SIST-TP CEN/CLC/TR 17602-70-23:2021
(Main)Space product assurance - Materials, mechanical parts and processes obsolescence management handbook
Space product assurance - Materials, mechanical parts and processes obsolescence management handbook
This Handbook provides guidelines to manage obsolescence of Materials, Mechanical Parts and Processes (in-house and sub-contracted).
It is useful for any actor of the European Space sector.
It covers Materials, Mechanical Parts and Processes (MMPP) used in flight hardware as well as ground support equipment (including test systems) and materials or tools used during process (not in the final product) and skills (knowhow).
It is not within the scope of this Handbook to address EEE components and software.
This document describes the general causes of obsolescences and introduces the concepts of proactive and reactive obsolescence management, depending of the programme phase.
Raumfahrtproduktsicherung - Handbuch für Obsoleszenzmanagement von Materialien, mechanischen Bauteilen und Prozessen
Assurance produit des projets spatiaux - Manuel de gestion de l’obsolescence des matériaux, des pièces mécaniques et des procédés
Zagotavljanje kakovosti proizvodov v vesoljski tehniki - Priročnik za upravljanje zastarelosti materialov, mehanskih delov in procesov
General Information
Standards Content (Sample)
SLOVENSKI STANDARD
SIST-TP CEN/CLC/TR 17602-70-23:2021
01-december-2021
Zagotavljanje kakovosti proizvodov v vesoljski tehniki - Priročnik za upravljanje
zastarelosti materialov, mehanskih delov in procesov
Space product assurance - Materials, mechanical parts and processes obsolescence
management handbook
Raumfahrtproduktsicherung - Handbuch für Obsoleszenzmanagement von Materialien,
mechanischen Bauteilen und Prozessen
Assurance produit des projets spatiaux - Manuel de gestion de l’obsolescence des
matériaux, des pièces mécaniques et des procédés
Ta slovenski standard je istoveten z: CEN/CLC/TR 17602-70-23:2021
ICS:
03.120.99 Drugi standardi v zvezi s Other standards related to
kakovostjo quality
49.140 Vesoljski sistemi in operacije Space systems and
operations
SIST-TP CEN/CLC/TR 17602-70-23:2021 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
---------------------- Page: 2 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
TECHNICAL REPORT
CEN/CLC/TR 17602-70-
23
RAPPORT TECHNIQUE
TECHNISCHER BERICHT
October 2021
ICS 49.140
English version
Space product assurance - Materials, mechanical parts and
processes obsolescence management handbook
Assurance produit des projets spatiaux - Manuel de Raumfahrtproduktsicherung - Handbuch für
gestion de l'obsolescence des matériaux, des pièces Obsoleszenzmanagement von Materialien,
mécaniques et des procédés mechanischen Bauteilen und Prozessen
This Technical Report was approved by CEN on 16 August 2021. It has been drawn up by the Technical Committee CEN/CLC/JTC
5.
CEN and CENELEC members are the national standards bodies and national electrotechnical committees of Austria, Belgium,
Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy,
Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia,
Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
CEN-CENELEC Management Centre:
Rue de la Science 23, B-1040 Brussels
© 2021 CEN/CENELEC All rights of exploitation in any form and by any means Ref. No. CEN/CLC/TR 17602-70-23:2021 E
reserved worldwide for CEN national Members and for
CENELEC Members.
---------------------- Page: 3 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Table of contents
European Foreword . 4
Scope . 5
References . 6
Terms, definitions and abbreviated terms . 7
3.1 Terms from other standards . 7
3.2 Terms specific to the present handbook . 7
3.3 Abbreviated terms. 8
Causes of obsolescence and purpose of obsolescence management . 10
4.1 Introduction . 10
4.2 Causes . 10
4.3 Purpose . 10
Overview of obsolescence management process . 12
5.1 Obsolescence management team . 12
5.2 Obsolescence management approach . 13
5.2.1 Proactive approach . 13
5.2.2 Reactive approach . 13
5.2.3 Obsolescence management in space programmes . 13
5.2.4 Obsolescence management plan . 14
5.3 Obsolescence management database . 14
Relevant practices for obsolescence management . 15
6.1 Proactive approach . 15
6.1.1 Overview . 15
6.1.2 Establishment of an obsolescence-awareness culture . 16
6.1.3 Knowledge of the MMPP . 16
6.1.4 Supply chain management . 17
6.1.5 Watch. 18
6.1.6 Obsolescence risk analysis for MMPP, programme risk analysis and
risk mitigation actions . 19
6.2 Reactive approach . 22
6.2.1 Overview . 22
6.2.2 Verify obsolescence information. 22
6.2.3 Communication . 23
2
---------------------- Page: 4 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
6.2.4 Application case analysis . 23
6.2.5 Obsolescence treatment . 23
Obsolescence data management . 25
7.1 In-house data management . 25
7.2 Network communication. 25
Annex A Obsolescence information template . 26
Annex B Example of content of obsolescence management database . 27
Annex C Example of obsolescence management plan . 28
Annex D Information about the REACH regulation . 29
Background . 29
D.1.1 Overview . 29
D.1.2 Definition of terms . 29
D.1.3 Relationship between substances, mixtures, and articles . 30
Technical consequences of REACH . 31
Additional information . 36
Figures
Figure 5-1: Obsolescence management versus space programme phases . 14
Figure 6-1: Proactive approach best practices scheme . 15
Figure 6-2: Reactive approach best practices scheme . 22
Tables
Table D-1 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Possibly long-term . 33
Table D-2 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Possibly mid-term . 34
Table D-3 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Imminent . 35
3
---------------------- Page: 5 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
European Foreword
This document (CEN/CLC/TR 17602-70-23:2021) has been prepared by Technical Committee
CEN/CLC/JTC 5 “Space”, the secretariat of which is held by DIN.
