SIST EN 4710-03:2019

Aerospace series - Quick release fastening systems for non-structural applications - Part 03: Spring clamp

This standard specifies the dimensions, mass, tolerances and static values of catch spring for use in fuselage interior equipment and non-structural or secondary structural area. This standard part shall be used in conjunction with EN 4710-06 and EN 4710-07 as described in EN 4710-02.
The applicable temperature range is −55 °C to 85 °C.

Luft- und Raumfahrt - Druckverschlüsse nicht-strukturelle Anwendungen - Teil 03: Feder Clip

Diese Europäische Norm legt die Maße, Massen, Toleranzen und statischen Werte von Federclips für die Anwendung bei Inneneinrichtungen von Luftfahrzeugzellen und in nicht strukturellen oder Sekundär-strukturbereichen fest. Dieser Teil der Norm ist in Verbindung mit EN 4710 06 und EN 4710 07 wie in EN 4710 02 beschrieben an¬zuwenden.
Der Anwendungstemperaturbereich beträgt −55 °C bis 85 °C.

Série aérospatiale - Fixations rapides filetées pour applications non-structurales - Partie 03 : Collier Iyre

La présente Norme européenne spécifie les dimensions, la masse, les tolérances et les valeurs statiques des colliers lyre pour utilisation dans les équipements intérieurs et dans les zones non structurales ou structurales secondaires du fuselage. La présente partie de la norme doit être utilisée conjointement avec les EN 4710-06 et EN 4710-07 comme défini dans l’EN 4710-02.
La plage de températures applicable est comprise entre - 55 °C et 85 °C.

Aeronavtika - Spončni sistemi za hitro sprostitev za nestrukturno uporabo - 03. del: Vzmetna objemka

Ta standard določa dimenzije, maso, tolerance in statične vrednosti natezne vzmeti za uporabo v notranji opremi v trupu letala ter nestrukturnem ali sekundarnem strukturnem območju. Ta del standarda se uporablja v povezavi s standardoma EN 4710-06 in EN 4710-07, kot je opisano v standardu EN 4710-02.
Temperaturno območje delovanja je med −55 °C do 85 °C.
