SIST EN 300 119-7 V1.1.1:2015

• Abstract:

  The new WI should detail requirements for subracks for use in harmonized racks/cabinets, as described in EN 300 119 7 [6]. The subrack will normally be supplied as a fully assembled structure, unequipped, partially equipped or fully equipped with plug-in units, etc.

• Status: Published
• Public Enquiry End Date: 31-Dec-2014
• Publication Date: 23-Apr-2015
• ICS: 19.040 - Environmental testing
• ICS: 33.050.01 - Telecommunication terminal equipment in general
• Technical Committee: SPN - Services and Protocols for Networks
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 11-Mar-2015
• Due Date: 16-May-2015
• Completion Date: 24-Apr-2015
• Ref Project: ETSI EN 300 119-7 V1.1.1 (2015-02) - Environmental Engineering (EE); European telecommunication standard for equipment practice; Part 7: Engineering requirements for Subracks in harmonized racks and cabinets with extended features

Overview

SIST EN 300 119-7 V1.1.1:2015 is a European standard developed under the Environmental Engineering (EE) series, focusing on the engineering requirements for subracks used in harmonized racks and cabinets with extended features in telecommunication environments. Published by SIST, this standard provides specifications that ensure interoperability, safety, and streamlined installation of subracks within standardized network infrastructure. These requirements apply to subracks supplied fully assembled, unequipped, partially equipped, or fully equipped with plug-in units.

This standard is vital for telecommunications equipment manufacturers, network infrastructure designers, and system integrators aiming to achieve high compatibility across various rack systems while accommodating advanced cabling and seismic needs.

Key Topics

• Harmonized Subrack Dimensions
  Defines height, width, and depth for subracks, including allowances for plug-in units and accessories. Specifications enable consistent fitting in both 300 mm and 600 mm deep racks, allowing for flexible installations, including back-to-back mounting in 600 mm racks.

• Mounting Solutions
  Addresses depth adjustment of subrack mounting brackets, making bracket positioning adaptable and supporting both European and international practices such as the EIA rack standards.

• Accessibility
  Ensures that subracks for 300 mm deep racks require only front access, facilitating installations against walls or back-to-back configurations.

• Weight Specifications
  Sets maximum weight for unequipped subracks (18 kg) for safe handling. Also includes guidance on providing equipped subrack weights for floor load calculations in data centers and telecom facilities.

• Extended Cabling Space
  Specifies additional front space to accommodate optical and electrical I/O cabling, improving cable management and accessibility.

• Seismic Considerations
  Aims to harmonize with international seismic requirements by aligning the mounting planes and rack depths to support earthquake-resistant installations.

Applications

• Telecommunication Networks
  Designed for public telecommunication networks and data center environments, ensuring that all housed subracks are compatible with harmonized racks and cabinets featuring extended mechanical and cable management features.

• Equipment Manufacturer Guidance
  Provides manufacturers with standardized design and assembly requirements, reducing customization overhead and promoting the development of interoperable plug-in units and systems.

• System Integration
  Streamlines the installation and maintenance process for system integrators managing different equipment from various suppliers, lowering installation complexity and ensuring consistent cable routing and access.

• Facility Planning and Safety
  Supports facility planners in meeting seismic, loading, and accessibility requirements, essential factors for safe, long-term operation in critical telecom and IT infrastructure.

Related Standards

• ETSI EN 300 119-1: Introduction and terminology for environmental engineering equipment practices
• ETSI EN 300 119-2: Engineering requirements for racks and cabinets
• ETSI EN 300 119-3: Engineering requirements for miscellaneous racks and cabinets
• ETSI EN 300 119-4: Subrack engineering for miscellaneous racks and cabinets
• ETSI EN 300 119-5: Preferred thermal management solutions for equipment
• ETSI EN 300 119-6: Requirements for harmonized racks and cabinets with extended features
• IEC 60917-2-2: Coordination dimensions for electronic equipment mechanical structures
• ECIA EIA/ECA-310-E: Cabinets, racks, and associated equipment (US standard)

---

Implementing SIST EN 300 119-7 improves the flexibility, safety, and interoperability of telecommunication infrastructure. Adoption of this standard underpins seamless integration, enhances cable management, and aligns European practices with global benchmarks for rack and subrack engineering.