It is highlighted that this technical report does not contain any requirement but only collection of data
or descriptions and guidelines about how to organize and perform the work in support of EN 16602-
70-23.
This Technical report (CEN/CLC/TR 17602-70-23:2021) originates from ECSS-Q-HB-70-23A.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such
patent rights.
This document has been prepared under a mandate given to CEN by the European Commission and
the European Free Trade Association.
This document has been developed to cover specifically space systems and has therefore precedence
over any TR covering the same scope but with a wider domain of applicability (e.g.: aerospace).
4
---------------------- Page: 6 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Scope
This Handbook provides guidelines to manage obsolescence of Materials, Mechanical Parts and
Processes (in-house and sub-contracted).
It is useful for any actor of the European Space sector.
It covers Materials, Mechanical Parts and Processes (MMPP) used in flight hardware as well as
ground support equipment (including test systems) and materials or tools used during process (not in
the final product) and skills (know-how).
It is not within the scope of this Handbook to address EEE components and software.
This document describes the general causes of obsolescences and introduces the concepts of proactive
and reactive obsolescence management, depending of the programme phase.
5
---------------------- Page: 7 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
References
EN Reference Reference in text Title
EN 16601-00-01 ECSS-S-ST-00-01 ECSS system – Glossary of terms
EN 16602-70 ECSS-Q-ST-70 Space product assurance – Materials, mechanical parts and
processes
EN 16602-70-71 ECSS-Q-ST-70-71 Space product assurance – Material, processes and their
data selection
EN 16601-10 ECSS-M-ST-10 Space project management – Project planning and
implementation
EN 16601-80 ECSS-M-ST-80 Space project management – Risk management
EN 62402:2007 Obsolescence management - Application guide
T. Rohr et al., ISMSE-12 Impact of REACH Legislation on European Space
ESTEC Noordwijk, The Programs
Netherlands, 2012
M. Chevalier et al., ISMSE- A method to customize qualification of substitutes in case
13 Pau, France, 2015 of material or process obsolescence
6
---------------------- Page: 8 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Terms, definitions and abbreviated terms
3.1 Terms from other standards
a. For the purpose of this document, the terms and definitions from ECSS-S-ST-00-01 apply, in
particular the following terms:
1. design
2. development
3. life cycle
4. lifetime
5. material
b. For the purpose of this document, the terms and definitions from ECSS-Q-ST-70 apply, in
particular the following term:
1. mechanical part
2. process
3.2 Terms specific to the present handbook
3.2.1 bill of MMPP
list of materials, processes or mechanical parts that are needed to manufacture or repair an end
product
NOTE This is reported in Declared Materials List (DML), Declared Processes
List (DPL) and Declared Mechanical Parts List (DMPL).
3.2.2 criticality
measure of severity of the consequences of MMPP obsolescence with regard to its use
3.2.3 obsolescence
transition from availability to unavailability of a material, mechanical part or process from the
manufacturer or supplier
NOTE The unavailability can be permanent or temporary.
7
---------------------- Page: 9 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
3.2.4 obsolescence management network
network of persons in charge of collecting, transmitting and recording all the information concerning
obsolescence issues and responsible to implement risk mitigation actions and obsolescence treatment
actions
NOTE Members of the obsolescence network can represent different
functions (e.g. procurement, quality, production, and design office)
3.2.5 obsolescence manager
person in charge of coordinating and supervising obsolescence management at company level and
following up obsolescence treatment projects progress
3.2.6 obsolescence risk analysis
assessment of the probability and severity of the risk of obsolescence and prioritization of the
obsolescence risk
3.2.7 proactive obsolescence management
actions to anticipate obsolescence and to mitigate the risks linked to obsolescence issues
3.2.8 reactive obsolescence management
reactive strategy consists in reacting only when the obsolescence is proven
1 Obsolescence is considered as proven when a discontinuance date is
known.
2 The discontinuance date can be transmitted through a formal
document by the supplier or related to date of ban determined by a
regulation.
