltage variations immunity tests
IEC 61000-6-3 - Electromagnetic compatibility (EMC) - EN 61000-6-3 -
Part 6-3: Generic standards - Emission
standard for residential, commercial and light-
industrial environments
IEC 61000-6-4 - Electromagnetic compatibility (EMC) - EN 61000-6-4 -
Part 6-4: Generic standards - Emission
standard for industrial environments
IEC 61558 Series Safety of power transformers, EN 61558 Series
power supplies, reactors
and similar products
CISPR 14-1 2005 Electromagnetic compatibility - EN 55014-1 2006
Requirements for household appliances,
electric tools and similar apparatus -
Part 1: Emission
CISPR 16-1-2 2003 Specification for radio disturbance and EN 55016-1-2 2004
immunity measuring apparatus and methods -
Part 1-2: Radio disturbance and immunity
measuring apparatus - Ancillary equipment -
Conducted disturbances
CISPR 16-2-1 2008 Specification for radio disturbance and EN 55016-2-1 2009
immunity measuring apparatus and methods -
Part 2-1: Methods of measurement of
disturbances and immunity - Conducted
disturbance measurements
CISPR 16-2-3 - Specification for radio disturbance and EN 55016-2-3 -
immunity measuring apparatus and methods -
Part 2-3: Methods of measurement of
disturbances and immunity - Radiated
disturbance measurements
CISPR 22 (mod) - Information technology equipment - Radio EN 55022 -
disturbance characteristics - Limits and
methods of measurement
---------------------- Page: 6 ----------------------
SIST EN 62041:2011
IEC 62041
®
Edition 2.0 2010-08
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Safety of transformers, reactors, power supply units and combinations thereof –
EMC requirements
Sécurité des transformateurs, bobines d’inductance, blocs d'alimentation et des
combinaisons de ces élements –
Exigences CEM
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
R
CODE PRIX
ICS 29.180, 33.100 ISBN 978-2-88912-157-1
® Registered trademark of the International Electrotechnical Commission
Marque déposée de la Commission Electrotechnique Internationale
---------------------- Page: 7 ----------------------
SIST EN 62041:2011
– 2 – 62041 © IEC:2010
CONTENTS
FOREWORD.3
1 Scope.5
2 Normative references.5
3 Terms and definitions .6
4 Classification .8
5 Test specifications .8
5.1 Immunity .8
5.1.1 Immunity against disturbances .8
5.1.2 Test levels .10
5.2 Emission .14
5.2.1 Categories .14
5.2.2 Test levels .15
6 Specification of environment .17
Bibliography .18
Figure 1 – Example of ports .7
Table 1 – Electrostatic discharges – Test levels at enclosure.10
Table 2 – Radiated, radio frequency electromagnetic field – Test levels at enclosure .11
Table 3 – Electrical fast transient/burst – Test levels at signal port .11
Table 4 – Electrical fast transient/burst – Test levels at input and output DC power ports .12
Table 5 – Electrical fast transient/burst – Test levels at input and output AC power ports .12
Table 6 – Conducted disturbances, inducted by radio-frequency fields – Test levels at
a
signal ports and input and output at DC and AC power ports.13
Table 7 – Surge – Test levels at signal ports .13
Table 8 – Surge – Test levels at input and output DC power ports.13
Table 9 – Surge – Test levels at input and output AC power ports.14
Table 10 – Voltage dips – Test levels at input AC power ports .14
Table 11 – Voltage interruptions – Test levels at input AC power ports.14
Table 12 – Harmonics and flicker – Test levels at low voltage AC mains ports .15
Table 13 – Conducted radio disturbances – Test levels at signal ports
(telecommunications/network ports) .16
Table 14 – Conducted radio disturbances – Test levels at DC power ports).16
Table 15 – Conducted radio disturbances – Test levels at low voltage AC mains ports .16
Table 16 – Radiated radio disturbances – Test levels at enclosure port.17
---------------------- Page: 8 ----------------------
SIST EN 62041:2011
62041 © IEC:2010 – 3 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
SAFETY OF TRANSFORMERS, REACTORS,
POWER SUPPLY UNITS AND COMBINATIONS THEREOF –
EMC REQUIREMENTS
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International standard IEC 62041 has been prepared by Technical Committee 96: Transformers,
reactors, power supply units and combinations thereof.
This second edition cancels and replaces the first edition published in 2003. It constitutes a
technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
– the frequency range for tests according to IEC 61000-4-3 has been extended above 1 GHz
according to technologies used in this frequency area;
– the testing requirements according to IEC 61000-4-11 have been amended significantly;
– the inclusion of a clause on tests in series production;
– the inclusion of a new clause on measurement uncertainly, and
– the inclusion of requirements on DC power ports and telecommunication ports.
