Advanced Surface Movement Guidance and Control System (A-SMGCS) - Part 4: Community Specification for a deployed non-cooperative sensor including its interfaces - Sub-part 2: Specific requirements for a deployed Surface Movement Radar sensor

The present document is applicable to deployed non-cooperative SMR sensor as a constituent of an Advanced Surface
Movement Guidance and Control System (A-SMGCS).
NOTE 1: Generic requirements for a non-cooperative sensor are defined in ETSI EN 303 213-4-1 [1].
The present document provides a European Standard for manufacturers, Air Navigation Service Providers and/or
Airport Operators, who have to demonstrate and declare compliance of their systems and constituents to the Essential
Requirements (ERs) of Annex VIII of Regulation EU 2018/1139 [i.6].
NOTE 2: The ERs in Annex VIII of Regulation EU 2018/1139 [i.6] covered by the present document are outlined
in Table A.1.
NOTE 3: Although the ERs of the SES Interoperability Regulation [i.1] have been repealed with effect from
11 September 2018 [i.6], a mapping of the requirements for the A-SMGCS Surveillance Service to this
same regulation [i.1] is provided in Annex B.
Any software elements related to the software assurance level of an A-SMGCS are out of scope of the present
document. As such the ERs of Regulation EU 2018/1139 [i.6] are not considered for software elements within the
present document.
The present document does not give presumption of conformity related to the maintenance requirements, environmental
constraints, procedure level, effect of harmful interference and civil/military coordination.
NOTE 4: For these ERs, the Air Navigation Service Provider will need to provide supplementary compliance
within their Interoperability Technical Files.
The present document does not give presumption of conformity to any current interoperability Implementing Rules
(IRs).
NOTE 5: Currently there are no relevant Implementing Rules for A-SMGCS.
Requirements in the present document which refer to "should" statements or recommendations in the normatively
referenced material (clause 2.1) are to be interpreted as fully normative ("shall") for the purpose of compliance with the
present document if they are unambiguously referred to from the present document.
The reference to particular requirements is done either by citing the unambiguous requirement number or range of
numbers (e.g. "[REQ 30.] to [REQ 35.]") or, if no requirement numbers are available, by indicating the paragraph and
clause of the reference material where the requirement can be found.
NOTE 6: Other requirements and other EU Regulations and/or Directives may be applicable to the product(s)
falling within the scope of the present document.