3.3 Abbreviated terms
For the purpose of this document, the following abbreviated terms apply:
Abbreviation Meaning
application for authorization
AfA
assembly, integration and test
AIT
Aerospace and Defense Industries Association of Europe
ASD
bill of material
BOM
Chemical Abstract Service Number
CAS Number
classification and labelling
C&L
classification, labelling and packaging
CLP
carcinogenic, mutagenic, reprotoxic
CMR
community rolling action plan
CoRAP
commercial off-the-shelf
COTS
declared materials list
DML
declared mechanical parts list
DMPL
8
---------------------- Page: 10 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Abbreviation Meaning
declared processes list
DPL
Export Administration Regulations
EAR
European Chemical Agency
ECHA
European Community number
EC Number
European Economic Area
EEA
electrical, electronic and electromechanical
EEE
environment, health and safety
EHS
European Union
EU
Groupement des industries françaises aéronautiques et
GIFAS
spatiales (French Aerospace Industries Association)
handbook
HB
harmonised classification and labelling
HCL
International Traffic in Arms Regulations
ITAR
materials, mechanical parts and processes
MMPP
materials and processes
M&P
Materials, Mechanical Parts and Processes Control Board
MPCB
Materials and Processes Technology Board
MPTB
member state
MS
ozone depleting substance
ODS
obsolescence management
OM
obsolescence management plan
OMP
Public Activities Coordination Tool
PACT
persistent, bioaccumulative and toxic
PBT
persistent organic pollutants
POP
research and development
R&D
Registration, Evaluation and Authorization of Chemicals
REACH
(European regulation)
risk management option analysis
RMOA
restriction of hazardous substances
RoHS
safety data sheet
SDS
substitute it now list
SIN List
substance of very high concern
SVHC
technology readiness level
TRL
very persistent and very bioaccumulative
vPvB
9
---------------------- Page: 11 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Causes of obsolescence and purpose of
obsolescence management
4.1 Introduction
Obsolescence can affect all space products throughout their lifecycle. Through obsolescence
management appropriate actions are put in place to minimise detrimental impact and costs
throughout the product life.
4.2 Causes
The main causes of obsolescence are:
a. Regulations and their evolution: Environmental regulations such as REACH, health and safety.
b. Import – export constraints: export control (e.g. ITAR), export licence, embargo.
c. Changes from suppliers such as
1. product evolution (formulation, raw material supply chain, packaging, product
properties, deviation from original specification),
2. manufacturing processes and means, streamlining of product ranges, manufacturing
stop, change of manufacturing location,
3. product designation, industrial re-organization.
d. Supplier force major circumstances: bankruptcies, industrial accidents (e.g. fire, explosion), loss
of know-how, natural disasters (e.g. flooding, storm, earthquake).
e. Market competitiveness such as too low volume of production, outdated technology, indirect
impact of environmental regulations.
NOTE Indirect impact of environmental regulations means that even if the
space sector is out of the scope (e.g. RoHS), the market availability is
driven by much larger actors that need to comply and drive
alternative product development.
f. Loss of employee specific skills and company know-how.
4.3 Purpose
The increasing number of obsolescence issues affects the space sector particularly due to the specific
characteristics of space programmes:
a. Long life cycles (especially for space transportation).
b. Low purchase volumes.
10
---------------------- Page: 12 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
c. Long MMPP qualification time (e.g. high performance requirements, high safety standards,
complex interactions between systems, and multinational programmes).
d. Low production volumes.
e. Use of proven technologies (heritage).
f. Complex contractual supply chain.
Obsolescence management of MMPP is an added-value to limit impacts of obsolescence to:
a. Ensure undisrupted manufacturing and maintenance of the space hardware during the whole
programme life time.
b. Avoid redesign during a later stage of the space programme.
c. Minimise cost and planning time.
d. Meet customer requirements related to obsolescence management.
e. Guarantee quality and sustainability of the supply chain.
f. Avoid use a non-qualified MMPP.
11
---------------------- Page: 13 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Overview of obsolescence management
process
5.1 Obsolescence management team
The establishment of an obsolescence management team is key of success of obsolescence
management (OM), including the identification of a person devoted to centralize information. This
person is responsible for the control of information as follows:
a. Set up actions to get the information as soon as possible
b. Information analysis
c. Communication of the information within internal network
This person can rely on the obsolescence management-dedicated network. This network can be
composed of different representatives that include the following functions:
a. Programme and project management
b. Procurement
c. M&P support
d. Quality control
e. Production
f. Design
g. Environment, health and safety
h. Product stewardship (product management and regulation specialist)
i. Legal support (REACH, export control …)
It is important that within companies a reciprocal communication line between OM management team
and other company members is established.
The OM team manages the implementation and the follow-up of actions, e.g. preventing obsolescence,
mitigating risk, treating obsolescence. It is responsible for the communication of the obsolescence
information to other members of the company.
It is essential that the OM team members are clearly identified inside the company. By that, any
member of the company becoming aware of obsolescence issues, informs the obsolescence
management team in timely manner.
12
---------------------- Page: 14 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
5.2 Obsolescence management approach
5.2.1 Proactive approach
The proactive OM approach consists of tracking any potential cause of obsolescence in order to
anticipate future obsolescence cases. It also aims at:
a. anticipating strategies in order to have a mitigation solution once obsolescence occurs.
b. not selecting obsolete or limited-life MMPP as alternative solution or as baseline in new
developments
The proactive approach is implemented at each step of the life of space products to meet product
lifetime requirements. It is important that the proactive approach is applied to all stages of a product
life-cycle, starting from the design phase.
This approach includes continuous monitoring for MMPP availability that allows identifying or
predicting their obsolescence date. This monitoring also allows assessing the risk of obsolescence
occurrence and its criticality for space hardware.
5.2.2 Reactive approach
Following the reactive strategy, actions are taken only when the obsolescence is confirmed, e.g.
identification of alternative solutions, stock-piling, no action.
5.2.3 Obsolescence management in space programmes
Obsolescence management involves implementing scheduled and coordinated actions in order to
secure the availability of a product during its entire life-cycle, through technical and economical
means (e.g. replacement, stockpiling). It can be implemented, as early as possible for better
anticipation, during all phases of a space programme such as design definition, development,
production, use, maintenance, spares and repairs.