---------------------- Page: 9 ----------------------
SIST EN 62041:2011
– 4 – 62041 © IEC:2010
It has the status of a product family EMC standard in accordance with IEC Guide 107:2009,
Electromagnetic compatibility – Guide to the drafting of electromagnetic compatibility
publications.
The text of this standard is based on the following documents:
FDIS Report on voting
96/358/FDIS 96/367/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
This standard is to be used in conjunction with IEC 61558 series.
In this standard, the following print types are used:
– requirements proper: in roman type;
– test specifications: in italic type;
– explanatory matter: in smaller roman type.
In the text of this publication, the words in bold are defined in Clause 3 of this standard and in
the IEC 61558 series.
The committee has decided that the contents of this publication will remain unchanged until the
stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data related to
the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
NOTE The attention of National Committees is drawn to the fact that equipment manufacturers and testing
organizations may need a transitional period following publication of a new, amended or revised IEC publication in
which to make products in accordance with the new requirements and to equip themselves for conducting new or
revised tests.
It is the recommendation of the committee that the content of this publication be adopted for implementation
nationally not earlier than 12 months from the date of publication.
---------------------- Page: 10 ----------------------
SIST EN 62041:2011
62041 © IEC:2010 – 5 –
SAFETY OF TRANSFORMERS, REACTORS,
POWER SUPPLY UNITS AND COMBINATIONS THEREOF –
EMC REQUIREMENTS
1 Scope
This international product family standard applies to transformers, reactors, power supply
units and combinations thereof covered by the IEC 61558 series of standards. This standard
deals with the electromagnetic compatibility requirements for emission and immunity within the
frequency range 0 Hz - 400 GHz. No measurement needs to be performed at frequencies
where no requirement is specified.
Transformers, reactors, power supply units and combinations thereof delivered with or
incorporated in an appliance or equipment should follow the relevant EMC standard applicable
to that appliance or equipment. However, this standard may be used as a guide to test the
transformers, reactors, power supply units and combinations thereof separately before
incorporating them in the appliance or equipment.
This EMC standard covers performance only. Other operations of the transformers, reactors
and power supply units (e.g. simulated faults in the electric circuitry for testing purposes or
functional safety due to the effects of the electromagnetic phenomena, or evaluation of human
being for exposure to electromagnetic fields (EMF)) have not been taken into consideration in
this standard.
NOTE When EUT (Equipment under Test) is used, it covers transformers, reactors, power supply units and
combinations thereof where applicable.
This standard does not apply to:
– uninterruptible power supplies (UPS) covered by IEC 62040 series;
– power supply units covered by IEC 61204-3,
(i.e. DC-DC converters, DC power and distribution equipment and power supply units for
use in applications covered by IEC 60950-1, IEC 61010-1, IEC 60601-1, IEC 60065 and IEC
62368-1);
– power supplies and converters for use with or in products covered by IEC 61347-1.
2 Normative references
The following referenced documents are indispensable for the application of this document. For
dated references, only the edition cited applies. For undated references, the latest edition of
the referenced document (including any amendments) applies.
IEC 61000-3-2, Electromagnetic compatibility (EMC) – Part 3-2: Limits – Limits for harmonic
current emissions (equipment input current ≤16 A per phase)
IEC 61000-3-3, Electromagnetic compatibility (EMC) – Part 3-3: Limits – Limitation of voltage
changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment
with rated current ≤ 16 A per phase and not subject to conditional connection
IEC 61000-3-11, Electromagnetic compatibility (EMC) – Part 3-11: Limits – Limitation of voltage
changes, voltage fluctuations and flicker in public low-voltage supply systems – Equipment with
rated current ≤75 A and subject to conditional connection
---------------------- Page: 11 ----------------------
SIST EN 62041:2011
– 6 – 62041 © IEC:2010
IEC 61000-3-12, Electromagnetic compatibility (EMC) – Part 3-12: Limits – Limits for harmonic
currents produced by equipment connected to public low-voltage systems with input current
>16 A and ≤75 A per phase
IEC 61000-4-2, Electromagnetic compatibility (EMC) – Part 4-2: Testing and measurement
techniques – Electrostatic discharge immunity test
IEC 61000-4-3, Electromagnetic compatibility (EMC) – Part 4-3: Testing and measurement
techniques – Radiated, radio-frequency, electromagnetic field immunity test
IEC 61000-4-4, Electromagnetic compatibility (EMC) – Part 4-4: Testing and measurement
techniques – Electrical fast transient/burst immunity test
IEC 61000-4-5, Electromagnetic compatibility (EMC) – Part 4-5: Testing and measurement
techniques – Surge immunity test
IEC 61000-4-6, Electromagnetic compatibility (EMC) – Part 4-6: Testing and measurement