Whenever possible, priority can be given to the proactive over reactive approach. A general scheme
describing the interaction between OM and space programme phases is shown in Figure 5-1.
Obsolescence management starts with the implementation of an obsolescence management plan. It
can start as early as the feasibility phase of space programmes by setting up an approach for
obsolescence management.
Implementation of proactive measures can start as soon as possible, for example from preliminary
definition, before bills of MMPP are available. A preliminary item list can be assessed in order to
identify obsolete or potential obsolete items. Also the manufacturer or supplier can be required to
inform the customer about the MMPP obsolescence status.
A detailed process to verify obsolescence issues can be typically implemented after PDR during the
detailed definition phase (phase C). During this stage, appropriate actions can be carried out in
accordance to the defined OM approach. A periodical review of obsolescence risks for products and
technologies can be managed at least at each design review throughout the whole programme.
It is important to perform communication between the OM team and other members of the company
in a continuous way, and is prerequisite for successful obsolescence management. It is also important
to collect, analyze, store and distribute information (knowledge management) to improve the
company OM process.
13
---------------------- Page: 15 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Space programme phases:
Preparatory phase Development phase Vehicle exploitation phase
Phase 0
Phase B Phase D Phase E
Phase C
Phase A Phase F
Mission Analysis /
Preliminary Qualification & Operation &
Needs Feasibility Detailed definition Disposal
definition Production Utilisation
identification
Obsolescence management:
Design for obsolescence
Implement proactive measures as early
as possible, preferably in the design
phase
Plan for obsolescence Check for new obsolescence&Act as planned
Develop obsolescence management
Check for new obsolescence to ensure early
approach in the framework of
reaction, consult the OM approach and apply an
product life cycle management
appropriate reactive option to handle occurred
obsolescence
Knowledge management
Communicating
[Based on ECSS-M-ST-10 and EN 62402:2007]
Figure 5-1: Obsolescence management versus space programme phases
5.2.4 Obsolescence management plan
Implementing an obsolescence management plan can be an effective way to mitigate obsolescence risk
especially for long-term space programmes. An example of the content of an obsolescence
management plan is provided in the Annex C. This plan is part of the proactive approach and can
complement the project risk management process.
5.3 Obsolescence management database
To anticipate and treat obsolescence, it is important to gather all the information in an obsolescence
management database independent of the considered OM approach (proactive or reactive). An
example of the content for an OM database is given in Annex B.
14
---------------------- Page: 16 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
Relevant practices for obsolescence
management
6.1 Proactive approach
6.1.1 Overview
Proactive best practices are summarized in Figure 6-1. The steps coloured in orange are explained in
the present section 6.1.
Bill of
MMPP
- Knowledge of
MMPP
- Watch
- Supply chain
management
Establish
obsolescence
risk level for
each MMPP
Risk analysis
vs impact on
program
yes
Risk?
Risk
no
mitigation
actions
Monitoring
of
MMPP list
Manufacturing
Figure 6-1: Proactive approach best practices scheme
15
---------------------- Page: 17 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
6.1.2 Establishment of an obsolescence-awareness culture
Establishing an obsolescence-awareness culture inside a company can constitute a change of mindset
in programme management, through communication and participation of all company employees. It
allows to anticipate obsolescence issues as integral part of project management. Obsolescence
management training can be an appropriate way to raise obsolescence awareness. It is important to
involve all members of the company, especially newcomers in such a training.
6.1.3 Knowledge of the MMPP
Prerequisite of obsolescence management is the knowledge of MMPP, this means to have the most
complete information about the composition of selected materials, mechanical parts and formulations
used during manufacturing processes. The detailed knowledge about MMPP allows the identification
of MMPP changes, including the identification of substances that are part of MMPP and face
obsolescence risks due to regulatory impact. The relevant information can be collected from suppliers
or sub-contractors or obtained in-house and be included in the obsolescence management database.
The following information can be collected:
a. Information from suppliers
1. Safety data sheets (SDS) analysis: The information relevant to be analyzed in SDSs are
CAS or EC numbers, changes to be checked and verified with supplier (change of CAS or
EC numbers, change of substance percentages, addition or removal of substances). It is
important to ask the supplier on a regular basis for an update of SDSs, especially for
products less frequently procured
2. Interviews of suppliers: Information about precursor or auxiliary substances,
intermediates, information about the supplier’s obsolescence risk management process
3. Request for procurement specification changes
4. Certificates of performance and associated test data
5. Supplier’s declarations, incl. REACH article 33 declarations
b. Information obtained in-house
Any change in performance and possibly composition can be tracked through incoming
inspections tests or monitoring of drift of process control parameters.
c. Information obtained from subcontractors
Information can be gathered through basic contractual documentation to be delivered to
customers, such as DML, DMPL and DPL. It is the responsibility of each customer in the supply
chain to ask its subcontractors to provide their obsolescence analysis. Such request can be done
e.g. during materials process control boards (MPCB), or even earlier during a preliminary
review milestone.
1 The MMPP lists do not provide the entire design information.
2 Performing MPCBs even for recurrent equipment, can be
recommended to track obsolescence issues.
d. Any other information
Information can also be found in literature, patents, and through networking. All the gathered
information can be systematically included in a dedicated tool for MMPP knowledge
management. It is important to maintain it up-to-date in order to facilitate subsequent risk
analysis.