techniques – Immunity to conducted disturbances, induced by radio-frequency fields
IEC 61000-4-11, Electromagnetic compatibility (EMC) – Part 4-11: Testing and measurement
techniques – Voltage dips, short interruptions and voltage variations immunity tests
IEC 61000-6-3, Electromagnetic compatibility (EMC) – Part 6-3: Generic standards – Emission
standard for residential, commercial and light-industrial environments
IEC 61000-6-4, Electromagnetic compatibility (EMC) – Part 6-4: Generic standards – Emission
standard for industrial environments
IEC 61558 (all parts), Safety of power transformers, power supplies, reactors and similar
products
CISPR 14-1:2005, Electromagnetic compatibility – Requirements for household appliances,
electric tools and similar apparatus – Part 1: Emission
CISPR 16-1-2:2003, Specification for radio disturbance and immunity measuring apparatus and
methods – Part 1-2: Radio disturbance and immunity measuring apparatus – Ancillary
equipment – Conducted disturbances
CISPR 16-2-1:2008, Specification for radio disturbance and immunity measuring apparatus and
methods – Part 2-1: Methods of measurement of disturbances and immunity – Conducted
disturbance measurements
CISPR 16-2-3, Specification for radio disturbance and immunity measuring apparatus and
methods – Part 2-3: Methods of measurement of disturbances and immunity – Radiated
disturbance measurements
CISPR 22, Information technology equipment – Radio disturbance characteristics – Limits and
methods of measurement
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
environment 1
residential, commercial and light-industrial locations, both indoor and outdoor
---------------------- Page: 12 ----------------------
SIST EN 62041:2011
62041 © IEC:2010 – 7 –
NOTE 1 Locations which are characterised by being supplied directly from a low voltage from the public mains
network are considered to be residential, commercial or light-industrial.
NOTE 2 The following list, although not comprehensive, gives an indication of location which are included:
– residential properties, e.g. houses, apartments, hotels, etc.;
– retail outlets, e.g. shops, supermarkets, etc.;
– business premises, e.g. offices, banks, etc.;
– areas of public entertainment, e.g. cinemas, public bars, dance halls, restaurants, etc.;
– outdoor locations, e.g. petrol stations, car parks, amusement and sports centres, etc.;
– light-industrial locations, e.g. workshops, laboratories, service centres, etc.
3.2
environment 2
industrial environments, both indoor and outdoor
NOTE Industrial locations are connected to a power network supplied from a high or medium transformer
dedicated to the supply of an installation feeding manufacturing or similar plant, and in addition characterised by
the existence of one or more of the following:
– industrial, scientific and medical (ISM) apparatus (as defined in CISPR 11);
– heavy inductive or capacitive loads are frequently switched;
– currents and associated magnetic fields are high.
3.3
equipment under test
EUT
it refers to transformers, reactors, power supply units and combinations thereof where
applicable
3.4
port
particular interface of the specified EUT with the external electromagnetic environment (see
Figure 1)
NOTE In some cases, different ports may be combined.
Enclosure port
Signal port AC power port
Transformer
(EUT)
DC power port
IEC 1982/10
Figure 1 – Example of ports
3.5
enclosure port
physical boundary of the EUT which electromagnetic fields may radiate through or impinge on
3.6
cable port
port at which a conductor or a cable is connected to the EUT
NOTE Examples are signal and power ports.
---------------------- Page: 13 ----------------------
SIST EN 62041:2011
– 8 – 62041 © IEC:2010
3.7
signal port
port at which a conductor or cable intended to carry signals is connected to the EUT
NOTE Examples are analogue inputs, outputs and control lines, data busses, communication networks, etc.
3.8
power port
port at which a conductor or cable carrying the primary electrical power needed for the
operation (functioning) of an EUT is connected
3.9
public mains network
power lines to which all categories of consumers have access to and that are operated by an
electrical power supply and/or distribution organization for the purpose of supplying electrical
energy
3.10
long distance lines
lines connected to a signal port and which inside a building are longer than 30 m, or which
leave the building (including lines of outdoor installations)
3.11
low voltage
voltage having a value below a conventionally adopted limit
[IEC 60050-151:2001, 151-15-03]
4 Classification
EUT are classified according to the incorporation of components and electronic circuits as
follows:
– category 0: EUT with or without passive protection component(s) and without electronic
circuits;
– category 1: EUT with passive components, and without electronic circuits;
– category 2: EUT with electronic circuits.
NOTE 1 Examples of passive protection components are fuses, thermal links, thermal cut-outs, circuit-breakers,
PTC’s, NTC’s and resistors.
NOTE 2 Examples of passive components are capacitors, inductors, diodes, LED’s, relays, VDR’s.
NOTE 3 Examples of electronic circuits are active semiconductors.
5 Test specifications
5.1 Immunity
5.1.1 Immunity against di
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