16
---------------------- Page: 18 ----------------------
SIST-TP CEN/CLC/TR 17602-70-23:2021
CEN/CLC/TR 17602-70-23:2021 (E)
6.1.4 Supply chain management
6.1.4.1 Overview
It is important to involve actively downstream supply chain actors in obsolescence management. It
can be done by specifying contractual obsolescence management requirements, through suppliers and
subcontractors monitoring, or by dedicated procurement specifications with suppliers.
6.1.4.2 Contractual obsolescence management requirements to supply
chain
Contractual clauses fo
...
SLOVENSKI STANDARD
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
01-julij-2021
Zagotavljanje kakovosti proizvodov v vesoljski tehniki - Priročnik za upravljanje
zastarelosti materialov, mehanskih delov in procesov
Space product assurance - Materials, mechanical parts and processes obsolescence
management handbook
Produktsicherung in der Raumfahrt - Handbuch zum Obsoleszenzmanagement für
Materialien, mechanische Teile und Prozesse
Assurance produit des projets spatiaux - Manuel de gestion de l’obsolescence des
matériaux, composants mécaniques et procédés
Ta slovenski standard je istoveten z: FprCEN/CLC/TR 17602-70-23
ICS:
03.120.99 Drugi standardi v zvezi s Other standards related to
kakovostjo quality
49.140 Vesoljski sistemi in operacije Space systems and
operations
kSIST-TP FprCEN/CLC/TR 17602-70- en,fr,de
23:2021
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
---------------------- Page: 2 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
TECHNICAL REPORT
FINAL DRAFT
FprCEN/CLC/TR 17602-
RAPPORT TECHNIQUE
70-23
TECHNISCHER BERICHT
April 2021
ICS 49.140
English version
Space product assurance - Materials, mechanical parts and
processes obsolescence management handbook
Assurance produit des projets spatiaux - Manuel de Produktsicherung in der Raumfahrt - Handbuch zum
gestion de l'obsolescence des matériaux, composants Obsoleszenzmanagement für Materialien, mechanische
mécaniques et procédés Teile und Prozesse
This draft Technical Report is submitted to CEN members for Vote. It has been drawn up by the Technical Committee
CEN/CLC/JTC 5.
CEN and CENELEC members are the national standards bodies and national electrotechnical committees of Austria, Belgium,
Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy,
Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia,
Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are
aware and to provide supporting documentation.
Warning : This document is not a Technical Report. It is distributed for review and comments. It is subject to change without
notice and shall not be referred to as a Technical Report.
CEN-CENELEC Management Centre:
Rue de la Science 23, B-1040 Brussels
© 2021 CEN/CENELEC All rights of exploitation in any form and by any means Ref. No. FprCEN/CLC/TR 17602-70-23:2021 E
reserved worldwide for CEN national Members and for
CENELEC Members.
---------------------- Page: 3 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
Table of contents
European Foreword . 4
1 Scope . 5
2 References . 6
3 Terms, definitions and abbreviated terms . 7
3.1 Terms from other standards . 7
3.2 Terms specific to the present handbook . 7
3.3 Abbreviated terms. 8
4 Causes of obsolescence and purpose of obsolescence management . 10
4.1 Introduction . 10
4.2 Causes . 10
4.3 Purpose . 10
5 Overview of obsolescence management process . 12
5.1 Obsolescence management team . 12
5.2 Obsolescence management approach . 13
5.2.1 Proactive approach . 13
5.2.2 Reactive approach . 13
5.2.3 Obsolescence management in space programmes . 13
5.2.4 Obsolescence management plan . 14
5.3 Obsolescence management database . 14
6 Relevant practices for obsolescence management . 15
6.1 Proactive approach . 15
6.1.1 Overview . 15
6.1.2 Establishment of an obsolescence-awareness culture . 16
6.1.3 Knowledge of the MMPP . 16
6.1.4 Supply chain management . 17
6.1.5 Watch. 18
6.1.6 Obsolescence risk analysis for MMPP, programme risk analysis and
risk mitigation actions . 19
6.2 Reactive approach . 22
6.2.1 Overview . 22
6.2.2 Verify obsolescence information. 22
6.2.3 Communication . 23
2
---------------------- Page: 4 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
6.2.4 Application case analysis . 23
6.2.5 Obsolescence treatment . 23
7 Obsolescence data management . 25
7.1 In-house data management . 25
7.2 Network communication. 25
Annex A Obsolescence information template . 26
Annex B Example of content of obsolescence management database . 27
Annex C Example of obsolescence management plan . 28
Annex D Information about the REACH regulation . 29
D.1 Background . 29
D.1.1 Overview . 29
D.1.2 Definition of terms . 29
D.1.3 Relationship between substances, mixtures, and articles . 30
D.2 Technical consequences of REACH . 31
D.3 Additional information . 36
Figures
Figure 5-1: Obsolescence management versus space programme phases . 14
Figure 6-1: Proactive approach best practices scheme . 15
Figure 6-2: Reactive approach best practices scheme . 22
Tables
Table D-1 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Possibly long-term . 33
Table D-2 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Possibly mid-term . 34
Table D-3 : Summary of legal obligations of industry, possible associated actions,
schedules as a function of regulatory step - Imminent . 35
3
---------------------- Page: 5 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
European Foreword
This document (FprCEN/CLC/TR 17602-70-23:2021) has been prepared by Technical Committee
CEN/CLC/JTC 5 “Space”, the secretariat of which is held by DIN.
It is highlighted that this technical report does not contain any requirement but only collection of data
or descriptions and guidelines about how to organize and perform the work in support of EN 16602-70-
23.
This Technical report (FprCEN/CLC/TR 17602-70-23:2021) originates from ECSS-Q-HB-70-23A.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such
patent rights.
This document has been prepared under a mandate given to CEN by the European Commission and
the European Free Trade Association.
This document has been developed to cover specifically space systems and has therefore precedence
over any TR covering the same scope but with a wider domain of applicability (e.g.: aerospace).
This document is currently submitted to the CEN CONSULTATION.
4
---------------------- Page: 6 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
1
Scope
This Handbook provides guidelines to manage obsolescence of Materials, Mechanical Parts and
Processes (in-house and sub-contracted).
It is useful for any actor of the European Space sector.
It covers Materials, Mechanical Parts and Processes (MMPP) used in flight hardware as well as ground
support equipment (including test systems) and materials or tools used during process (not in the final
product) and skills (know-how).
It is not within the scope of this Handbook to address EEE components and software.
This document describes the general causes of obsolescences and introduces the concepts of proactive
and reactive obsolescence management, depending of the programme phase.
5
---------------------- Page: 7 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
2
References
EN Reference Reference in text Title
EN 16601-00-01 ECSS-S-ST-00-01 ECSS system – Glossary of terms
EN 16602-70 ECSS-Q-ST-70 Space product assurance – Materials, mechanical parts
and processes
EN 16602-70-71 ECSS-Q-ST-70-71 Space product assurance – Material, processes and their
data selection
EN 16601-10 ECSS-M-ST-10 Space project management – Project planning and
implementation
EN 16601-80 ECSS-M-ST-80 Space project management – Risk management
EN 62402:2007 Obsolescence management - Application guide
T. Rohr et al., ISMSE-12 Impact of REACH Legislation on European Space
ESTEC Noordwijk, The Programs
Netherlands, 2012
M. Chevalier et al., ISMSE- A method to customize qualification of substitutes in
13 Pau, France, 2015 case of material or process obsolescence
6
---------------------- Page: 8 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
3
Terms, definitions and abbreviated terms
3.1 Terms from other standards
a. For the purpose of this document, the terms and definitions from ECSS-S-ST-00-01 apply, in
particular the following terms:
1. design
2. development
3. life cycle
4. lifetime
5. material
b. For the purpose of this document, the terms and definitions from ECSS-Q-ST-70 apply, in
particular the following term:
1. mechanical part
2. process
3.2 Terms specific to the present handbook
3.2.1 bill of MMPP
list of materials, processes or mechanical parts that are needed to manufacture or repair an end product
NOTE This is reported in Declared Materials List (DML), Declared Processes
List (DPL) and Declared Mechanical Parts List (DMPL).
3.2.2 criticality
measure of severity of the consequences of MMPP obsolescence with regard to its use
3.2.3 obsolescence
transition from availability to unavailability of a material, mechanical part or process from the
manufacturer or supplier
NOTE The unavailability can be permanent or temporary.
3.2.4 obsolescence management network
network of persons in charge of collecting, transmitting and recording all the information concerning
obsolescence issues and responsible to implement risk mitigation actions and obsolescence treatment
actions
NOTE Members of the obsolescence network can represent different functions
(e.g. procurement, quality, production, and design office)
7
---------------------- Page: 9 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
3.2.5 obsolescence manager
person in charge of coordinating and supervising obsolescence management at company level and
following up obsolescence treatment projects progress
3.2.6 obsolescence risk analysis
assessment of the probability and severity of the risk of obsolescence and prioritization of the
obsolescence risk
3.2.7 proactive obsolescence management
actions to anticipate obsolescence and to mitigate the risks linked to obsolescence issues
3.2.8 reactive obsolescence management
reactive strategy consists in reacting only when the obsolescence is proven
NOTE 1 Obsolescence is considered as proven when a discontinuance date is
known.
NOTE 2 The discontinuance date can be transmitted through a formal
document by the supplier or related to date of ban determined by a
regulation.
3.3 Abbreviated terms
For the purpose of this document, the following abbreviated terms apply:
Abbreviation Meaning
application for authorization
AfA
assembly, integration and test
AIT
Aerospace and Defense Industries Association of Europe
ASD
bill of material
BOM
Chemical Abstract Service Number
CAS Number
classification and labelling
C&L
classification, labelling and packaging
CLP
carcinogenic, mutagenic, reprotoxic
CMR
community rolling action plan
CoRAP
commercial off-the-shelf
COTS
declared materials list
DML
declared mechanical parts list
DMPL
declared processes list
DPL
Export Administration Regulations
EAR
European Chemical Agency
ECHA
European Community number
EC Number
European Economic Area
EEA
electrical, electronic and electromechanical
EEE
8
---------------------- Page: 10 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
Abbreviation Meaning
environment, health and safety
EHS
European Union
EU
Groupement des industries françaises aéronautiques et
GIFAS
spatiales (French Aerospace Industries Association)
handbook
HB
harmonised classification and labelling
HCL
International Traffic in Arms Regulations
ITAR
materials, mechanical parts and processes
MMPP
materials and processes
M&P
Materials, Mechanical Parts and Processes Control Board
MPCB
Materials and Processes Technology Board
MPTB
member state
MS
ozone depleting substance
ODS
obsolescence management
OM
obsolescence management plan
OMP
Public Activities Coordination Tool
PACT
persistent, bioaccumulative and toxic
PBT
persistent organic pollutants
POP
research and development
R&D
Registration, Evaluation and Authorization of Chemicals
REACH
(European regulation)
risk management option analysis
RMOA
restriction of hazardous substances
RoHS
safety data sheet
SDS
substitute it now list
SIN List
substance of very high concern
SVHC
technology readiness level
TRL
very persistent and very bioaccumulative
vPvB
9
---------------------- Page: 11 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
4
Causes of obsolescence and purpose of
obsolescence management
4.1 Introduction
Obsolescence can affect all space products throughout their lifecycle. Through obsolescence
management appropriate actions are put in place to minimise detrimental impact and costs throughout
the product life.
4.2 Causes
The main causes of obsolescence are:
a. Regulations and their evolution: Environmental regulations such as REACH, health and safety.
b. Import – export constraints: export control (e.g. ITAR), export licence, embargo.
c. Changes from suppliers such as
1. product evolution (formulation, raw material supply chain, packaging, product properties,
deviation from original specification),
2. manufacturing processes and means, streamlining of product ranges, manufacturing stop,
change of manufacturing location,
3. product designation, industrial re-organization.
d. Supplier force major circumstances: bankruptcies, industrial accidents (e.g. fire, explosion), loss
of know-how, natural disasters (e.g. flooding, storm, earthquake).
e. Market competitiveness such as too low volume of production, outdated technology, indirect
impact of environmental regulations.
NOTE Indirect impact of environmental regulations means that even if the
space sector is out of the scope (e.g. RoHS), the market availability is
driven by much larger actors that need to comply and drive alternative
product development.
f. Loss of employee specific skills and company know-how.
4.3 Purpose
The increasing number of obsolescence issues affects the space sector particularly due to the specific
characteristics of space programmes:
a. Long life cycles (especially for space transportation).
b. Low purchase volumes.
c. Long MMPP qualification time (e.g. high performance requirements, high safety standards,
complex interactions between systems, and multinational programmes).
d. Low production volumes.
10
---------------------- Page: 12 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
e. Use of proven technologies (heritage).
f. Complex contractual supply chain.
Obsolescence management of MMPP is an added-value to limit impacts of obsolescence to:
a. Ensure undisrupted manufacturing and maintenance of the space hardware during the whole
programme life time.
b. Avoid redesign during a later stage of the space programme.
c. Minimise cost and planning time.
d. Meet customer requirements related to obsolescence management.
e. Guarantee quality and sustainability of the supply chain.
f. Avoid use a non-qualified MMPP.
11
---------------------- Page: 13 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
5
Overview of obsolescence management
process
5.1 Obsolescence management team
The establishment of an obsolescence management team is key of success of obsolescence management
(OM), including the identification of a person devoted to centralize information. This person is
responsible for the control of information as follows:
a. Set up actions to get the information as soon as possible
b. Information analysis
c. Communication of the information within internal network
This person can rely on the obsolescence management-dedicated network. This network can be
composed of different representatives that include the following functions:
a. Programme and project management
b. Procurement
c. M&P support
d. Quality control
e. Production
f. Design
g. Environment, health and safety
h. Product stewardship (product management and regulation specialist)
i. Legal support (REACH, export control …)
It is important that within companies a reciprocal communication line between OM management team
and other company members is established.
The OM team manages the implementation and the follow-up of actions, e.g. preventing obsolescence,
mitigating risk, treating obsolescence. It is responsible for the communication of the obsolescence
information to other members of the company.
It is essential that the OM team members are clearly identified inside the company. By that, any member
of the company becoming aware of obsolescence issues, informs the obsolescence management team in
timely manner.
12
---------------------- Page: 14 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
5.2 Obsolescence management approach
5.2.1 Proactive approach
The proactive OM approach consists of tracking any potential cause of obsolescence in order to
anticipate future obsolescence cases. It also aims at:
a. anticipating strategies in order to have a mitigation solution once obsolescence occurs.
b. not selecting obsolete or limited-life MMPP as alternative solution or as baseline in new
developments
The proactive approach is implemented at each step of the life of space products to meet product lifetime
requirements. It is important that the proactive approach is applied to all stages of a product life-cycle,
starting from the design phase.
This approach includes continuous monitoring for MMPP availability that allows identifying or
predicting their obsolescence date. This monitoring also allows assessing the risk of obsolescence
occurrence and its criticality for space hardware.
5.2.2 Reactive approach
Following the reactive strategy, actions are taken only when the obsolescence is confirmed, e.g.
identification of alternative solutions, stock-piling, no action.
5.2.3 Obsolescence management in space programmes
Obsolescence management involves implementing scheduled and coordinated actions in order to
secure the availability of a product during its entire life-cycle, through technical and economical means
(e.g. replacement, stockpiling). It can be implemented, as early as possible for better anticipation, during
all phases of a space programme such as design definition, development, production, use, maintenance,
spares and repairs.
Whenever possible, priority can be given to the proactive over reactive approach. A general scheme
describing the interaction between OM and space programme phases is shown in Figure 5-1.
Obsolescence management starts with the implementation of an obsolescence management plan. It can
start as early as the feasibility phase of space programmes by setting up an approach for obsolescence
management.
Implementation of proactive measures can start as soon as possible, for example from preliminary
definition, before bills of MMPP are available. A preliminary item list can be assessed in order to identify
obsolete or potential obsolete items. Also the manufacturer or supplier can be required to inform the
customer about the MMPP obsolescence status.
A detailed process to verify obsolescence issues can be typically implemented after PDR during the
detailed definition phase (phase C). During this stage, appropriate actions can be carried out in
accordance to the defined OM approach. A periodical review of obsolescence risks for products and
technologies can be managed at least at each design review throughout the whole programme.
It is important to perform communication between the OM team and other members of the company in
a continuous way, and is prerequisite for successful obsolescence management. It is also important to
collect, analyze, store and distribute information (knowledge management) to improve the company
OM process.
13
---------------------- Page: 15 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
Space programme phases:
Preparatory phase Development phase Vehicle exploitation phase
Phase 0
Phase B Phase D Phase E
Phase C
Phase A Phase F
Mission Analysis /
Preliminary Qualification & Operation &
Needs Feasibility Detailed definition Disposal
definition Production Utilisation
identification
Obsolescence management:
Design for obsolescence
Implement proactive measures as early
as possible, preferably in the design
phase
Plan for obsolescence Check for new obsolescence&Act as planned
Develop obsolescence management
Check for new obsolescence to ensure early
approach in the framework of
reaction, consult the OM approach and apply an
product life cycle management
appropriate reactive option to handle occurred
obsolescence
Knowledge management
Communicating
[Based on ECSS-M-ST-10 and EN 62402:2007]
Figure 5-1: Obsolescence management versus space programme phases
5.2.4 Obsolescence management plan
Implementing an obsolescence management plan can be an effective way to mitigate obsolescence risk
especially for long-term space programmes. An example of the content of an obsolescence management
plan is provided in the Annex C. This plan is part of the proactive approach and can complement the
project risk management process.
5.3 Obsolescence management database
To anticipate and treat obsolescence, it is important to gather all the information in an obsolescence
management database independent of the considered OM approach (proactive or reactive). An example
of the content for an OM database is given in Annex B.
14
---------------------- Page: 16 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
6
Relevant practices for obsolescence
management
6.1 Proactive approach
6.1.1 Overview
Proactive best practices are summarized in Figure 6-1. The steps coloured in orange are explained in the
present section 6.1.
Bill of
MMPP
- Knowledge of
MMPP
- Watch
- Supply chain
management
Establish
obsolescence
risk level for
each MMPP
Risk analysis
vs impact on
program
yes
Risk?
Risk
no
mitigation
actions
Monitoring
of
MMPP list
Manufacturing
Figure 6-1: Proactive approach best practices scheme
15
---------------------- Page: 17 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
6.1.2 Establishment of an obsolescence-awareness culture
Establishing an obsolescence-awareness culture inside a company can constitute a change of mindset in
programme management, through communication and participation of all company employees. It
allows to anticipate obsolescence issues as integral part of project management. Obsolescence
management training can be an appropriate way to raise obsolescence awareness. It is important to
involve all members of the company, especially newcomers in such a training.
6.1.3 Knowledge of the MMPP
Prerequisite of obsolescence management is the knowledge of MMPP, this means to have the most
complete information about the composition of selected materials, mechanical parts and formulations
used during manufacturing processes. The detailed knowledge about MMPP allows the identification
of MMPP changes, including the identification of substances that are part of MMPP and face
obsolescence risks due to regulatory impact. The relevant information can be collected from suppliers
or sub-contractors or obtained in-house and be included in the obsolescence management database.
The following information can be collected:
a. Information from suppliers
1. Safety data sheets (SDS) analysis: The information relevant to be analyzed in SDSs are CAS
or EC numbers, changes to be checked and verified with supplier (change of CAS or EC
numbers, change of substance percentages, addition or removal of substances). It is
important to ask the supplier on a regular basis for an update of SDSs, especially for
products less frequently procured
2. Interviews of suppliers: Information about precursor or auxiliary substances,
intermediates, information about the supplier’s obsolescence risk management process
3. Request for procurement specification changes
4. Certificates of performance and associated test data
5. Supplier’s declarations, incl. REACH article 33 declarations
b. Information obtained in-house
Any change in performance and possibly composition can be tracked through incoming
inspections tests or monitoring of drift of process control parameters.
c. Information obtained from subcontractors
Information can be gathered through basic contractual documentation to be delivered to
customers, such as DML, DMPL and DPL. It is the responsibility of each customer in the supply
chain to ask its subcontractors to provide their obsolescence analysis. Such request can be done
e.g. during materials process control boards (MPCB), or even earlier during a preliminary review
milestone.
NOTE 1 The MMPP lists do not provide the entire design information.
NOTE 2 Performing MPCBs even for recurrent equipment, can be
recommended to track obsolescence issues.
d. Any other information
Information can also be found in literature, patents, and through networking. All the gathered
information can be systematically included in a dedicated tool for MMPP knowledge
management. It is important to maintain it up-to-date in order to facilitate subsequent risk
analysis.
16
---------------------- Page: 18 ----------------------
kSIST-TP FprCEN/CLC/TR 17602-70-23:2021
FprCEN/CLC/TR 17602-70-23:2021 (E)
6.1.4 Supply chain management
6.1.4.1 Overview
It is important to involve actively downstream supply chain actors in obsolescence management. It can
be done by specifying contractual obsolescence management requirements, through suppliers and
subcontractors monitoring, or by dedicate
...
